Trust BT-1300TP Manual

BT-1300TP BLUETOOTH USB ADAPTER
Product information
Adapter
A: USB plug protective cap
B: Status LED
C: USB extension cable

Installation

Turn on the PC and connect the Bluetooth Adapter to a free USB port. If necessary, use the USB
1
extension cable.
Windows XP Service Pack 2: wait until Windows states that the device is ready for use.
2
Windows XP Service Pack 1 and Windows 2000: click "Cancel".
3 Insert the Trust installation CD-ROM into the CD-ROM drive.
4 Close all other programs and select "Install driver".
5 Click "Next" until window 6 appears.
6 Click "OK".
Click "Finish". If the Bluetooth icon appears red, then see the Troubleshooting section.
7
8 If you are requested to restart the computer, select "Yes".

Configuration

Double-click on the Bluetooth icon in the taskbar
9
Click "Next".
10
11
Enter a different computer name (optional) and click "Next".
Select "Services" (optional) and click "Next". You will now have to wait. If requested, do not restart the
computer.
12
Some service can only be selected if the required hardware (such as a modem) is present in the
system.
13 Click "Skip".
14 Click "Finish". If requested, restart the computer.

Connecting to other Bluetooth devices

If necessary, make the other Bluetooth device detectable (press the connect button). Also see the
15
instruction manual provided with the device.
16 Double-click the Bluetooth icon in the taskbar. My Bluetooth Locations will be opened.
17 Click "Search for devices in range".
A: Right-click the discovered device.
18
B: Select "Pair Device".
19 Click in the "Bluetooth PIN code Required" window.
Lit continuously: On Flashing: Bluetooth activity
1
UK
