It is recommended that for the initial set-up of the winch (prior to applying any load)
that the winch be operated in the WIRED mode
Once the winch has been set-up then the remote hand control can be operated either
in the WIREED or WIRELESS mode
To use the remote hand controller in the WIRELESS mode remove the control cable
from the control box, unplug the remote hand controller from the control cable and
press the MODE button on the remote hand controller until the LED light marked
WIRELESS is illuminated
Step 1:
Remove 4 small Phillips head screws. (Fig A)Note: there location because of the
different lengths.
Step 2:
With care, pull out circuit board with battery housing attached (Fig B)
Remove battery and replace with new one (type 23A)
Step 3:
Carefully reassemble the remote. Make sure the plug and switch are in the correct
placement before tightening screws. (Fig C)
Remote battery replacement
