Wireless Base Stations
▫
and Client Devices
Surveillance Cameras
▫
Remote Control
▫
Remote Lighting
▫
Off Grid Electronics
▫
Congratulations! on your purchase of the TPDIN-SC48-20
20A MPPT Solar Controller with 7 Port Gigabit Passive PoE
Switch. Please take a moment to review this Qwik Install Guide
before use.
Operation Modes: Solar Only operation, Solar with DC Back-
up, DC Only operation.
Key Features: Industrial Strength, Manageable, 24VDC or
48VDC Output, 7 Gigabit Passive PoE ports, 48V 20A MPPT So-
lar, Automated Alerts, Removable Connections
Safety:
For your own protection, follow these safety rules.
▫
Perform as many functions as possible on the ground
▫
Do not attempt to install on a rainy, windy or snowy day or if
there is ice or snow accumulation at the install site or if the
site is wet.
▫
Make sure there are no people, pets, etc. below if you are
working on a roof or ladder.
Recommended Tools: Small Flat Blade Screwdriver, Phil-
lips Screwdriver
Please help preserve the environment and return
any used batteries to an authorized depot
TPDIN-SC48-20
MPPT Solar Controller
with Passive PoE Switch
Advertisement
Related Manuals for Tycon Power Systems TPDIN-SC48-20
Summary of Contents for Tycon Power Systems TPDIN-SC48-20
- Page 1 Remote Lighting ▫ Off Grid Electronics ▫ Congratulations! on your purchase of the TPDIN-SC48-20 20A MPPT Solar Controller with 7 Port Gigabit Passive PoE Switch. Please take a moment to review this Qwik Install Guide before use. Operation Modes: Solar Only operation, Solar with DC Back- up, DC Only operation.
- Page 2 STEP 1: Remove Large 4 Pin and Small 2 Pin Green connectors from the top of the unit. STEP 2: Attach the TPDIN-SC48-20 to a DIN Rail mount. To mount to a flat plate remove the DIN Rail bracket from the back by removing 5 screws and mount to a plate using the two wall mount tabs provided.
- Page 3 el of the controller. Note: System and Control pages are broken into small sections. If you make changes to the small section you need to save each section individually. STEP 9: Open your browser and type the IP address of the con- troller into the browser address field.
- Page 4 manual control or auto control (time, voltage or temperature). Time Settings: Enable and set Network Time Protocol (NTP) and set time zone (Mountain time is GMT –7). Sync internal clock with PC. Misc Settings: Set log file write interval. Data Logger holds up to15,000 records.
- Page 5 Ping Control: There are two ping controls which can be setup to ping any of the ports. If the ping fails then that port will be power cycled. Email Alerts: The controller supports emailing alerts via any smtp mail server. Alerts can be set for under voltage, over current, ping fail- ures or periodic status emails.
-
Page 6: Specifications
PoE voltage selected. Passive PoE voltage is supplied on Ethernet pins 4,5(V+) and 7,8(V-). SPECIFICATIONS Subject to change without notice TPDIN-SC48-20 Controller Type MPPT Solar Input Voltage 62VDC to 85VDC... -
Page 7: Reset To Factory Defaults
TECH CORNER Additional Information you may find useful RESET TO FACTORY DEFAULTS: There is a button on the top of the controller labelled FACTORY DEFAULT. Pressing and holding this button for over 5 seconds will reset to factory defaults. RESET the CONTROLLER: There is a button on the top of the controller labelled RESET. - Page 8 This will import to excel with all the data columns intact. Limited Warranty The TPDIN-SC48-20 Solar Controller with PoE Switch is supplied with a limited 24 month warranty which covers material and workmanship defects. This warranty does not cover the following: ...
