System Build 7445059COM Instruction Booklet page 9

Wall cabinet
Hide thumbs

Advertisement

STEP 3
Insert two cam locks into both the back rail (E) and bottom rail (I) as shown. Insert the steel
dowels into each part as shown.
systembuild.com
(x4)
(x5)
#A22570
#A21500
E
I
9
Quick
Assembly
Tip
Proper orientation of CAM LOCK
