Summary of Contents for SkyHopper PRO V
- Page 2 Specifications may be subject to change at any time.
- Page 3 Mobilicom hereby grants a non-exclusive, nontransferable worldwide license to the licensee of this software product to use the SkyHopper PRO V Graphical User Interface (GUI), in object code only for the sole and internal purpose of configuring, monitoring and managing Mobilicom’s SkyHopper PRO V.
-
Page 4: Table Of Contents
Abbreviation List Overview 2.1 Network Topologies & Applications 2.1.1 Point-to-Point 2.2 SkyHopper PRO V Main Features 2.3 Packets Supported by the SkyHopper PRO V Network Physical Description 3.1 Front View Connectors 3.2 Unit Cables: Types & Usage Mechanical Specifications Technical Specifications 5.1 Radio &... - Page 5 Figure 9: Web GUI Video Screen of the Encoder Figure 10: Web GUI Video Screen of the Decoder Figure 11: RS232 / 1PPS Connector (IOIOI) (SkyHopper PRO V Side) Figure 12: Power Connector (SkyHopper PRO V Side) Figure 13: Web GUI Advanced Configuration...
-
Page 6: Abbreviation List
Power ratio in decibels of the measured power referenced to one mill watt Cyclic Delay Diversity Controller Unit A SkyHopper PRO V Unit, in PTP setup, which acts as an endpoint communication unit. Typically a Ground Unit. Convolutional Turbo Code... -
Page 7: Table 1: Abbreviation List
Point-To-Multipoint Quadrature Amplitude Modulation QPSK Quadrature Phase Shift Keying (modulation) A SkyHopper PRO V unit, in PTP setup, which acts as an endpoint communication unit that distributes clocks Remote Unit in the system. Typically the Aerial Unit. Radio Frequency Root Mean Square (Average) -
Page 8: Overview
(receivers). An additional benefit of your SkyHopper PRO V is that it offers Control, Telemetry and Payload all in one RF channel. No need for separate solutions for each, no need for excess items to weigh down your drone. -
Page 9: Skyhopper Pro V Main Features
2.2. SkyHopper PRO V Main Features SkyHopper PRO V offers the following features to take your drone to new levels: SkyHopper PRO V is equipped with two camera inputs, allowing for the simultaneous connectivity of two separate cameras simultaneously ... -
Page 10: Physical Description
Power: ZE - ZER-04V-S Power connectors utilizing 7-14.5VDC CAUTION: When SkyHopper PRO V is carried by a person, environment temperature should not exceed 45°C (113°F) NOTE – Information about the connectors’ pin assignments are available in Appendix C – Connectors Pinout LED: SkyHopper PRO V’s LEDs indicate power on, data transmission and link status. -
Page 11: Mechanical Specifications
FCC, CE or TELEC limits and/or in a country that does not comply with FCC, CE or TELEC regulations. Please note that SkyHopper specifications vary based on FCC, CE and TELEC regulations. -
Page 12: Power Specifications
5.4. Embedded GPS Characteristics SkyHopper PRO V has a built-in GPS receiver. In a PTP network configuration it is used for location information only (which can be operated by the customer via the SkyHopper API). In a Multi-Unit network, it is used for synchronization and can also be used by the customer for location purposes. -
Page 13: Tdma
7. Point-to-Point (PTP) A PTP network is a radio link between 2 SkyHopper PRO V units. The configuration (frequency and profile) of both units must be the same with only one difference - one unit is configured as a Remote Unit while the other unit is configured as a Controller Unit. -
Page 14: Ptp Link Step-By-Step Configuration
7.1. PTP Link Step-by-Step Configuration In order to build a PTP link, two SkyHopper PRO V units are required. One unit acts as a remote unit, while the other as a controller unit. 1. Connect antennas to RF1 and RF2 connectors, and power up the unit. -
Page 15: Skyhopper Pro V Led Indicator
Slow Blink – Error (synced to ACTV LED) Fast Blink – Tx & Rx Air Traffic active Should there be an error in your SkyHopper PRO V unit, both the ACTV and DATA LEDs will be simultaneously slow blinking. Link status, CINR, RSSI, throughput and unit log information is available in the Web GUI, which can be found online at www.skyhopper.biz/skyhopper-pro-v#support. -
Page 16: Video Information
HDMI Digital Analog The HDMI camera connects to the HDMI input port of SkyHopper PRO V; the analog camera connects to the supplied RCA cable, which then connects to the analog port; and the IP camera connects to Ethernet port. -
Page 17: Figure 8: Web Gui Video Information Screen
Figure 8: Web GUI “Video Information” screen NOTE – This screen will be functional only when a SkyHopper PRO V unit will be set as a “Remote” unit. This is due to the fact that a camera may not be connected directly to the decoder because a video stream from said camera must first be encoded, and only then may it be decoded on the other side. -
Page 18: Video Encoder
NAT address. Please pay attention that this should be an IP address of the user’s laptop / PC that is connected to the “Controller” SkyHopper PRO V unit. In this case, the user will not need to set a proper port in the “Port” field, because the video streaming will be directed to his laptop / PC. -
Page 19: Table 6: Video Stream Connection Options
User Manual The user must keep in mind that there are several options to set video streams that depend on which and how many cameras are connected. NOTE – When speaking about a video stream, we mean the video we are getting from camera. In our case, if the recording of the video stream will be defined the same as video stream (HDMI or analog camera), we’ll be using only one video stream, and one mux. - Page 20 User Manual The “Audio” trigger enables / disables the audio stream that would be embedded within the video stream. Audio capabilities are currently disabled, but will be enabled in the near future. The “Record” trigger enables the recording of a stream over the SD card (if present). The user can select the FPS number and quality (if it is supported in that resolution combined with the analog stream as described in Table 6).
-
Page 21: Video Decoder
Please note that this should be an IP address of the user’s laptop / PC that is connected to the “Controller” SkyHopper PRO V unit. In this case, the user will not need to enter a proper port in the “Port” field, because the video streaming will be directed to his laptop / PC. -
Page 22: Installation & Setup
Cables should be chosen according to their attenuation (lower attenuation gives better results) and flexibility (according to the path they pass through). Each cable should have an MMCX Male connector on the SkyHopper PRO V end, and a connector matching the antenna’s connector on the other. -
Page 23: Appendix A - Specifications
User Manual Appendix A - Specifications Encoder / Decoder Options Video Encoder/Decoder H.264 very low latency HD/SD Video Formats up to: 1920x1080p Video Inputs / Outputs Micro HDMI (Input/Output) Analog (Input) Audio Inputs / Outputs Embedded Audio over HDMI, Analog Dual Encoder / Decoder Simultaneous HD / SD Streams Radio and Modem... - Page 24 User Manual Synchronization 1PPS sync input Encryption AES-128 bit Environmental Temperature Range Operating Storage -10°C to 40°C -50°C to 85°C Humidity 5 to 95% Interfaces Data Ethernet, RS232 Full Ethernet Protocol Transparency IP,TCP,UDP, RTP, HTTP Broadcast, Multicast, Unicast Ethernet, VLAN, VPN Serial Data RS232 Optional...
-
Page 25: Appendix B - Mechanical Drawings
User Manual Appendix B - Mechanical Drawings... -
Page 26: Appendix C - Connector Pinouts
User Manual Appendix C – Connector Pinouts C.1. RS-232/1PPS Figure 11: RS232/1PPS connector (IOIOI) (SkyHopper PRO V side) SkyHopper PRO V Name Description Housing P/N: 502380-0600Pins P/N: 502381-0000 RS232 out D9 Pin 2 RS232 in D9 Pin 3 1PPS In Table 7: RS232/1PPS connector pinout (IOIOI) C.2. -
Page 27: Table 8: Pwr Connector Type & Pin Mapping
User Manual SkyHopper PRO V Description Housing P/N: ZER-04V-S, Pins P/N: SZE-002T-P0.3 GND (-VDC) GND (-VDC ) Vin+ (+VDC) Vin+ (+VDC) Table 8: PWR Connector Type and Pin Mapping... -
Page 28: Appendix D - Setting Up A Pixhawk Based System
RS232 but there is a difference in the voltage levels. D.1. SkyHopper Setup The first stage is to setup the SkyHopper link to enable the UART interface on the link. The configuration should be setup on both units (Remote/Aerial and Controller/Ground). -
Page 29: Uart-To-Ethernet
User Manual D.3. UART-to-Ethernet There is an option to configure the system to work with a UART-to-Ethernet configuration, which eliminates the use of the serial cable on the Ground Unit. Please refer to the UART-to-Ethernet Connection Guide online at www.skyhopper.biz/skyhopper-provsupport. -
Page 30: Appendix E - Troubleshooting
Not connected to power source or 1. Verify power cable properly battery is empty connected to the SkyHopper PRO V PWR connector 2. Verify that the battery or power supply connected SkyHopper PRO V power cable and to a power outlet 3. - Page 31 User Manual Technical Support Inquiries For technical support for SkyHopper PRO V, please contact: Support@skyhopper.biz...
