3G-431R 3G HSUPA Wifi Modem/Router
431R/421R/321R/311R/221R/211R
---------------------------------------------------------- Version: 2.0-----------------------------------------------------------
Solwise Ltd
www.solwise.co.uk
深圳市华美信科科技有限公司
HAME TECHNOLOGY CO., LIMITED
3G Router

Quick Start Guide

Quick Start Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the 3G-431R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Solwise 3G-431R

Summary of Contents for Solwise 3G-431R

  • Page 1: Quick Start Guide

    深圳市华美信科科技有限公司 HAME TECHNOLOGY CO., LIMITED Quick Start Guide 3G-431R 3G HSUPA Wifi Modem/Router 3G Router 431R/421R/321R/311R/221R/211R Quick Start Guide ---------------------------------------------------------- Version: 2.0----------------------------------------------------------- Solwise Ltd www.solwise.co.uk...
  • Page 2 深圳市华美信科科技有限公司 HAME TECHNOLOGY CO., LIMITED Quick Start Guide Check Package Contents: 3G Router x1 DC9V 1A Power Adapter x1 3G External Antenna x1 WIFI External Antenna x1 RJ45 Ethernet Cable x1 CD-ROM (User Manual) x1 Quick Start Guide x1 Pedestal x1 System Requirements: The recommended PC configuration for using the Router is as follows:...
  • Page 3 深圳市华美信科科技有限公司 HAME TECHNOLOGY CO., LIMITED Quick Start Guide (Figure 1) Step2: If you access to Internet over 3G network, please insert URIM card into USIM CARD slot (Figure 2). (Figure 2) Step3: If you access to Internet over other network access way, please connect the network connection cable to xDSL/Cable Modem and WAN port (Figure 3).
  • Page 4 深圳市华美信科科技有限公司 HAME TECHNOLOGY CO., LIMITED Quick Start Guide (Figure 4) If operation is correct, PWR LED will light. After about 10 seconds the 3G LED will flash light. And it will take about 20 seconds for Router to complete activation. After activation, WIFI LED will light. Step5: Connect Router to PC or laptop，there are two connection ways for selecting.
  • Page 5 深圳市华美信科科技有限公司 HAME TECHNOLOGY CO., LIMITED Quick Start Guide Configure the network settings Step1: On the desktop, right-click on “My Network Places”, select “Properties”. (Figure 6) (Figure 6) Step2: In the following pop-up window, right-click on “Local Area Connection” and select “Properties”. (Figure 7) (Figure 7) Step3: In the following window, select “Internet Protocol (TCP/IP)”...
  • Page 6 深圳市华美信科科技有限公司 HAME TECHNOLOGY CO., LIMITED Quick Start Guide (Figure 8) Step4: In the following pop-up window, select “Obtain an IP address automatically” and “Obtain DNS server address automatically”. Then click“OK”. (Figure 9) (Figure 9) Step5: If you selected LAN connection. Please double check if the Router is really connected to your computer, when “Local Connection”...
  • Page 7 深圳市华美信科科技有限公司 HAME TECHNOLOGY CO., LIMITED Quick Start Guide as figure 10. 【If you selected WIFI connection, Before step5, please click on “Wireless Network Connection” icon in the lower right of desktop, check the wireless network status and select your wireless network. Then connect to it.】 (Figure 10) Step6: Input order “ping 192.168.0.1”...
  • Page 8 深圳市华美信科科技有限公司 HAME TECHNOLOGY CO., LIMITED Quick Start Guide Configure 3G Router Step1: Open Web browser, input 192.168.0.1 at Address bar, then press “Enter”. (Figure 12) 【Note: If you connect to Internet over TD network, please input 192.168.1.1】 (Figure 12) Step2: In the following pop-up window, both input “admin” at “User name” bar and “Password”...
  • Page 9 深圳市华美信科科技有限公司 HAME TECHNOLOGY CO., LIMITED Quick Start Guide connection ways as follows: ①Static IP Address If your ISP gave you a static IP Address, please select “Static IP Address”, and input information of “WAN IP Address”, “WAN Subnet Mask”, “WAN Router”, “Primary DNS”...
  • Page 10 深圳市华美信科科技有限公司 HAME TECHNOLOGY CO., LIMITED Quick Start Guide (Figure 15) ③PPP over Ethernet If you connect to Internet over ADSL modem, please select “PPP over Ethernet”, and input the information of “PPPoE User Name”, “PPPoE Password” that provided by ADSL ISP , and the other options keep Windows default.
  • Page 11 深圳市华美信科科技有限公司 HAME TECHNOLOGY CO., LIMITED Quick Start Guide (Figure 16) ④3G If you connect to Internet over 3G, you must set “APN” and “Dialed Number” firstly according to the information of local network operators, and keep other options as Windows default. (Figure 17)
  • Page 12 深圳市华美信科科技有限公司 HAME TECHNOLOGY CO., LIMITED Quick Start Guide (Figure 17) Step4: After selected the internet connection way, click “WLAN setting” and go ahead the wireless configuration ①Set SSID Default SSID of the Router is “****”, channel is 6. You can modify SSID to make sure the unique name which can identify your wireless network.
  • Page 13 深圳市华美信科科技有限公司 HAME TECHNOLOGY CO., LIMITED Quick Start Guide (Figure 18) ②Set password To set password of wireless network, you can select WEP as Encryption mode, and select the corresponding “WEP Encryption”, 64bit or 128bit. And select “Default KEY ID” and the type of “WEP KEY” corresponding to KEY ID bar, then input password to “Save Settings”.
  • Page 14 深圳市华美信科科技有限公司 HAME TECHNOLOGY CO., LIMITED Quick Start Guide ③After settings finished, go into “System Tools”, select “Reboot the System”, then select “Yes” and “Save Settings”. (Figure 20) so far, the settings of Router is basically complete.( Remark: Press the “Reset” button in the back of Router more than 5 seconds, the settings will be reset to factory default.) (Figure 20) Note: The manufacturer reserves the right to modify above-mentioned information...
