13) Display reverse setting
1. Press <MENU> to enter EDIT interface.
2. Press <UP/DOWN> to choose, then press ENTER
to enter Disp
3. Press <UP/DOWN> to choose 'ON'/'OFF'
4. Press <Enter> to confirm, or press <MENU> to
exit.
14) Working time
1. Press ENTER to enter EDIT interface
2. Press <UP/DOWN>, then press ENTER
Fhrs to check the light's working time
3. Press ENTER to confirm, or press <MENU> to exit.
15) Software Version
1. Press ENTER to enter EDIT interface
8. DMX CHANNEL INSTRUCTION

12 DMX Channel chart

Channel Function
CH1
CH2
CH3 Pan/Tilt Speed
CH4 Dimming
CH5
SPL-LED-663S 12 Channel Mode
Value
PAN 000-255
Tilt 000-255
000-255
000-255
000-015
016-096
Strobe
097-175
176-255
2. Press <UP/DOWN>, then press ENTER
Ver to check the light's version information
3.Press ENTER to confirm, or press <MENU> to exit.
16) Whole fixture reset
1. Press <MENU> to enter EDIT interface.
2. Press <UP/DOWN> to choose, then press ENTER
to enter Rest
3. After reset, it will go back to the upper interface
17) Factory default settings
1. Press <MENU> to enter EDIT interface.
2. Press <UP/DOWN> to choose, then press ENTER
to enter Defa
3. Press ENTER to confirm,or press <MENU> to exit.
Details
Pan 0-630°
Tilt 0-210°
Pan/Tilt speed from fast to slow
White LED dimming (0-100%)
Strobe off
Strobe (1HZ-25HZ Slow-Fast)
Strobe (1HZ Slow-Fast)
Random Strobe
P. 11
