Laser Pegs MLB 002 Instruction Manual

Please read manual before you begin! Failure to
LIMITED
follow this manual's instructions may result in
damage to the Triangle Power base, AC adapter
EDITION
and/or Laser Pegs®. Not adhering to these
For Boys And Girls directions will void the manufacturer's warranty.
Packaging has to be kept since it contains
Ages 5 And Up
important information.
12 Models+
WARNING:
CHOKING HAZARD
Any creation you can build
-
Small parts.
LIGHTED
Not for children under 3 yrs.
Do not submerge in water.
CONSTRUCTION SET INCLUDES:
• 17 Laser Pegs®
• 79 Construction Parts
• Triangle Power Base
• Instruction Manual
Requires 3 AA Batteries
Construction Compatible
Compatible with other construction kits
Batteries NOT
EN71, RoHS COMPLIANT
Included
This product complies to
all safety requirements
MODEL INSTRUCTIONS
All additional model instructions can
be downloaded at www.LaserPegs.com
Laser Peg® Parts List
x1 x2
There Are No LEDs In The 90 Degree Peg
Or Baseball Cap
AV
BASEBALL
CAP
90° PEG
x1 x1 x4
x2
Y PEG
x1
STRAIGHT
T-PEG
STACKABLE
45° PEG
SQUARE
SQUARE
PEG
WHEEL PEG
M-M PEG
BAT PEG
Color Each Laser Peg® is color coded on the circuit board inside
each shape. There is No LED In The 90 Degree Peg.
Code
Laser Pegs ® Stackable
Laser Pegs
® link that
Triangle Power
allows you to connect to
Base
other construction kits.
Construction Parts List
x2
x2 x2 x2
x2
x4 x2
x2
x2
x6
x2
x2
x5
x2
x1
x4
x2
x2
x2
x2
x2 x1
x1
Connecting Pegs
To construct with Laser Pegs®, slide two pieces together to form a
connection. Slide each piece on and off smoothly. The 90° pegs are
essential to construction but they DO NOT ILLUMINATE.
Press button
Power Button
to turn on/off
Push button to cycle
through 3 different
light settings.
AC Adapter
Connection
When Using Batteries
1. Remove screws.
2. Place three AA batteries in the correct
position - as displayed inside the Triangle
Power Base.
of ASTM F 963
3. Push RED button to turn on!
4. Do not mix old and new batteries.
5. Do not mix alkaline, standard (carbon-
zinc), or rechargeable (nickel-cadmium)
batteries!
6. Exhausted batteries are to be removed
from the power base.
7. Never connect more than 200 Laser Pegs®
8. Non-rechargeable batteries are not to be
recharged.
9. Rechargeable batteries are only to be
charged under adult supervision.
10. Rechargeable batteries are to be removed
from the toy before being charged.
11. Batteries are to be inserted with the
x1 correct polarity.
x1
12. The supply terminals are not to be short-
BASEBALL
circuited.
PEG
x1
x1
GLOVE PEG
Using an
x1
AC Adapt
er
Remove all batteries
from Laser Pegs® power
base before using the
5 volt AC adapter.
*To avoid short-circuits, keep metal objects and
other un-authorized materials from obstructing
the peg holes.
The AC adapter and the power base are to be regularly examined for damage
to the cord, plug, enclosure and other parts, and in the event of such damage,
they must not be used until the damage has been repaired.
WARNING! Each Laser Peg® draws current from the batteries. Therefore, the more
pegs you use, the quicker you will deplete your battery power! As the power
weakens, the current will slowly fail and some Laser Pegs® will illuminate (typically
x2
the reds and yellows) and some won't. When the Laser Pegs® dim the Laser Pegs®
are not broken, they just need stronger batteries or an AC Adapter.
You have 3 simple options...
x2
1. Use a 5 volt AC Adapter –available from www.LaserPegs.com
2. Change the batteries.
3. Use high quality batteries. They will last a little longer, but they will still deplete
x2
rapidly the more laser pegs you connect!
www.LaserPegs.com
This manual is copyright and cannot be reproduced or used online without Laser
Pegs®Ventures LLC permission. Copyright 2013 © All Rights Reserved US Patent
x1
#7,731,558 Additional Global & Multiple Patents Pending. Laser Pegs®Ventures
LLC. 8304 Consumer Ct Sarasota FL. 34240. Contact: Support@LaserPegs.com
MLB Series Bat, Baseball, and Glove Pegs
The MLB Series Laser Pegs® kit includes the Bat, Baseball, and Glove Pegs.
These shapes can be used with any other existing Laser Pegs® kit. All three
of the MLB Series Pegs illuminate.
Peg Holes
Add 3-AA Batteries
3-AA Batteries
BASEBALL
PEG
Remove LR-44 Batteries
The LR-44 batteries are only for the
"Try-Me" function, they should be
All MLB Series Laser Pegs® specialty pegs can be used with other existing
removed from the Triangle Power
Laser Pegs® kits.
Base and replaced with 3 - "AA"
batteries before giving it to the
child.
MLB Series Baseball Cap is also included.
When using an AC
Adapter, NEVER
Your MLB Series Laser Pegs® includes the Baseball Cap. This part does NOT
place the adapter
illuminate. It is a construction part that is exclusive to Laser Pegs® and
plug into the Tri-
designed to mate to the socket side of the Wheel Peg.
angle power base
top peg holes.
Never connect more than 200
Laser Pegs® when using a 5 volt
(2000mA) AC Adapter.
The Cap is designed
to fit snuggly onto
the wheel peg.
Affixing MLB Team Logo Stickers
Your MLB Series Laser Pegs® kit comes with a set of licensed MLB team
decal stickers. There is one sticker per team included. These stickers can
be affixed to the front of the Baseball Cap part.
GLOVE PEG
The MLB Series Laser
Pegs® kit Baseball,
Bat, and Glove
Pegs have only one
mating end.
BAT PEG
There will be one (1) sheet of MLB logo stickers included inside each
individual MLB Series Laser Peg® kit. This sheet of stickers will have a logo
representing each Major League team that can be placed on the front of
the Baseball Cap. Before applying stickers, it is advisable to first wipe any
dirt, oil or residue that maybe on the surface of the part due to handling
with a clean dry cloth. This will help ensure proper adhesion to the cap's
surface.
Apply Sticker to
the front of the
Baseball Cap.
Carefully place the
Cap onto the socket
side of a wheel peg
to complete your
player models.
WARNING! Do not ingest stickers or backing sheet. This could be potentially
dangerous and may cause severe injury. So keep away from small children.
