4.7.1.5 A-B T Mode

This mode has almost the same setup procedure and operation as A-B F mode required.
However Dual input channels will be totalized and additional A-B T combined input
calculated values would change significantly except if A-B Mode pull-down Menu is
selected with " / " option (division calculation) as observed from the example in Figure
4.13 as A/B value always remained value of 3 PCB's while the others are changing
rapidly.
Users must access Configuration Page for setting this device operate under this mode,
first select option A-B T Mode from Device Type Selection (Operation Mode) Pull-Down
Menu then choose your type of Calculation:
+ : addition will calculate the sum of A+B
- : subtraction will calculate the difference of A-B
x : multiplication will calculate the product of A.B
/ : division will calculate the ratio of A/B.
From A-B Mode (Calculation Type) Pull-down submenu.
For A-B T Mode ID, observe Message Item Window and notice items following:
a= A-B T Mode
b= combined (calculated results of A&B) input reading value.
c=CH A input count value is totalizing until users manually reset
d=CH B input count value is totalizing until users manually reset
j= not applied ( previous Number of Batch Mode Measurement)
k= not applied ( previous Number of Batch Mode Measurement)
Make certain that Debounce Time must be zero when operating with
frequency signals.
30
