Trust BT-2200Tp Manual

BT-2200Tp Bluetooth 2.0 EDR USB Adapter
Product information
Adapter
A: USB plug protective cap
B: Status LED Lit continuously: On Flashing: Bluetooth activity
C: USB extension cable

Installation

Turn on the PC and insert the Trust installation CD-ROM into the CD-ROM drive.
1
2 Close all other programs and select "Install driver".
3 Click "Next" until window 4 appears.
4 Click "OK".
5 A window will be displayed which requests you to connect the adapter. Do not press the buttons.
Connect the Bluetooth adapter to a USB port. If necessary, use the USB extension cable.
6
A: If a window is displayed which states that the driver is not digitally signed, click "Next".
7 B: Click "Finish". If the Bluetooth icon in the task bar appears red, then see the Troubleshooting
section.
If you are requested to restart the computer, select "Yes".
8

Configuration

9 Double-click the Bluetooth icon in the taskbar
Click "Next".
10
11
Enter a different computer name (optional) and click "Next".
Select "Services" (optional) and click "Next". You will now have to wait. If requested, do not restart the
computer.
12
Some services can only be selected if the required hardware (such as a modem) is present in the
system.
13 Click "Skip".
14 Click "Finish". If requested, restart the computer.

Connecting to other devices

If necessary, make the other Bluetooth device detectable (press the connect button for a couple of
15
seconds). Also see the instruction manual provided with the device.
16 Double-click the Bluetooth icon in the taskbar. My Bluetooth Locations will be opened.
17 Click "Search for devices in range".
Double-click the desired device.
18
Next, double-click the desired service.
19
20 Click in the "Bluetooth PIN code Required" window.
A: Enter the device's PIN code. PIN code information (may be different):
21
Pairing with device type PIN code
1
UK
