TECshow MadBox XL 3-in-1 User Manual page 6

Number Button
1 Standby
2 Show 0
3 Show 1
4 Show 2
5 Show 3
6 Show Fast
7 Show Slow
8 Show Sound
Ringing
1) The applicable temperature for the lighting is between
-25°C to 40°C. Do not use the lighting under or above the
temperature.
2) The installation of the effect has to be built and con-
structed in a way that it can hold 10 times the weight for 1
hour without any harming deformation.
3) The installation must always be secured with a second-
ary safety attachment, e.g. an appropriate safety rope.
Never stand directly below the device when mounting, re-
P. 6
MADBOX XL 3-IN-1
ENGLISH VERSION
Function
Light standby
LED+Laser +Strobe, random show
LED show
Strobe show
Laser show
Show 0-Show3 fast show LED indicator flickers fast
Show 0-Show3 slow show LED indicator flickers slow
Show 0-Show3 controlled by sound LED indicator flickers with sound beat
HANGING BRACKET
moving or servicing the fixture.
4) The operator has to make sure the safety relating and
machine technical installations are approved by an expert
before taking the device into operation for the first time.
5) These installations have to be approved by a skilled
person once a year.
6) M8 screws on the mounting bracket which for fixed be-
tween hanging bracket's 12.5mm hole.
MOUNTING BRACKET
