Pyle Pro AZR6XA Owner's Manual page 4

Connecting to standard AC power
After making all other connections, set the POWER switch
to OFF position. Then connect the power cord to a standard
AC outlet.
Mounting the amplifier
This amplifier is designed to accept standard rack mounting
installations. Two slots on each end of the front panel make
it suitable for such an installation.
Tightly secure four mounting screws (not supplied) through
these fours slots and into your standard electronics equipment
rack.
Turning the amplifier on
1. Turn on the audio input source equipment which is
connected to the amplifier INPUT jacks.
2. Set the amplifier's Channel 1 and Channel 2 output level
gain controls to the minimum level settings.
3. Push in the power switch to turn the amplifier on.
Using the power blue LED meters
The meter pointer position indicates the amplifier output
power. For ease of reading in dark environments, the meter
is illuminated.
Caring for your Pyle Pro Amplifier
Your Pyle Pro Amplifier is an example of superior design
and craftsmanship. The following suggestions will help you
care for your amplifier so you can enjoy years of use:
• Keep the amplifier dry. If it gets wet, wipe immediately.
• Use the amplifier only in well-ventilated installations.
• Handle the amplifier gently and carefully - do not drop!
• Keep the amplifier away from dust and dirt.
• Wipe occasionally with a damp cloth to keep it looking
new. Do not use harsh chemicals, solvents or
detergents!
4 – PYLE PRO PZR6XA/10XA/30XA/50XA Amplifier Owner's Manual
Using the Channel 1 and Channel 2 Output Level controls
Rotate output level gain clockwise to increase, or counter-
clockwise to decrease the output power. To get the best
performance with the least sound distortion, always adjust
the output level gain so the meter's pointer does not
continuously exceed the extreme right of the meter's scale.
CAUTION: It is possible to overdrive the amplifier by
setting output level gain too high, which may cause
damage or failure.
About the internal clip circuitry
Special clip circuitry incorporated into your Pyle Pro
amplifier's design protects the amplifier and speaker system
from being damaged from overdriving power.
Under normal conditions, the amplifier's clip indicator will
flicker as the output power momentarily exceeds the level
as set by the output level gain selector.
However, under excessive output conditions, the clip
indicator lights remain on continuously, alerting you that
the special clip circuitry has become active. When this
occurs, you should simply reduce the output power level
by rotating the Master Volume control counterclockwise.
Limited Warranty
All PYLE PRO products are carefully constructed and tested before shipment.
Units purchased in the USA are warranted to be free of defects in material
and workmanship for two (2) years from the date of purchase. This warranty
is limited to the original retail purchaser of the amplifier.
Should the unit fail due to factory defects in material or workmanship, your
unit will be repaired or replaced at the sole discretion of PYLE.
To obtain warranty service, you must first call our Consumer Return Hotline
at (718) 236-6948 to obtain a Return Authorization Number. This R.A. # must
appear on the outside of your package and on all paperwork relating to your
return.
When returning the unit to us for warranty service, it must be carefully packed
and shipped, prepaid, to:
R.A.#: _____________
PYLE PRO Service Center
1600 63rd Street
Brooklyn, NY 11204
You must also include the following items with your return:
• A copy of your sales receipt or other proof of purchase
• A brief letter, indicating the problem you are experiencing with the
product
• Include in your letter your return address, daytime phone number and
R.A. number
• Also include a check or money order for $15.00 for return shipping,
handling and insurance, or provide your Visa/MC number with
expiration date.
Our obligation under this warranty is limited to the repair or replacement of
the defective unit when it is returned to us prepaid. This warranty will be
considered void if the unit was tampered with, improperly serviced or subject
to misuse, neglect or accidental damage.
Amplifier Specifications PZR6XA
Input Impedance, balanced (unbalanced) 20 k-Ohms (10 k-Ohms)
Continuous Output Power
Stereo Mode
70W x 2
20 Hz to 20 kHz, 8 Ohms
100W x 2
1 kHz, 4 Ohms
110W x 2
Maximum Power, 8 Ohms
130W x 2
Maximum Power, 4 Ohms
1100W x 2
Peak Power, 8 Ohms
Bridged Mode
175W x 1
20 Hz to 20 kHz, 8 Ohms
200W x 1
1 kHz, 8 Ohms
2200W x 1
Peak Power
THD 0.1%
at rated output power
Frequency Response 10 Hz to 50 kHz
+/– 3 dB
Input Sensitivity 1.0V
for rated output power
Signal-to-Noise Ratio 100 dB
A-Weighted
Speaker Impedance
4-16 Ohms
Stereo
8-16 Ohms
Bridged
Power Requirement 120 VAC, 60 Hz / 230 VAC, 50 Hz
Dimensions 3 x 19 x 10
H x W x D, inches 15/32 11/16
(88 x 482 x 271)
(mm)
Weight, lbs (kg) 16.5 (7.5)
PYLE PRO PZR6XA/10XA/30XA/50XA Amplifier Owner's Manual - 5
PZR10XA PZR30XA PZR50XA
20 k-Ohms (10 k-Ohms) 20 k-Ohms (10 k-Ohms) 20 k-Ohms (10 k-Ohms)
170W x 2 200W x 2
220W x 2 300W x 2
230W x 2 230W x 2
260W x 2 350W x 2
1650W x 2 2200W x 2 2750W x 2
380W x 1 500W x 1
440W x 1 600W x 1
3300W x 1 4400W x 1 5500W x 1
0.1% 0.1%
10 Hz to 50 kHz 10 Hz to 50 kHz 10 Hz to 50 kHz
1.0V 1.0V
100 dB 100 dB
4-16 Ohms 4-16 Ohms 4-16 Ohms
8-16 Ohms 8-16 Ohms 8-16 Ohms
120 VAC, 60 Hz 120 VAC, 60 Hz
3 x 19 x 10 5 x 19 x 15 5 x 19 x 15
15/32 11/16 3/16 3/8 3/16
(88 x 482 x 271) (132 x 482 x 390) (132 x 482 x 390)
20.02 (9.1) 28.16 (12.8) 29.7 (13.5)
260W x 2
400W x 2
300W x 2
450W x 2
700W x 1
800W x 1
0.1%
1.0V
100 dB
3/8
