KneeRover PRO User Manual page 2

KneeRover
®
Please follow the step by step instructions on the following pages to
properly assemble your KneeRover
diagram below identifies the key components of the scooter to aid
with assembly. Visit kneerover.com for assembly videos.
Weight Capacity = 350 pounds
Handlebar Height
Adjustment
Knee Platform
Rear Brake
Mechanism
Integrated Shock
Technology
Pneumatic
12" Wheels
Set Up Instructions:
All Terrain scooter. The
®
Hand Brake Lever
Brake Cable
Steering Column
Quick Release
Clamp
Removable Front
Axle
Setup Instructions:
Step 1: Install Front Axle
Please take your time to carefully complete all steps before operating your new
KneeRover scooter. First, remove the kneepad from bottom of the scooter and
®
put aside for step 4. Next, place the front axle with 12" wheels under the
scooter frame, ensuring the round bolts by the wheels are facing up (as shown
below). Align the axle and frame holes, insert front axle bolts and tighten
completely using the allen wrench provided.
Step 2: Install Tie Rods
The fully assembled tie rods should be as follows (from top down): LEFT tie
rod, washer, black guide, washer, RIGHT tie rod, washer, and nut. Insert the
bolt into the top (LEFT) tie rod so that head of the bolt is sitting flush. Next
insert the bolt thru the washer and black guide (as shown below). Place a
washer and bottom (RIGHT ) tie rod onto bolt from below the black guide.
Finally insert a washer and nut, and then fully tighten.
Tie Rod
Bolt
Washer
Washer
Black Guide
Front Axle
Bolt
Scooter Frame
Front Axle
Round Bolt
Tighten
Nut
