Appendix C – Connectors' Pinout
C.1. RS-232/1PPS
SkyHopper PRO
Housing P/N: 502380-0600Pins P/N: 502381-0000
1
2
3
4
5
6
C.2. Power Cable
Housing P/N: ZER-04V-S, Pins P/N: SZE-002T-P0.3
Figure 8: RS232/1PPS connector (IOIOI) (SkyHopper PRO side)
N/A
RS232 out
N/A
RS232 in
GND
1PPS In
Table 6: RS232/1PPS connector pinout (IOIOI)
Figure 9: Power connector (SkyHopper PRO side)
SkyHopper PRO
1
2
3
4
Table 7: PWR Connector Type and Pin Mapping
Name Description
D9 Pin 2
D9 Pin 3
Description
GND (-VDC)
GND (-VDC )
Vin+ (+VDC)
Vin+ (+VDC)
17
