ergolet Helios/150 User Manual

Mobile hoist
Hide thumbs
Table of Contents

Advertisement

Quick Links

Helios/150
Mobile hoist
r m
User manual
Important information
Please read this user manual carefully
before using the product!
This user manual is intended as a guide
for caregivers and other users, as well as
technical personnel during servicing and
maintenance of the product.
maintenance of the product.
Date: 04-05-2017
Ver: 3

Advertisement

Table of Contents

Troubleshooting

loading
Need help?

Need help?

Do you have a question about the Helios/150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ergolet Helios/150

Summary of Contents for ergolet Helios/150

  • Page 1 Helios/150 Mobile hoist User manual Important information Please read this user manual carefully before using the product! This user manual is intended as a guide for caregivers and other users, as well as technical personnel during servicing and maintenance of the product.

  • Page 3: Table Of Contents

    CONTENTS 1 AIM AND USE ____________________________________________ 4 Purpose __________________________________________ 4 Safety instructions __________________________________ 4 Before use ________________________________________ 5 Terminology _______________________________________ 5 Unpacking ________________________________________ 7 Assembly instruction ________________________________ 7 Spreader bar and lifting slings _________________________ 9 2 FUNCTIONS _____________________________________________ 10 Pictograms and functions – Control-box _______________ 10 Pictograms and functions –...

  • Page 4: Aim And Use

    Helios/150 is a mobile hoist designed to transfer persons in institutions such as nursing homes, hospitals, care centres and in home care. Helios/150 can be used for transfer between bed and chair/wheelchair, from chair to another chair and from chair to a toilet.

  • Page 5: Before Use

    Before use The carer/helper is responsible for ensuring that a check is carried out BEFORE the mobile hoist and accessories are used, including the following: The following items are checked before use: • Check that the mobile hoist is complete and no parts are missing. •...
  • Page 6 Hoist with electric leg spreading (Fig 1.4b) Handles Lifting arm Hand control Actuator Spreader Control box, emergency stop Mast Base electric leg spreading Fig. 1.4b...

  • Page 7: Unpacking

    Unpacking Check that all the parts are present and undamaged. Any suspicion of damage or shortage should be reported to your dealer or Winncare Nordic ApS. We recommend that the box packaging is kept if the mobile hoist is to be used on other sites or for return shipment in case of repair or annual check.
  • Page 8 3. Assemble the actuators piston rod to the lifting arm. Use a 5mm Allen key and a 13mm spanner to tighten the bolt /nut. (Fig. 1.6D+1.6E). Put the cap on the nut. Fig. 1.6D Fig. 1.6E 4. The hand control, lifting arm and electrical leg spreader are connected to the control box.

  • Page 9: Spreader Bar And Lifting Slings

    Spreader bar and lifting slings The mobile hoist is equipped with a spreader bar, which is designed for use with Winncare Nordic ApS lifting slings. Winncare Nordic ApS ´s lifting slings have 4-6 lifting straps and are designed for lifting hooks larger than ø8mm. If using non-authorized slings, Winncare Nordic ApS will have no responsibility for faults or accidents.

  • Page 10: Functions

    2 FUNCTIONS Pictograms and functions – Control-box (1) Connecting plug – power supply (2) Connecting plug – hand control (3) Connecting plug - lifting actuator (4) Connecting plug - electrical leg spreading (5) Emergency stop – See section 2.3 (6) Charge – indicates charging on the battery (see section 2.4).

  • Page 11: Pictograms And Functions - Hand Control

    Pictograms and functions – Hand control Manuel leg spreading 1. Up – Press the button continuously and the lift moves upwards. The lift will stop by releasing the button. 2. Down – Press the button continuously and the lift moves downwards. The lift will stop by releasing the button.

  • Page 12: Safety Functions

    Safety functions Emergency stop: This function is only to be used in an emergency e.g. if the mobile hoist does not react or does not stop after pressing a button on the hand control. If the emergency button has been activated all functions immediately stop.

  • Page 13: Transport

    Battery alarm: If the power of the battery is low, an audible alarm will sound when the hand control is activated. Charge directly from the wall outlet 1) Make sure that the emergency stop is not pressed in. 2) Insert the plug into the mains. 3) The cable from the charger to the mains must be loose.

  • Page 14: Maintenance

    4 CHECK AND TROUBLESHOOTING Annual check Helios/150 must be inspected at least annually in accordance with EN/ISO 10535, Annex B, which recommends that a qualified person with knowledge to the product carries out a service and weight test.

  • Page 15: Troubleshooting

    Troubleshooting Fault: The hoist does not react Possible cause: Emergency stop is activated. when the hand control Solution: Release the emergency stop (see section 2.3) buttons UP/DOWN are Possible cause: Defect hand control. used. Solution: Try using another hand control. Alternative is to get a new hand control from the dealer and Winncare Nordic ApS.

  • Page 16: Technical Specifications And Dimensions

    5 TECHNICAL SPECIFICATIONS AND DIMENSIONS Technical specifications Lifting properties: Load capacity: 150 kg Number of lift movements: 40 cycles per charge with 80kg / 0,5 m Duty cycle: 10%, max, 2 min/18 min Manual emergency lowering: Electronic lowering: Electrical details: Power supply (Input): 100-240 VAC 50/60 Hz, max 0,35 A Output voltage:...

  • Page 17: Dimensions

    Dimensions Highest point Maximum reach point Lowest position a) Max. reach at 600 mm (reference height): 554mm b) Max. reach from base: 554mm c) Reach from base with legs spread to 700 mm: 319mm d) Min. Dist. from wall to CSP* at max.

  • Page 18: Enviroment And Quality

    6 ENVIROMENT AND QUALITY Helios/150 has an expected life time of a minimum of 10 years under the assumption that all recommended service checks have been carried out and that the normal maintenance and care instructions have been followed. Disposal Disposal of this mobile hoist can be made through Winncare Nordic ApS.

  • Page 19: Symbols And Abbreviations

    Symbols and abbreviations Direct current Double insulated The patient is not separated from the ground and the chassis Refer to user instruction The product should be reused where possible Safe working load (user + sling) The product is CE-marked.
  • Page 20 93/42/EØF CLASS I EN/ISO 10535 EN 60601-1-2 UM-910-00779UK...
