R u g g e d T a b l e t C o m p u t e r
R T C - 7 0 0 R
TF-RTC-700R-TA-WBGH-1110
NVIDIA® TEGRA™ 2 1.0
GHz Dual Core Processor
Rugged Tablet Computer
7" WXGA TFT LCD Display
1Mini HDMI, 1Mini USB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RTC-700R and is the answer not in the manual?

Questions and answers

Related Manuals for Aaeon RTC-700R

Summary of Contents for Aaeon RTC-700R

  • Page 1 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R TF-RTC-700R-TA-WBGH-1110 NVIDIA® TEGRA™ 2 1.0 GHz Dual Core Processor Rugged Tablet Computer 7”...
  • Page 2 AAEON assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. AAEON reserves the right to make changes in the product design without notice to its users.
  • Page 3 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R Acknowledgments All other products’ name or trademarks are properties of their respective owners. •...

  • Page 4: Packing List

    R T C - 7 0 0 R Packing List Before you begin operating your tablet computer, please make sure that the following materials are enclosed: • RTC-700R Rugged Tablet with Android™ • AC Adapter with Power Cord • DVD-ROM for USB driver & manual...
  • Page 5 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R Options The following items are normally optional, but some vendors may include them in the standard package. Some items may not be available in some countries, or some vendors may choose not to carry all the times.
  • Page 6 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R Safety & Maintenance You can use your Rugged Tablet Computer under a wide range of environmental conditions.
  • Page 7 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R ampere ratings of all the devices sharing the extension do not exceed the rating of the extension cord or the rating of the wall outlet.
  • Page 8 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R This device complies with Part 15 FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that...

  • Page 9: Table Of Contents

    R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R Contents Chapter 1 Settings 1.1 Introduction..............1-2 1.2 Features................1-3 1.3 Android™ ...............1-4 1.4 Quick Start ..............1-5 1.5 Touch Panel Control............1-6 1.6 Settings ................1-7 Chapter 2 Applications...
  • Page 10 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R A.4 Safety Caution ..............A-6 A.5 Battery Disposal ............A-7 A.6 Battery Caution ............A-9 A.7 Adapter Caution............A-10...

  • Page 11: Chapter 1 Settings

    R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R Chapter Settings 1- 11 Chapter 1 Introduction...

  • Page 12: Introduction

    R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 1.1 Introduction This Rugged Tablet Computer (RTC) is a fully functional PC with built-in wireless connectivity, Bluetooth®...

  • Page 13: Features

    R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 1.2 Features Included Software Google Android™ v3.2 which includes: • Google Text •...

  • Page 14: Android

    R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 1.3 Android™ About Android™ Android™ for Developers offers an online orientation for Android ™...

  • Page 15: Quick Start

    The input voltage range between the wall outlet and this adapter is AC 100V–240V, and the output voltage of this adapter is DC 12V, 2A. When using the RTC-700R for the first time, fully charge the battery for up to 8 hours to prolong battery life and whenever the battery power is depleted.

  • Page 16: Touch Panel Control

    R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 1.5 Touch Panel Control Single taps Single taps on the touch panel screen lets the user select a certain item or activate an application.

  • Page 17: Settings

    R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 1.6 Settings The settings screen allows you to configure some settings of your RTC-700R, which includes: Wireless & Network...
  • Page 18 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 1. Wireless & Network Select Wireless & networks for Wi-Fi settings, Bluetooth® settings, VPN settings and Mobile network settings.
  • Page 19 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R Select the name of your network. Type in your password. 1- 19 Chapter 1 Introduction...
  • Page 20 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R The system will confirm that you are connected to the internet. 1- 20 Chapter 1 Introduction...
  • Page 21 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 2. 3G For 3G functions, insert the SIM card and type in your PIN Number. 1- 21 Chapter 1 Introduction...
  • Page 22 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R The RTC-700R will confirm the 3G connection. 1- 22 Chapter 1 Introduction...
  • Page 23 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 3. Sound Select Sound to configure volume settings for audio broadcasts. 1- 23 Chapter 1 Introduction...
  • Page 24 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 4. Screen Select Screen to adjust the brightness of the RTC-700R. 1- 24 Chapter 1 Introduction...
  • Page 25 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 5. Location & Security Select Location & Security to secure this tablet computer. This can also be used to determine positioning for Google Maps and other GPS related functions.
  • Page 26 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 6. Applications Select Applications to manage applications, observe services, storage use and battery use, as well as to locate options in terms of application development.
  • Page 27 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 7. Account & Sync Select Accounts & sync to decide which applications to receive and sync data.

  • Page 28: Chapter 1 Introduction

    R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 8. Privacy Select Privacy to back up important files. 1- 28 Chapter 1 Introduction...
  • Page 29 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 9. Storage Select Storage to view how much storage space is filled up, and to view the available storage space.
  • Page 30 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 10. Language & Input Select Language & input to choose the correct language. 1- 30 Chapter 1 Introduction...
  • Page 31 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 11. Date & time Select Date & time appropriate for your time zone. 1- 31 Chapter 1 Introduction...
  • Page 32 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R The system will confirm the date. 1- 32 Chapter 1 Introduction...

  • Page 33: Chapter 2 Applications

    R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R Chapter Applications 2-33 Chapter 2 Getting Started...

  • Page 34: Hardware And Software

    R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R Hardware and Software This chapter introduces the different components and controls of your RTC, including the hardware components, the software, and the audio and video systems.

  • Page 35: Appearance

    R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 2.1 Appearance Front View 1.2M Pixel Camera Top View Power Button 2 - 3 Chapter 2 Getting Started...

  • Page 36: Right And Bottom View

    R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R Right and Bottom View Rear View 2 - 4 Chapter 2 Getting Started...
  • Page 37 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R Inserting the Micro-SD Card Hold the micro-SD card by its edges with the edge-connector side towards the slot.

  • Page 38: Configurations

    R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 2.2 Configurations Click the tabs on the left to switch screens and access the related configurations.
  • Page 39 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R Unlocking the RTC-700R To unlock this tablet, tap and drag the lock out of the circle...
  • Page 40 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 2 - 8 Chapter 2 Getting Started...

  • Page 41: Applications

    R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 2.3 Applications File Manager allows the user to locate and manage data on the internal storage device or connected external storage devices easily.
  • Page 42 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 3. The internal storage location (mnt/sdcard/) is displayed. 2 - 10 Chapter 2 Getting Started...
  • Page 43 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R To access the external storage device through File Manager: 1. Select the Apps menu on the upper right hand corner. 2.
  • Page 44 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 5. Locate and tap Removable. 6. All connected external storage devices are displayed. 7.
  • Page 45 After setting up your account, you can log into the market at your discretion. 1. Select Market on desktop. 2. Add an account to the RTC-700R to continue. Select Yes to continue. 3. Enter email and password to sign in. Select “Create account” if you do not have a Google account.
  • Page 46 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 2 - 14 Chapter 2 Getting Started...
  • Page 47 R T C - 7 0 0 R Select Music on desktop to play desired music files. This application automatically displays and stores audio files in the RTC-700R and connected external storage devices. You can shuffle audio files, or select the desired album for music enjoyment.
  • Page 48 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R Select Gallery on the RTC-700R desktop to browse images or video files. This application automatically displays image and video files stored in the RTC-700R.
  • Page 49 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 2 - 17 Chapter 2 Getting Started...
  • Page 50 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R Sharing and deleting albums Select desired album in the gallery and hold until the tool bar on the top appears.
  • Page 51 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R Sharing, deleting and editing images Select desired images in the gallery and use the tool bar on the top right hand corner to share, delete or edit the selected image.
  • Page 52 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R Select Camera on the Apps menu to take photos or record videos. You can use either the front or back camera.
  • Page 53 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R Email allows you to add several email accounts, browse and manage emails. To set up an email account: 2 - 21 Chapter 2 Getting Started...
  • Page 54 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 1. Select Email and enter your email address and password. Tap Next. 2. The RTC-700R automatically checks for outgoing mail server settings. 2 - 22 Chapter 2 Getting Started...
  • Page 55 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 3. Tap Next to configure Account options. 4. Name the account and enter the name you would like displayed on outgoing messages.
  • Page 56 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R To add Email accounts: 1. Tap Email and login 2. Tap Account settings button on the top right hand corner. 3.
  • Page 57 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R Gmail (Google Mail) allows you to access your Gmail account, receive and compose emails. To set up a Gmail account: 1.
  • Page 58 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 2. The RTC-700R communicates with the Google server to set up your account.
  • Page 59 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R Google Places Google Places offer information about nearby attractions, such as restaurants, coffee shops, gas stations, etc. 2 - 27 Chapter 2 Getting Started...

  • Page 60: Google Maps

    R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R Google Maps Google Maps helps you locate where you are. Use the tool bar on the top to get directions or to create customized maps.
  • Page 61 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R Documents Polaris® Office is office software that supports Document, Spreadsheet and Presentation. To start using Polaris®...
  • Page 62 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 3. The Polaris® Office control panel is displayed. 4. Tap My Folders and select SD card. 5.
  • Page 63 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 2 - 31 Chapter 2 Getting Started...
  • Page 64 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R Recent Files Tap Recent Files on the top right hand corner to access recently edited files.
  • Page 65 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R Adding Accounts You can edit files with Polaris® Office from other accounts, including Google documents and Box.net.
  • Page 66 MyNet plays audio and video files, as well as viewing image files and from another PC, DLNA TV or DLNA speakers. You can play music, watch videos or view photos in the RTC-700R on your PC and vice versa. 1. Ensure that the RTC-700R and secondary PC are connected to the same wireless access point (AP).
  • Page 67 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 2. Click and enable Allow remote control of my Player and automatic devices to play media in the Media Player on the 3.
  • Page 68 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 2 - 36 Chapter 2 Getting Started...

  • Page 69: Chapter 3 Connectors

    R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R Chapter Connectors 3-37 Chapter 3 Making Connections...
  • Page 70 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R Making connections Your RTC is equipped with a full array of ports and connectors, including standard input/output (I/O) ports for quickly and easily adding peripheral devices such as printers, keyboards, etc.

  • Page 71: Right Side Connectors

    R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 3.1 Right Side Connectors Mini HDMI Mini USB DC-in 1. Mini HDMI Connect to a HDMI device via mini HDMI cable.

  • Page 72: Top Side Connectors

    R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 3.2 Top Side Connectors SIM Card Slot Earphone Power Button Micro-SD Card Slot 3-40 Chapter 3 Making Connections...
  • Page 73 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 1. Earphone The built-in microphone can be used for audio recordings, voice narrations or video conferencing.
  • Page 74 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R Chapter 4 - 42 Chapter 4 Power Management...

  • Page 75: Chapter 4 Frequently Asked Questions

    R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 4.1 Frequently Asked Questions (FAQ) 1. What is the default storage path to download software? Select “File Manager”.
  • Page 76 7. How can I do a screen shot? Select Settings-> Screen-> Select Screenshot. Press soft key: Display the recent apps-> The RTC-700R will state: Screenshot is saved. Stay in screenshot mode? -> Select "yes." The photos are stored on the "File Manager" path: /sdcard/Screenshots.
  • Page 77 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 8. How do I uninstall applications? Select Settings-> Applications-> Manage applications-> Downloaded-> Select the applications that you would like to uninstall->...
  • Page 78 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R 13. How do I start GPS services? Select Settings-> Location & security-> Use GPS Satellites.
  • Page 79 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R Appendix Statements Appendix A Statements A-...

  • Page 80: A.1 Statements

    R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R A.1 Statements Declarations and Safety Statements Federal Communications Commission Statement This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 81 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R Reorient or relocate the receiving antenna. Increase the separation between equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
  • Page 82 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R RF Exposure Information (SAR) This device meets the government’s requirements for exposure to radio waves.

  • Page 83: Canadian Notice

    R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R A.2 Canadian Notice IC Regulations This device complies with Industry Canada license-exempt RSS standard(s).
  • Page 84 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R marketed in the U.S. and Canada. For products available in the U.S./Canada markets, only channels 1-11 can be operated.

  • Page 85: Ce Mark Notice

    R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R A.3 CE Mark Notice CE marking for devices without wireless LAN/Bluetooth® The shipped version of this device complies with the requirements of the EEC directives 2004/108/EC “Electromagnetic compatability”...

  • Page 86: A.4 Safety Caution

    R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R A.4 Safety Caution Important Safety Instructions Power Safety Requirement Products with electrical current ratings up to 2A and weighs more than 1 Kg must use approved power cords greater than or equal to: VCTF, 3G or 0.75mm2.

  • Page 87: A.5 Battery Disposal

    R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R A.5 Battery Disposal Regulatory information / Disclaimers Installation and use of this Wireless LAN device must be in strict accordance with the instructions included in the user documentation provided with the product.
  • Page 88 R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R to correct any interference caused by such unauthorized modification, substitution or attachment. Manufacturer and its authorized resellers or distributors will assume no liability for any damage or violation of government regulations arising from failing to comply with these guidelines.

  • Page 89: A.6 Battery Caution

    R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R A.6 Battery Caution There is a danger of explosion if the battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer.

  • Page 90: A.7 Adapter Caution

    R u g g e d T a b l e t C o m p u t e r R T C - 7 0 0 R A.7 Adapter Caution This RTC is for use with model NO. LTE24E-S2-2. 4 - 58 Chapter 4 Power Management...
