Milestone pro MP-SC-5T User Manual

Compact scaler switcher
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
MP-SC-5T
Compact Scaler Switcher
All Rights Reserved
Version: MP-SC-5T_2016V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MP-SC-5T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Milestone pro MP-SC-5T

Summary of Contents for Milestone pro MP-SC-5T

  • Page 1 User Manual MP-SC-5T Compact Scaler Switcher All Rights Reserved Version: MP-SC-5T_2016V1.0...

  • Page 2: Safety Precautions

    Compact Scaler Switcher (with PoC) SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference.  Unpack the equipment carefully and save the original box and packing material for possible future shipment ...
  • Page 3 The item PoC is short for Power over Cable, and when the power adapter is connecting with HDMI Twisted Pair PoC Receiver, MP-SC-5T can’t be energized through PoC. The receiver works with MP-SC-5T can only be HDMI Twisted Pair PoC Receiver. The item “far-end” means the device (e.g. display device, 3 party RS232 device etc) connected with HDMI Twisted Pair PoC Receiver.

  • Page 4: Table Of Contents

    4.4.1 Installation/uninstallation of RS232 Control Software ......15 4.4.2 Basic Settings ..................15 4.4.3 RS232 Communication Commands ............16 4.4.4 Control MP-SC-5T or 3rd Party Device from Local ........ 24 4.4.5 Control MP-SC-5T from Local or Remote ..........25 4.5 Operations in OSD Menu................. 25...
  • Page 5 Compact Scaler Switcher (with PoC) 4.5.1 Option ....................26 4.5.2 Picture ....................27 4.5.3 Sound ....................27 4.5.4 Setup ..................... 28 4.6 Instructions of VGA Converting Cable ............. 29 5. Specification ......................30 6. Panel Drawing ......................32 7. Troubleshooting & Maintenance ................32 8.

  • Page 6: Introduction

    1. Introduction 1.1 Introduction to MP-SC-5T MP-SC-5T is a compact mini scaler switcher with 5 video inputs (3 HDMI, 2 VGA) and 6 audio inputs (3 HDMI audio & 2 VGA audio: switched following the video; 1 MIC audio input). As the VGA input supports VGA, YPbPr and C-video, so the scaler switcher is compliant with multiple video signals.

  • Page 7: Product Appearance

    VOL + FW UPDATE MENU SOURCE / AUTO ENTER MIC - MP-SC-5T ① Power indicator Illuminate red when power on, turn green in standby mode. ② LCD screen Show real-time system working status ③ SOURCE/AUTO  Used as video source selection button, press to select one source, press again to select next source, switching circularly between HDMI1, HDMI2, HDMI3, VGA1 and VGA2.
  • Page 8 Compact Scaler Switcher (with PoC) ④ ENTER Confirm selection in menu. ⑤ RESO/AUTO  Manual-switching mode: Press this button to select the resolution of HDMI local output & HDBaseT output manually. The resolution can be selected among 1920x1200, 1920x1080, 1600x1200, 1360x768, 1280x800, 1280x720, 1024x768.

  • Page 9: Rear Panel

    Audio output port, the audio comes from the input audio corresponding to the selected video source and mixed with MIC audio. ③ IR OUT 5 in total, connect with IR emitters to control local source devices or MP-SC-5T from remote, switched along with corresponding video source. ④ IR IN Connects with IR receiver (with carrier wave only), to receive IR signal send by the IR remote or remote controller of other input/output device.

  • Page 10: System Connection

    Compact Scaler Switcher (with PoC) ⑨ VIDEO INPUT Video input ports, include 3 HDMI inputs & 2 VGA inputs. VGA ports support YPbPr, C-video and VGA format. Factory default is VGA format. ⑩ OUTPUT a) HDMI local output b) HDBaseT output, support PoC. HDBaseT output boasts green and yellow indicator The green indicator will blink when power.

  • Page 11: Connection Procedure

    The audio of HDMI can be embedded or external by sending the right command. Step3. Connect a HDMI display device to HDMI output port of MP-SC-5T with HDMI cable. Step4. Connect HDMI Twisted Pair PoC Receiver to HDBaseT output port of MP-SC-5T with twisted pair.
  • Page 12 Compact Scaler Switcher (with PoC) used for condenser microphone. Connect the microphone in this way: “+” connects to positive, “-” connects to negative and “ ” to ground.  MIC input MIC input has a low frequency characteristics, and wide frequency response. When switch to “MIC”, the microphone input is used for connecting with dynamic microphone.
  • Page 13 Compact Scaler Switcher (with PoC)  LINE input LINE input has a low frequency characteristics, and wide frequency response. When switch to “LINE”, the microphone input is used for connecting with line audio or wireless microphone output. There are two different connection methods: 1) Unbalanced connection: “+”...

  • Page 14: Application

    RESO/AUTO button for 7 seconds or more to switch between auto-adjusting/ manual-adjusting mode. Note: 1. In auto-adjusting mode, MP-SC-5T will choose the resolution of the display device at the far-end as the preferred resolution. If you need to choose the resolution of local HDMI display device: ...

  • Page 15: Volume Adjusting

     Connect INPUT 3 with a source device, and then it will choose INPUT 3 to output.  Remove the signal of INPUT 3, MP-SC-5T will detect from INPUT 1 to INPUT 5. And when it detects that input 2 is available, it will choose INPUT 2 to output.

  • Page 16: Used In Osd Menu

    The “MERGE_51T.bin” file is provided/ authorized by our engineering department. 2) Plug the USB flash disk to the MP-SC-5T USB port on its front panel. 3) Press the button “MENU” for 7 seconds or more to update the software automatically.

  • Page 17: Operations Of Ir

    4.2.1 IR Remote As IR signal can be transmitted bi-directionally between MP-SC-5T and HDMI Twisted Pair PoC Receiver, it is able to use the IR remote at the far-end to control MP-SC-5T or HDMI source devices (via CEC function buttons).

  • Page 18: Ir Operations

    The 5 IR OUT ports correspond to the 5 video inputs separately, and the IR signals are switched following the corresponding video source. 1) Control far-end device from local Control MP-SC-5T or far-end display device from local through corresponding IR remote. 2) Control local device from remote...

  • Page 19: Operations Of Cec Function

    Compact Scaler Switcher (with PoC) 4.3 Operations of CEC Function MP-SC-5T supports CEC, it can be turned on/ off by sending RS232 commands or OSD menu operations. The default setting is ON. Commands pertaining to CEC: “50686%” (enable CEC) and “50687%” (disable CEC)

  • Page 20: Operations Of Rs232 Control

    Pair PoC Receiver, so it is able to control a third party RS232 device from local or control MP-SC-5T from remote. When to control a third party RS232 device, the baud rate of this device should be 2400, 4800, 9600, 19200, 38400, 57600 or 115200.

  • Page 21: Rs232 Communication Commands

    Compact Scaler Switcher (with PoC) Parameter Configuration area Monitoring area, indicates if the command sent works. Command Sending area Please set the parameters of COM number, bound rate, data bit, stop bit and the parity bit correctly, and then you are able to send command in Command Sending Area. 4.4.3 RS232 Communication Commands Communication protocol: RS232 Communication Protocol Baud rate: 9600...
  • Page 22 Compact Scaler Switcher (with PoC) Command Function Feedback Example 50682% Select AV 1 for INPUT 4 Input 4 Set & Switch to AV 1 50683% Select VGA 2 for INPUT 5 Input 5 Set & Switch to VGA 2 50684% Select YPbPr 2 for INPUT 5 Input 5 Set &...
  • Page 23 Compact Scaler Switcher (with PoC) Command Function Feedback Example Choose external audio as HDMI 2 HDMI 2 Audio from LINE 50709% audio input Choose embedded audio as HDMI 3 50710% HDMI 3 Audio from Embedded audio input Choose external audio as HDMI 3 50711% HDMI 3 Audio from LINE audio input...
  • Page 24 Compact Scaler Switcher (with PoC) Command Function Feedback Example 505xx% Set the sharpness to xx. Sharpness: xx (xx=00~99) Color Temperature: xx Adjust the color temperature (xx= Cool/ Medium/ Warm/ 50607% User.) Aspect Ratio: xx (xx= 16:9/ 4:3/ auto/ panorama/ justscan/ 50608% Set the aspect ratio zoom1/ zoom2, when the input...
  • Page 25 Compact Scaler Switcher (with PoC) Command Function Feedback Example 50699% Check the system version Version Vx.x.x 50688% Enable MIC noise detecting MIC detect: enable 50689% Disable MIC noise detecting MIC detect: disable 50690% Check MIC noise detecting statue MIC detect: XXXX 50791% HDCP Active HDCP Active...
  • Page 26 Compact Scaler Switcher (with PoC) Command Function Feedback Example 50609% OK for OSD selection Key: ok 50610% LEFT button Key: left 50611% RIGHT button Key: right 50612% UP button Key: up 50613% DOWN button Key: down MENU button (enter OSD) OSD: Enter 50616% 50618%...
  • Page 27 Compact Scaler Switcher (with PoC) Command Function Feedback Example (xx= Cool/ Medium/ Warm/ User.) Check Volume Icon display status Volume Icon: xxxx 50651% Embedded Audio Output: Check Digital audio output status 50652% enable/disable HDMI1 Audio from XXXX port Check the audio input sources for HDMI2 Audio from XXXX port 50712% HDMI 1, 2, 3...
  • Page 28 Compact Scaler Switcher (with PoC) Command Function Feedback Example image width) Stretch upwards from bottom side 50676% Output Height Adjust xx (decrease image height) Stretch downwards from bottom side 50677% Output Height Adjust xx (increase image height) Turn off HDMI output HDMI power off 50730% 50731%...

  • Page 29: Control Mp-Sc-5T Or 3Rd Party Device From Local

    Secondly, send command 50787% (serial control mode 1, factory default) via RS232 communication software. Lastly, send the right command of MP-SC-5T or other remote RS232 device connected in present system. Connect as below: Control MP-SC-5T or 3rd party device from local...

  • Page 30: Control Mp-Sc-5T From Local Or Remote

    4.4.5 Control MP-SC-5T from Local or Remote  Control MP-SC-5T from local Firstly, connect the RS232 port of MP-SC-5T to RS232 port of PC. Secondly, send command 50788% via RS232 communication software. Lastly, send the right command to control MP-SC-5T. Connect as below: Control MP-SC-5T from local ...

  • Page 31: Option

    Compact Scaler Switcher (with PoC) MP-SC-5T provides a powerful OSD operation menu, contains 4 parts: optional settings, image settings, audio settings and system setting etc. Press MENU button on front panel (or MENU button on IR remote/send command 50616%) to enter in OSD menu, so it is able to do some settings through the OSD menu.

  • Page 32: Picture

    HDMI3. Software Update (USB): Insert the USB flash disk with updating file to USB port of MP-SC-5T, to update the software through this menu. 4.5.2 Picture Including Picture Mode, Color Temperature, Aspect Ratio, Noise Reduction, Screen and Color Range.

  • Page 33: Setup

    Compact Scaler Switcher (with PoC) Sound mode: Includes Standard, Music, Movie, Sports and User. Only User mode supports to set treble and bass. Surround Sound: Includes Off, Surround and SRS Trusurround XT. EQ: To adjust the sound balance. 4.5.4 Setup Including OSD Language, Restore Factory Default, Blending, HDMI CEC, OSD Duration and version inquiry OSD Language: Supports 7 languages, including English (default), Chinese etc.

  • Page 34: Instructions Of Vga Converting Cable

    VERSION: Displays software version 4.6 Instructions of VGA Converting Cable As VGA source supports YPbPr and C-video source, MP-SC-5T provides with 2 VGA converting cables to compliant with these signals. When need to select these signals as input source, please switch to channel INPUT 4 (or INPUT 5), and then set the signal type in OSD.

  • Page 35: Specification

    Compact Scaler Switcher (with PoC) setting, press SOURCE/AUTO button on front panel to switch to AV1 or AV2 source. 2. Via RS232 commands Send command 50682% (or 50685%) to switch to YPbPr1 (or YPbPr2) source. 3. Via IR remote & OSD Press MENU button on IR remote to enter in OSD, and then enter in OPTION setting menu: set “INPUT 4 Select”...
  • Page 36 2 = TX, 3 = RX, 5 = Remote RS232 Configuration General Temperature -10 ~ +40℃ Humidity 10% ~ 90% 8W, supply power to MP-SC-5T and HDMI Twisted Pair PoC Receiver separately Power Power DC12V ± 0.5V Supply Consumption 16W, MP-SC-5T supplies power to HDMI...

  • Page 37: Panel Drawing

    Compact Scaler Switcher (with PoC) 6. Panel Drawing RESO / AUTO MIC + SYSTEM MONITOR VOL - VOL + FW UPDATE MP-SC-5T ENTER MIC - CEC Control IR Call Back Auto Switching Smart EDID Management HDBaseT Integrated with PoC MP-SC-5T...
  • Page 38 Compact Scaler Switcher (with PoC) POWER indicator doesn’t Fail connection of power Make sure the power cord work or no respond to any cord. connection is good. operation EDID management does The HDMI cable is broken Change for another HDMI not work normally at the output end.

  • Page 39: After-Sales Service

    Compact Scaler Switcher (with PoC) 8. After-sales Service If there appear some problems when running MP-SC-5T, please check and deal with the problems referring to this user manual. Any transport costs are borne by the users during the warranty. 1) Product Limited Warranty: We warrants that our products will be free from defects in materials and workmanship for three years, which starts from the first day you buy this product (The purchase invoice shall prevail).
