- Page 1 FLOW engineering Instruction Manual P/N: 77-43010 Make: Ford Model: Focus ST Year: 2013-2014 Engine: L4-2.0L EcoBoost...
- Page 2 • Please read the entire instruction manual before proceeding. • Ensure all components listed are present. • If you are missing any of the components, call customer support at 951-493-7100. • Ensure you have all necessary tools before proceeding. • Do not attempt to work on your vehicle when the engine is hot. •...
- Page 3 aFepower.com Page 3...
- Page 4 REMOVAL Figure A Refer to Figure A for step 1-3 Sleep Mode Before installing your aFe Module you will have to place your vehicles ECU in sleep mode. In order to place your vehicles ECU in sleep mode you will need to do the following: Sep 1: If the engine is cold, open the hood, close the doors, lock the car and wait 30 seconds Step 2: If the engine is warm, open the hood, close the doors, lock the car and wait 20 minutes Step 3: If the engine is warm and you can’t wait 20 minutes, disconnect the battery...
- Page 5 REMOVAL Figure B Refer to Figure B for steps 4-5 Step 4: Remove the engine cover. Step 5: Unplug your MAP sensor first located on the elbow connecting to the OE air box. aFepower.com Page 5...
- Page 6 INSTALL Figure C Refer to Figures C for steps 6-7 Step 6: Locate your MAP jumper harness on your aFe module. It is the 2 wire harness with grey and black colored wires. Step 7: Plug the large connector on to the stock engine harness and the small connector to the MAP sensor.
- Page 7 INSTALL Figure D Refer to Figure D for steps 8-10 Step 8: Unplug your CACT sensor second located on the intercooler inlet side under the passenger headlight. Step 9: Locate your CACT jumper harness on your aFe module it is the 4 wire harness with a violet and green colored wires.
- Page 8 Neatly zip tie your aFe module harness on to your stock harness. Step 12: Re-install the engine cover. The blue LED light indicates that all processes are complete and ready to go. Your installation is now complete! Thank you for choosing aFe Power! Page 8...
- Page 9 This page left blank intentionally. aFepower.com Page 9...
- Page 10 Air Intake System Air Filter aFe Shirt aFe Watch P/N: TR-5305B-R P/N: 10-10133 P/N: 40-30372 M P/N: 40-10125 P/N: 40-30373 L P/N: 40-30374 XL P/N: 40-30375 2XL aFe Flashlight aFe Hat aFe License Plate aFe Euro Plate P/N: 40-10131 P/N: 40-10114 P/N: 40-10097 P/N: 46-33017 To purchase any of the items above, view airflow charts, dyno graphs, photos, and video please go to aFepower.com.
-
Page 11: Warranty
Warranty General Terms: • aFe warrants their products to be free from manufacturer’s defects due to workmanship and material. • This warranty applies only to the original purchaser of the product and is non-transferrable. • Proof of purchase of the aFe product is required for all warranty claims. •... - Page 12 advanced FLOW engineering, inc. 252 Granite Street Corona, CA 92879 TEL: 951.493.7100 E-Mail:Tech@aFepower.com P/N: 06-80695...
