Page 1: Quick Installation Guide
Wireless Broadband Router UltraSkyM18P1 Quick Installation Guide Connecting the Router Configure Computer Login the Router Run Setup Wizard Wireless connecting for PC 1 / 12 ... -
Page 2: Connecting The Router
1.Connecting the Router 1-1. Power on the router with the correct power adapter 1-2. Connect one end of the standard network cable to the router’s LAN port and the other end to the network adapter of your computer. 1-3. Connect another network cable between ADSL modem and the router’s WAN port. -
Page 3: Login The Router
2-4. Select “Obtain an IP address automatically” and the “Obtain DNS server address automatically” by clicking the radio-button. Click OK . 3.Login the Router Input the website http://192.168.1.1 in Internet explorer address column, User should see the login page, input the user name and password (default user name and password is “admin”),login windows as below: ... -
Page 4: Run Setup Wizard
click “ok” button enter the Setup wizard page 4.Run Setup Wizard Click “Setup Wizard” button and click “Next” show following window: 4 / 12 ... -
Page 5: Operation Mode
4.1 Operation Mode The router support three kinds operation mode: Gateway, Bridge, wireless ISP, system default is “Gateway”. Recommend the Gateway mode for general user. Click “Next” button. 4.2 Time Zone Setting 5 / 12 ... -
Page 6: Lan Interface Setup
You can maintain the system time by synchronizing with a public time server over the Internet. Recommend keep the default settings, Click “Next” button. 4.3 LAN Interface Setup This page is used to configure the parameters for local area network. Here you may change the setting for IP address, subnet mask. - Page 7 This page is used to configure the parameters for Internet network which connects to the WAN port of your router. Here you may change the access method to Static IP, DHCP, PPPoE, PPTP or L2TP by click the item value of WAN Access type.
- Page 8 4.4.2 If your access type is DHCP Client, then you can get the IP address from the ISP. 4.4.3 If your access type is PPPoE, with ADSL virtual dialing, you need to fill in following details: User Name: Fill in ADSL access user name which supply by ISP, if you not sure can check with ISP.
- Page 9 4.4.4 If your access type is PPTP, please take following for reference 4.4.5 If your access type is L2TP, please take following for reference. Click “ Next” button 9 / 12 ...
-
Page 10: Wireless Basic Settings
4.5 Wireless Basic Settings This page is used to configure the wireless parameters. Band: 2.4GHz(B+G+N). Mode: AP. Network Type: Infrastructure. SSID: All-Link (default). Channel Width: 40MHz(default) ControlSideband: Upper(default) Channel Number: 11(default) Recommend keep the default setting, Click “Next” button. 10 / 12 ... -
Page 11: Wireless Security Setup
4.6 Wireless Security Setup Encryption: None(default), you can choose WEP,WPA(TKIP),WPA2(AES),WPA2 MIXED Encryption method. Click Finished to finish the settings. Note: the router must be restart to take changes effect, So if you change some settings from this guide, system can restart router automatically. 5.Wireless setting for PC 5-1. - Page 12 Networks 5-2. click Refresh network list at left up place, it will search the wireless network, select the wireless network you want to connect and click Connect . 12 / 12 ...
