Menu Instruction

DMX address setting

•
Press MENU when it shows Address, then press
ENTER.
•
Change the DMX address by UP or DOWN.
Function selection
•
Press MENU until it shows Intro, press ENTER.
•
Press UP or DOWN to choose Reset, Run.
• When choosing Reset, press ENTER, and press UP
or DOWN to choose YES or NO. When choosing YES, press
ENTER the equipment reset, restore factory sett
• When choosing Run, press ENTER press UP or
DOWN to choose DMX512 Auto1, Auto2, Auto3, Sound1,
Sound2, Slave. When choosing DMX512 the DMX control-
ler sending the signal(3 pin signal is valid),
• When choosing Auto1 Auto2 Auto3 Sound1 or
Sound2 Auto1, Auto2, Auto3, Sound1, Sound2, choose
Auto or Sound mode,it can be used as the master. When
choosing Slave it is Slave receive the Master signal. Choose
the Slave need to quit to the main menu can be controlled.
P. 8
MINI HIVE 10
ENGLISH VERSION
