Hidrotermal HIDRO-HMT300 User Manual

Swimming training pump hidro-hmt series

Advertisement

Quick Links

IMPORTANT SAFETY INSTRUCTIONS

This appliance must be installed by qualified electrician according
to national wiring rules.
When installing and using this electrical equipment, basic safety
precautions should always be followed, including the following:
1.READ AND FOLLOW ALL
INSTRUCTIONS
2.WARNING To reduce the risk of injury.
do not permit children to use this product
unless they are closely supervised at all
times.
3.WARNING Risk of Electrical Shock.
Connected only to grounding type rece-
ptacle protected by a ground fault circuit
interrupter(GFCI). Contact a qualified
electrician if you cannot verify that the
receptacle is protected by GFCI.
4.CAUTION Do not bury cord. Locate
cord to minimize abuse from lawnmowers,
hedge trimmers, and other equipment.
5.CAUTION
In case the running
parts will injure people, don't make
the electric pump running before then
pipeline have been connected.
6.WARNING To reduce the risk of
electrical shock, replace damaged
cord immediately.
7.WARNING To reduce the risk of
electrical shock, do not use extension
cord to connect unit electric supply;
a properly located outlet.
provide
8.CAUTION The pump is suitable
for swimming pool.
Contact your local government for information regarding the collection
systems available.
If electrical appliances are disposed of in landfills or dumps, hazardous
substances can leak into the groundwater and get into the food chain,
damaging your health and well-being.
SWIMMING TRAINING PUMP
USER MANUAL
HIDRO-HMT SERIES PUMP
9.Do not install within an outer encl-
osure or beneath the skirt of a hot tub
unless so marked.
10
. This appliance can be used by
children aged from 8 years and above
and persons with reduced physical,
sensory or mental capabilities or lack
of experience and knowledge if they
have been given supervision or instru-
ction concerning use of the appliance
in a safe way and understand the
hazards involved. Children shall not
play with the appliance. Cleaning and
user maintenance shall not be made
by children without supervision.
11. Keep the appliance and its cord out
of reach of children less than 8 years.
12.Children should be supervised to
ensure that they do not play with the
appliance.
13. Household use only.
14. Do not dispose of electrical applia-
nces as unsorted municipal waste, use
separate collection facilities.
SAVE THESE INSTRUCTIONS
15.
-1-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HIDRO-HMT300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hidrotermal HIDRO-HMT300

  • Page 1: Important Safety Instructions

    SWIMMING TRAINING PUMP USER MANUAL HIDRO-HMT SERIES PUMP IMPORTANT SAFETY INSTRUCTIONS This appliance must be installed by qualified electrician according to national wiring rules. When installing and using this electrical equipment, basic safety precautions should always be followed, including the following: 1.READ AND FOLLOW ALL 9.Do not install within an outer encl- INSTRUCTIONS...
  • Page 2 1.General swimming 2.lnstallation 3.Pipe Assembly 4.Electrical connection 5.Controls Prior to Initial Start-up...
  • Page 3: Trouble Shooting Guide

    -Is there a leak in the piping or the pump? PROPERLY -Is the proper voltage applied to the pump? LOW VOLTAGE -Is there an extension cord being used? Performance curves U .S .GPM IMP.GPM (ft) (psi) 2900r/min HIDRO-HMT550(H) HIDRO-HMT350(H) HIDRO-HMT400(H) HIDRO-HMT300(H) 1200 1500 l/min m /h Flow...
  • Page 4 Installation diagram Vacuum hose Vacuum head Water pump Stand filter Qmax Power Hmax Model (l/min) (kW) 1100 HIDRO-HMT300(H) G2 / HIDRO-HMT350(H) 1210 11.5 HIDRO-HMT400(H) 1300 4FBT HIDRO-HMT550(H) 1500 17.5 V / Hz esp: See pump nameplate. Liquid temperature: 4 ~ 50 Storage temperature: -10 +50 .
