TECshow SATURN User Manual page 14

23 DMX Channel chart
Channel Function
CH1
CH2 PAN Fine
CH3
CH4 Tilt Fine
CH5 Pan/Tilt Speed
CH6 Dimming
CH7 Strobe
CH8 Color wheel
CH9 Gobo wheel
P. 14
Tecshow Saturn | English version
Value
PAN 000-255
000-255
Tilt 000-255
000-255
000-255
000-255
000-015
016-096
097-175
176-255
000-030
031-055
056-080
081-105
106-130
131-155
156-180
181-205
206-230
231-255
000-021
000-034
035-047
048-060
061-073
074-086
087-099
100-112
113-125
126-138
139-151
152-164
165-177
178-190
191-203
204-216
217-229
230-242
243-255
Details
Pan 0-630°
Pan fine
Tilt 0-210°
Tilt fine
Pan/Tilt speed from fast to slow
White LED dimming (0-100%)
Strobe off
Strobe (1HZ-25HZ Slow-Fast)
Strobe (1HZ Slow-Fast)
Random Strobe
open
red
green
blue
yellow
orange
magenta
light green
purple
cyan
open
gobo 1
gobo 2
gobo 3
gobo 4
gobo 5
gobo 6
gobo 7
gobo 8
gobo 9
gobo 1 shaking
gobo 2 shaking
gobo 3 shaking
gobo 4 shaking
gobo 5 shaking
gobo 6 shaking
gobo 7 shaking
gobo 8 shaking
gobo 9 shaking
