- Page 1 MANGA Point User’s Manual (Last updated: 2004-06-14)
- Page 2 This document contains proprietary and confidential information of PePLink Ltd. The contents of this document may not be disclosed to third parties. Copies and duplicated in any form, in whole or in part, without prior written permission of PePLink Ltd is forbidden. This publication is subject to change without notice.
- Page 3 Connections between peripherals of this equipment may be made with low voltage non-shielded computer data cables. Network connections may consist of non-shielded CAT 5 cable. Use only PepLink approved wall adapter to supply 9 VDC to system. Indoor use only.
-
Page 4: Table Of Contents
CONTENTS INTRODUCTION..................1 What is MANGA Point?....................1 INSTALLATION.................... 2 Connecting Your Computer and Your MANGA Point ........2 Turning on Your MANGA Point................2 Login to MANGA Point....................3 CONFIGURATION..................5 Connect..........................5 CPE Setup........................6 Port Forward.........................9 Incoming Traffic Filter ....................10 Outgoing Traffic Filter ....................11 Specification.......................12... -
Page 5: Introduction
1 INTRODUCTION What is MANGA Point? MANGA Point is a network device for one or more PCs on a LAN to simultaneously access secure wireless broadband Internet service. With integrated 4 Ethernet switching ports and user-friendly web-based network administration features, MANGA Point can connect 4 PCs to the Internet without installing any wireless LAN adapter or configuring tedious wireless network settings on the PCs. -
Page 6: Installation
2 INSTALLATION Connecting Your Computer and Your MANGA Point For the initial configuration of your MANGA Point, connect your local computer LAN port to MANGA Point LAN port using straight-through Ethernet or crossover Ethernet cables. Turning on Your MANGA Point After you’ve made the connections, connect the power cable to a power supply and look at... -
Page 7: Login To Manga Point
INSTALLATION Login to MANGA Point Make sure your MANGA Point hardware is properly connected (refer to instructions in the hardware installation chapter 2.1). Launch your web browser. You should be redirected to MANGA Point web administration page. If you are not being redirected to web administration page, enter “192.168.1.1”... - Page 8 (Access Point). MANGA Point is registering and authenticating to Radius server. MANGA Point is obtaining an IP address from DHCP server. MANGA Point is connected to the Internet. Navigating the main menu items: Click on the item’s name to configure the corresponding item.
-
Page 9: Configuration
Password to login Radius server. IMPORTANT: If you are currently connected to the Internet, clicking the “Connect” button will disconnect the MANGA Point from Internet and Radio (Access Point). The status page will show the connection status. If connection failed, you can click Retry button to re-connect again. -
Page 10: Cpe Setup
CONFIGURATION CPE Setup LAN Interface – Configures IP address over the LAN interface. IP Address/Subnet Mask: Enter fixed IP address and its associated subnet mask. Default is 192.168.1.1/255.255.255.0. DHCP Server – Allows you to enable or disable the DHCP function. DHCP server is enabled by default. - Page 11 Enable/Disable: Enable or disable the DMZ function. Default is disabled. DMZ IP Address: This is an IP address of a LAN computer for which all incoming accesses to the MANGA Point’s WAN IP address will be redirected to. Wireless setup – Configures the wireless interface.
- Page 12 WAI Redirection – To configure whether to redirect all web accesses to the web administration page. The user will be redirected to web administration page for any URL if MANGA Point is not connected to Internet. Enable/Disable: Enable or disable the WAI Redirection function.
-
Page 13: Port Forward
Port Forward Port forward can be used to set up public services on your network. When a user from the Internet makes certain request on your network, the MANGA Point can forward the request to specific computer which handles the request. -
Page 14: Incoming Traffic Filter
CONFIGURATION Incoming Traffic Filter Configure the MANGA Point to block specific external traffic from Internet to internal network. You can set up different filters based on the network protocol and port number. To modify the filter setting: 1. Select a filter entry using the Filter box. -
Page 15: Outgoing Traffic Filter
CONFIGURATION Outgoing Traffic Filter Configure the MANGA Point device to block specific external traffic from internal network to Internet. You can set up different filters based on the network protocol and port number. To modify the filter setting: 1. Select a filter entry using the Filter box. -
Page 16: Specification
CONFIGURATION Specification Technical Specification - Standard IEEE 802.3 and 802.3u 10Based-T and 100Based-TX IEEE 802.11g standard compliant IEEE 802.11x standard compliant - Media Access Protocol: IEEE 802.11g and IEEE 802.11b - Data Rate: 54Mbps/48Mbps/36Mbps/24Mbps/11Mbps/5.5Mbps/2Mbps/1Mbps - Modulation Technique OFDM/DSSS, BPQSK, QPSK/CCK Hardware Specification - Four port 10/100Base-T RJ-45 Ethernet switch - Reset button... -
Page 17: Troubleshooting
3. Can’t browse through the MANGA Point from the LAN Check the TCP/IP settings on the client side. Verify that the IP addresses and subnet masks of the MANGA Point and the computer on the LAN are on the same subnet. 4. Connection failed in the connection status page The WAN IP address is provided when the login authentication is successful.
