Summary of Contents for SkyHopper PRO
- Page 1 By Mobilicom By Mobilicom User Manual...
- Page 2 SkyHopper PRO www.skyhopper.biz support@skyhopper.biz Specifications may be subject to change at any time.
- Page 3 Mobilicom hereby grants a non-exclusive, nontransferable worldwide license to the licensee of this software product to use the SkyHopper PRO Graphical User Interface (GUI), in object code only for the sole and internal purpose of configuring, monitoring and managing Mobilicom’s SkyHopper PRO.
-
Page 4: Table Of Contents
Network Topologies and Applications.............................. 7 2.1.1 Point-to-Point (PTP) ................................7 SkyHopper PRO Main Features ..............................7 Packets supported by the SkyHopper PRO network ........................8 PHYSICAL DESCRIPTION .................................. 8 Front View Connectors ..................................8 Unit Cables: Type & Usage ................................8 MECHANICAL SPECIFICATIONS ................................ - Page 5 TABLE 1: ABBREVIATION LIST ................................... 5 TABLE 2: SKYHOPPER PRO MECHANICAL SPECIFICATIONS ........................ 9 TABLE 3: SKYHOPPER PRO POWER SPECIFICATIONS ........................10 TABLE 4: SKYHOPPER PRO ENVIRONMENTAL SPECIFICATIONS ....................... 10 TABLE 5: EMBEDDED GPS CHARACTERISTICS OF SKYHOPPER PRO ....................10...
-
Page 6: Abbreviation List
Cyclic Redundancy Code Decibel Power ratio in decibels of the measured power referenced to one milliwatt Cyclic Delay Diversity A SkyHopper PRO Unit, In PTP setup, which acts as an endpoint communication unit. Typi- Controller Unit cally a Ground Unit. Convolutional Turbo Code... -
Page 7: Table 1: Abbreviation List
Abbreviation List continued A SkyHopper PRO unit, in PTP setup, which acts as an end point communication unit that Remote Unit distributes clocks in the system. Typically the Aerial Unit. Radio Frequency Root Mean Square (Average) RSSI Receiver Signal Strength Indication... -
Page 8: Overview
(receivers). An additional benefi t of your SkyHopper PRO is that it offers Control, Telemetry and Payload all in one RF channel. No need for separate solutions for each, no need for excess items to weigh down your drone. -
Page 9: Packets Supported By The Skyhopper Pro Network
Power: ZE - ZER-04V-S Power connectors utilizing 7-14.5VDC CAUTION – When SkyHopper PRO is carried by a person, environment temperature should not exceed 45°C (113°F) ► NOTE – Information about the connectors’ pin assignments are available in Appendix C – Connectors... -
Page 10: Mechanical Specifications
FCC or CE limits and/or in a country that does not comply with FCC or CE regulations. Please note that SkyHopper specifi cations vary based on FCC or CE regulations. -
Page 11: Power Specifications
5.4. Embedded GPS Characteristics SkyHopper PRO has a built-in GPS receiver. In a PTP network configuration it is used for location information only (which can be operated by the customer via the SkyHopper API). In a Multi-Unit network, it is used for synchronization and can also be used by the customer for location purposes. -
Page 12: Tdma
7.1. PTP Link Step-by-Step Configuration In order to build a PTP link, two SkyHopper PRO units are required. One unit acts as a remote unit, while the other as a controller unit. Connect antennas to RF1 and RF2 connectors, and power up the unit. -
Page 13: Figure 6: Web Gui Main Screen
Set the profi le as required (RF bandwidth, bitrate and ratio) and click on the “Apply” button as shown on Figure 7. The unit will reboot. Repeat stages 1-4 with the 2nd unit. Figure 7: Web GUI “Advanced confi guration” screen ► NOTE – A PTP setup requires 2 SkyHopper PRO units confi gured with same frequency and profi le. -
Page 14: Skyhopper Pro Led Indicator
D) Fast Blink – Tx & Rx Air Traffic active Should there be an error in your SkyHopper PRO unit, both the ACTV and DATA LEDs will be simultaneously slow blinking. Link status, CINR, RSSI, throughput and unit log information is available in the Web GUI, which can be found online at www. -
Page 15: Appendix A - Specifications
Appendix A - Specifications Radio and Modem Frequency 2.4GHz (ISM) 900MHz (ISM) - Optional 5.8GHz (ISM) - Optional Antenna’s Connectors MMCX (X2) TX Power Control 50dB RX Dynamic Range 70dB Sensitivity Max –101dBm Radio Access Method OFDM - TDMA Duplexing Configuration MIMO 2X2 Channel BW... - Page 16 Power DC Voltage (Battery Operated) 7-14.5V DC Power Consumption Up to 12 Watt 8W Average Configuration and Management Unit Monitoring Application Web-Based Application Program Interface API, Code Lib. (Optional) Integrated Options* Video Encoder/Decoder H.264 very low latency HD/SD Video Formats up to: 1920x1080p Video Inputs / Outputs Micro HDMI (Input/Output) Analog (Input)
-
Page 17: Appendix B - Mechanical Drawings
THE USE OF CERTIAN HAZARDOUS SUBSTANCES IN ELECTRONIC EQUIPMENT" (RoHS DIRECTIVE 2002/95/EC). MOBILICOM IS PROHIBITED. 1 CONNECTOR: CAT5, RECEPTACLE NAME SIGNATURE DATE FINISH: TITLE: SKY HOPPER PRO UNIT 2 CONNECTOR: MOLEX, CLICK MATE SERIES, 6 PINS, RECEPTACLE (P/N: 5023860670) DRAWN ILAN B. 1/11/2017 INTERFACE CONTROL APPV'D ILAN B. -
Page 18: Appendix C - Connectors' Pinout
Appendix C – Connectors’ Pinout C.1. RS-232/1PPS Figure 8: RS232/1PPS connector (IOIOI) (SkyHopper PRO side) SkyHopper PRO Name Description Housing P/N: 502380-0600Pins P/N: 502381-0000 RS232 out D9 Pin 2 RS232 in D9 Pin 3 1PPS In Table 6: RS232/1PPS connector pinout (IOIOI) C.2. -
Page 19: Appendix D - Setting Up A Pixhawk Based System
RS232 but there is a difference in the voltage levels. D.1. SkyHopper Setup The fi rst stage is to setup the SkyHopper link to enable the UART interface on the link. The confi guration should be setup on both units (Remote/Aerial and Controller/Ground). -
Page 20: Appendix E -Troubleshooting
Disable the PC firewall Trying to connect to remote unit Verify ETH cable is connected to the PCs ETH when link is down. port and to the SkyHopper PRO MAIN con- nector If needed: replace cables. Ping the unit Try to connect to the local unit and verify link...
