System Build 7461315COM Manual

2 door / 1 drawer base cabinet
Hide thumbs

Advertisement

Available languages

Available languages

Quick Links

Download this manual
7461315COM
2 Door / 1 drawer Base Cabinet
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-866-452-4081 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.systembuild.com
WARNING
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
Easy
Assembly Difficulty Meter
For the latest information on SystemBuild products
follow us at Ameriwood Home
B347461315COMT1
Tough
You
Tube

Advertisement

loading
Need help?

Need help?

Do you have a question about the 7461315COM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for System Build 7461315COM

Summary of Contents for System Build 7461315COM

  • Page 1 7461315COM 2 Door / 1 drawer Base Cabinet B347461315COMT1 Date of Purchase ___ / ___ / ___ Lot Number: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Do Not Return This Product! Contact our customer service team for help first.

  • Page 2: Helpful Hints

    Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Assembly Tips Call us! 1-866-452-4081 Monday-Friday 9am - 5pm CST Tube Visit systembuild.com to view the limited warranty valid in the U.S. and Canada. Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 1-2 ESTIMATED ASSEMBLY TIME: 1 HOUR...

  • Page 3: Before You Start

    Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: Flat Head Screwdriver, #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight.

  • Page 4: Board Identification

    Board Identification Not actual size Right Panel Left Panel Bottom 37461315010 37461315020 37461316030 37461315040 Drawer Front Left Door Back Rail Right Door 37448316050 37461315060 37461315070 37461315080 Drawer Bottom Left Drawer Side Right Drawer Side Drawer Back 37461316100 37461316120 37461316090 37461316110 systembuild.com...
  • Page 5 Board Identification Not actual size Drawer Brace Adjustable Shelf Stringer 37461000130 37461316140 37461315150 This piece is paperboard construction. It is not made from Left Panel wood, but is required for the 37461315010 assembly of your unit. Parts List ITEM PART NUMB DESCRIPTION 37461315010 LEFT PANEL...

  • Page 6: Part List

    Part List Actual Size (x7) (x24) (x40) (x7) (x4) (x2) #A22610 #A12100 #A11120 #A21110 #A22620 #A80250 7/16" pan head cam lock cam bolt 1/2" pan head nail shelf support (x6) (x3) (x22) (x4) (x3) #A23700 #A13800 #A11600 #A13410 #A21520 vinyl cap 2-1/4"...
  • Page 7 Part List Not Actual Size (x4) (x2) (x4) #A43610 #A92510 #A43600 leg mount base plate adjustable leg (x1) (x2) #A55015 #A54220 lock drawer bracket (x1) #A56100 drawer slide systembuild.com...
  • Page 8 STEP 1 (x1) #A56100 Extend the slide as shown. Press the release lever and remove the inner slide. release lever Use these holes to fasten to the left and right panels (A&B). Use these holes to fasten to the left and right drawer sides (I&J). inner slide systembuild.com...
  • Page 9 STEP 2 (x2) (x1) (x3) (x1) #A22620 #A22610 #A12100 #A56100 Position the drawer slide (without inner slide) from step 1 as shown. Start by attacing the slide at the rear. While sliding the middle of the slide locate the holes in the panels with the access hole in the slide and fasten with screws (4) as shown.
  • Page 10 STEP 3 (x2) (x1) (x3) (x1) #A22620 #A22610 #A12100 #A56100 Position the drawer slide (without inner slide) from step 1 as shown. Start by attacing the slide at the rear. While sliding the middle of the slide locate the holes in the panels with the access hole in the slide and fasten with screws (4) as shown.
  • Page 11 STEP 4 loosen to separate (x4) #A65615 systembuild.com...
  • Page 12 STEP 5 (x1) #A84050 (x4) #A22610 (x3) #A13800 Do not tighten scerw. raw surface Be sure the back rail (E) is centered on the top (C). systembuild.com...
  • Page 13 STEP 6 Quick Assembly (x2) (x2) Proper orientation of CAM LOCK #A22620 #A21610 7/16" Approx. systembuild.com...
  • Page 14 STEP 7 Note: All finished edges face up. systembuild.com...
  • Page 15 STEP 8 (x4) #A13410 finished edge systembuild.com...
  • Page 16 STEP 9 (x4) (x4) (x4) #A11600 #A43610 #A43600 Fasten the leg mount (16) to the bottom (D) with screws (9). Press the leg sleeve (15) into the leg mount (16). Screw the adjustable leg (15) completely into the leg sleeve (15). systembuild.com...
  • Page 17 STEP 10 IMPORTANT! THE BACK PANEL IS A STRUCTURAL PART OF THIS UNIT AND MUST BE INSTALLED PROPERLY. (x34) #A21110 Carefully turn your unit over on its front side. Assure that the unit is square. Distance from corner to corner must be equal as shown. Attached the back panel as shown nailing straight into the raw edges.
  • Page 18 STEP 11 (x2) #A54220 Lay the drawer sides down on a flat hard surface. Carefully line up the drawer bracket with the holes in the drawer side as shown. Using a hammer, tap each bracket stem part way into each hole.
  • Page 19 STEP 12 (x6) (x2) #A12100 #A56100 (inner slide from step 1) systembuild.com...
  • Page 20 STEP 13 (x4) (x1) (x1) (x1) #A12100 #A22620 #A22610 #A21520 Be sure groove in drawer sides line up with grove in drawer front. Quick Assembly Proper orientation of CAM LOCK 7/16" Approx. systembuild.com...
  • Page 21 STEP 14 Attached drawer brace (M) to the drawer front (F) as shown. Slide the drawer bottom (L) into the groove in the left drawer side (I), right drawer side (J) and drawer front (F). unfinished surface systembuild.com...
  • Page 22 STEP 15 (x6) #A11600 systembuild.com...
  • Page 23 STEP 16 (x2) (x1) (x2) (x1) #A11120 #A23700 #A52995 #A55015 optional systembuild.com...
  • Page 24 STEP 17 (x1) (x4) (x2) (x2) (x1) #A12100 #A52995 #A65615 #A23700 #A92510 systembuild.com...
  • Page 25 STEP 18 (x4) (x2) (x1) (x2) (x1) #A12100 #A23700 #A52995 #A65615 #A92510 systembuild.com...
  • Page 26 STEP 19 If needed, adjust the adjustable legs to level your unit. For Masonry, Concrete, or other wall materials: Consult your local hardware store for appropriate anchors to securely attach the safety bracket. IMPORTANT: THIS UNIT MUST BE SECURE TO THE WALL TO HELP PREVENT TIPOVER. FOLLOW THESE INSTRUCTIONS TO INSTALL THE ANTI-TIPPING SAFETY BRACKET PROVIDED WITH THIS PRODUCT.
  • Page 27 STEP 20 Loosen screw A Loosen screw C Loosen screw C Adjust door. Turn screw B to Adjust door. Tighten screw A move door. Tighten screw C Tighten screw C *side view Insert the four shelf supports (3) and set the adjustable Suelte el tornillo A Acomode la puerta.
  • Page 28 STEP 21 Install the drawer by inserting the inner slide into the track of the middle slide and press completely in. You will need to push forcefully onto the drawer front to fully engage the slides. The locking bar of the lock when locked will engage the hole in the bottom surface of the top. systembuild.com...

  • Page 29: Maximum Loads

    Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. 40 lbs 18.1 kg 75 lbs 34 kg 50 lbs 22.7 kg 50 lbs 22.7 kg Warning: Risk of injury to persons - do not place a television on this furniture.
  • Page 30 Register your product to receive the following: * New trend details - sneak peek on what's new * Surveys - have a voice within our community * Exclusive deals and discount codes * Quick and easy replacement part service To register your product, visit systembuild.com Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You"...
  • Page 31 Español Cubierta Delantera Este libro de instrucciones contiene información IMPORTANTE de seguridad. Por favor lea y manténgalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda. Llamenos al: 1-866-452-4081 (Gratis) Lunes - Viernes 9am - 5pm CST Visitar: www.systembuild.com PRECAUCION Este mueble puede volcarse y causar graves heridas y/o muerte.
  • Page 32 Español Página 13 Conecte los panel trasero como se muestra clavando directamente en los bordes sin procesar. Asegura qie e; inidad es cuadrada. Distancia de esquina a esquina debe ser igual como se muestra por favor. IMPORTANT: El Panel trasero es una parte estructural de la unidad y debe ser instalado correctamente.
  • Page 33 Español Página 16 Registre su producto para recibir lo siguiente: * Detalles de nuevas tendencias - Vistazo a lo nuevo * Encuestas - alec su voz entre su comunidad * Códigos de ofertas y descuentos exclusivos * Fácil y rápido servicio de partes de remplace Para registrar su producto, visite systembuild.com Clasificasión de 5 estrellas Visite el sitio web de su tienda local, califique su comprado...
  • Page 34 Français Couverture Avant CE LIVRET D'INSTRUCTION CONTIENT DES INFORMATIONS IMPORTANTES SUR LA SÉCURITÉ. VEUILLEZ LIRE ET GARDER POUR UNE RÉFÉRENCE FUTURE Ne retournez pas ce produit! Contactez notre équipe de service à la clientèle amicale d'abord pour obtenir de l'aide. Appelez-nous: 1-866-452-4081 (sans frais) du Lundi au Vendredi de 9h à...
  • Page 35 Français Page 13 Attachez les panneaux arrière comme indiqué en cliquant directement dans les bords bruts. Assurez-vous que le meuble està égallté. La disancee de coin doit être égale comme montré. IMPORTANT: Le panneau arrière est une partie structurelle de cet appreil et doit être installé correctement.
  • Page 36 Français Page 16 Enregistrez votre produit pour recevoir les éléments suivantes: * Détails sur les nouvelles tendances - un aperçu sur les nouveautés * Sondages - avoir une voix au sein de notre communauté * Offres exclusives et codes promo * Service de pièces de rechange rapide et facile Pour enregistrer votre produit, visitez systembuild.com 5 Étoiles...
