4.7.4 Operation Condition Parameters

This section of Configuration Page allows users to setup:
Input Reading Scale & Offset
Reading configuration: Gate time, Debounce time, Reading Format, Number of Digit
and Decimal Point.
Counting Mode: Direction and A-B Channel combined modes.
Figure 4.18 Example of Operation Condition Parameters Section
Failure of proper configuration will result in misled measurement data or no data
displayed.
A Scale 1.00000000E-00
0
A Offset
A Gate Time (mS)
A Debounce Time (mS)
B Scale 1.00000000E-00
0
B Offset
B Gate Time (mS)
B Debounce Time (mS)
Reading Format
Number of Digits
Decimal Point
A-B Mode +
Counter Mode
0
0
1000
0
Decimal
9
0
Count UP
Save
