COMMAX NURESCALL SYSTEM J J N N S S - - 4 4 C C M M • Thank you for purchasing COMMAX products. • Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow instructions to use a product exactly.
Page 2
www.safemag.ru CONTENTS 1. System Introduction ........2.
Page 3
www.safemag.ru 1. System Introduction This system was designed to exchange the communication between nurse and patient through data communication system. This system was composed with master station which can control and display whole system and Power controller, and the sub station are connected with 4 common wires. 1 master station is able to cover maximum 32 sub stations and install the presence switch, emergency switch and corridor light.
Page 4
www.safemag.ru 4. Signal and Lamp Specification. Section SOUND Corridor Light Communication Call: XXXX Steady Green Bed Paging Call: XXXX Flashing Green Melody Sound Flashing White Toilet(Room) Emerg: XXXX Flashing Red Emer. Sound Flashing Red Toilet(Corridor) Emerg: XXXX Flashing Red Emer. Sound Steady Red Presence S/W Steady Green...
Page 5
www.safemag.ru 5-2-2. Lift up the handset in Master station for communication. (Corridor Light will be off) 5-2-3. If the master station is on the line, it will automatically flash the green led on the bed for its conversation. If press the call button, it will be reserved with the alarming of red lamp, and then it will be automatically connected after the previous conversation.
Page 6
www.safemag.ru 5-9-2. When receiver answers the phone, you can communicate. 5-9-3. To cancel it, hang off the handset and if receiver cancels it, you can hear the busy tone. 5 5 - - 1 1 0 0 . . I I n n t t e e r r p p h h o o n n e e R R e e c c e e i i v v i i n n g g 5-10-1.
Page 7
www.safemag.ru 6. How to assign the common Number This system is designed for micro process based Data communication, hence setting up identification numbers is required to activate communication function. 6 6 - - 1 1 . . I I n n t t e e r r p p h h o o n n e e - Interphone No.
Page 8
www.safemag.ru operation ex) No.43 unit arailable to receive broadcasting No. 32 + 8 +2+1=No.43 ex) No.90 unit impossible to receive broadcasting No. 64 + 16 +8+2=No.90 - If press “1" button, ADDR>XXXX-XX will blink in the display window, input the number and press the remote-control button.
Page 9
www.safemag.ru 8 8 - - 3 3 . . H H o o w w t t o o c c o o n n n n e e c c t t b b e e t t w w e e e e n n D D S S S S a a n n d d M M a a s s t t e e r r s s t t a a t t i i o o n n As the related drawing No.9-3, insert the plate cable and fix with B.K.T.
Page 10
www.safemag.ru 8 8 - - 7 7 . . I I n n t t e e r r p p h h o o n n e e c c o o n n n n e e c c t t i i o o n n For TP-90AN connection or connection among the systems, the interphone shall be connected with 10 pieces of cable by parallel.
Page 11
www.safemag.ru 9. NURSE CALL System Drawing 9-1. System Diagram www.safemag.ru...
Page 12
www.safemag.ru 9-2. System Wiring Diagram www.safemag.ru...
Page 13
9-3. Parts Name and Connecting Method 9-3-3. How to connect between JNS-4CM and DSS www.safemag.ru...
Page 14
www.safemag.ru 9-4. System Connection Schematic www.safemag.ru...
Page 22
513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea Int’l Business Dept. : Tel.; +82-31-7393-540~550 Fax.; +82-31-745-2133 Web site : www.commax.com Printed In Korea / 2009.11 www.safemag.ru...
