Fujitsu ASY30UBBJ Service Manual

Fujitsu ASY30UBBJ Service Manual

Split type room air conditioner wa ll m ount ed type refrigerant r410a
Hide thumbs Also See for ASY30UBBJ:

Advertisement

Table of Contents

SPLIT TYPE
ROOM AIR CONDITIONER
WA L L M O U N T E D
Models
Indoor unit
Outdoor unit
ASY30FBBJ
AOY30FNBDL
ASY30UBBJ
AOY30UNBDL
CONTENTS
. . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . .
t y pe
1
2
. . . . . . . . . . .
3
. . . .
4
6
. . . . . . . . . . . . . . .
8
9
. . . . . . . .
18

Advertisement

Table of Contents
loading

Related Manuals for Fujitsu ASY30UBBJ

Summary of Contents for Fujitsu ASY30UBBJ

  • Page 1: Table Of Contents

    Models Indoor unit Outdoor unit ASY30FBBJ AOY30FNBDL ASY30UBBJ AOY30UNBDL CONTENTS SPECIFICATIONS ..... . OUTLINE AND DIMENSIONS ...

  • Page 2: Specifications

    SPECIFICATIONS TYPE Cooling only Cool and Heat INDOOR UNIT ASY30FBBJ ASY30UBBJ OUTDOOR UNIT AOY30FNBDL AOY30UNBDL 7.90 kW 7.90 kW COOLING CAPACITY 8.40 kW HEATING CAPACITY ELECTRICAL ATA 230 V 230 V POWER SOURCE 50 Hz 50 Hz FREQUENCY 13.0 A 13.0 A...

  • Page 3: Outline And Dimensions

    OUTLINE AND DIMENSIONS Unit : mm INDOOR UNIT 1,120 OUTDOOR UNIT 2005.01.17...

  • Page 4: Refrigerant System Diagram

    Distributor Strainer Condenser Evaporater PRESSURE CHECK Charging valve VALVE Refrigerant pipe 3-Way Accumulator Condenser valve 15.88mm(5/8") Models : ASY30UBBJ / AOY30UNBDL OUTDOOR UNIT Cappillary tube Refrigerant pipe INDOOR UNIT 9.52mm(3/8") Strainer 3-Way valve Distributor Compressor Strainer Evaporater Condenser Accumulator...

  • Page 5: Circuit Diagram

    GRAY THERMISTOR GRAY (PIPE TEMP.) BLACK THERMISTOR BLACK (ROOM TEMP.) GREEN/ YELLOW MOTOR GRAY GRAY STEP MOTOR GRAY (RIGHT/ LEFT) GRAY CIRCUIT DIAGRAM PINK Model : ASY30FBBJ / AOY30FNBDL GRAY GRAY GRAY GRAY STEP MOTOR GRAY GRAY (UP/DOWN) GRAY GRAY GRAY GRAY GRAY...
  • Page 6 (PIPE TEMP.) BLACK THERMISTOR BLACK (ROOM TEMP.) GREEN/ YELLOW MOTOR GRAY GRAY STEP GRAY MOTOR GRAY (RIGHT/ LEFT) PINK Models : ASY30UBBJ / AOY30UNBDL GRAY GRAY GRAY GRAY STEP GRAY MOTOR GRAY GRAY (UP/DOWN) GRAY GRAY GRAY GRAY GRAY GRAY...

  • Page 7: Pcb Circuit Diagram

    INDOOR PCB CIRCUIT DIAGRAM CONTROLLER PCB ASSEMBLY ASY30FBBJ : K05EF-050EWSE-C1 CN3 B3B-XASK-1-A THRMAL FUSE UL1430 INDICATOR PCB GRAY SW201 10K x 2 AWG26 EVQ-PAG-04K EZ-0018HSE-D <1/10W> R41 1.0K <1/10W> 201-8 GRAY GRAY D2SB20 7805 R42 47 <1/10W> D1F60 201-7 2SD1191 GRAY D202 R202...
  • Page 8 CONTROLLER PCB ASSEMBLY ASY30UBBJ : K05EF-0507HSE-C1 CN3 B3B-XASK-1-A THRMAL FUSE UL1430 INDICATOR PCB GRAY SW201 10K x 2 AWG26 EVQ-PAG-04K EZ-0018HSE-D R41 1.0K <1/10W> <1/10W> GRAY 201-8 GRAY D2SB20 7805 R42 47 <1/10W> D1F60 201-7 2SD1191 GRAY D202 R202 R2 10K 1000P <R>...

  • Page 9: Error Display

    ERROR DISPLAY The OPERATION, TIMER and SWING lamps operate as follows according to the error contents. Fast flashing Slow flashing Error display Error contents OPERATION TIMER SWING (RED) (GREEN) (ORANGE) Indoor unit circuit board error Indoor unit room temperature sensor wire 2 times opened Indoor unit room temperature sensor wire...

  • Page 10: Disassembly Illustration

    DISASSEMBLY ILLUSTRATION INDOOR UNIT 473-1 146-2 574-2 163-2 146-1 160-1 855-1 855-2 574-1 338-1 178-1 69-1 338-2 178-1 963-1 69-2 2004.12.02...
  • Page 11 INDOOR UNIT 2005.01.17...
  • Page 12 INDOOR UNIT 522-2 522-3 522-1 2005.01.17...
  • Page 13 OUTDOOR UNIT 2004.12.01...
  • Page 14 OUTDOOR UNIT 2004.12.01...
  • Page 15 OUTDOOR UNIT 2005.01.17...
  • Page 16 OUYDOOR UNIT AOY30FNBDL 824-4 823-2 815-3 989-1 989-2 218-3 824-4 OUTDOOR UNIT AOY30UNBDL 823-2 815-3 218-3 989-1 989-2 2004.12.01...
  • Page 17 OUTDOOR UNIT AOY30FNBDL 82-1 13-2 2004.11.30...
  • Page 18 OUTDOOR UNIT AOY30UNBDL 13-2 82-1 2004.11.30...

  • Page 19: Parts List

    PARTS LIST INDOOR UNIT Part No. Part No. Ref. Ord. Ref. Ord. Description Description Q'ty Q'ty ASY30FBBJ ASY30FBBJ Capacitor (Fan Motor) 9704305060 338-1 Motor Holder-B 9368551001 Water Seal Plate 9369684005 338-2 Motor Holder-C 9368769000 Bracket (Eva. ) 9369372001 Indicator PCB Assy 9702307011 Decoration Plate-F Assy 9368757014...
  • Page 20 INDOOR UNIT Part No. Part No. Ref. Ord. Ref. Ord. Description Description Q'ty Q'ty ASY30UBBJ ASY30UBBJ Capacitor (Fan Motor) 9704305060 338-1 Motor Holder-B 9368551001 Water Seal Plate 9369684005 338-2 Motor Holder-C 9368769000 Bracket (Evaporator) 9369372001 Indicator PCB Assy 9702307011 Decoration Plate-F...
  • Page 21 OUTDOOR UNIT Part No. Part No. Ref. Ord. Ref. Ord. Description Description Q'ty Q'ty AOY30FNBDL AOY30FNBDL Fan Cover (Guard) 9371187013 117-3 Hex. Nut w/Sp. Washer 301721180114 Emblem-Rear 9371388014 Clamp No.1219 313361271706 Cabinet-A, Painted 9359797029 218-3 Power Relay 9900074012 Cabinet-B, Painted 9359798026 Accumulator 9385005006...
  • Page 22 Ref. Ord. Description Description Q'ty Q'ty AOY30UNBDL AOY30UNBDL Fan Cover (Guard) 9371187013 117-3 Hex. Nut w/Sp. Washer 301721180114 Emblem-Rear "FUJITSU" 9371388014 Clamp No. 1219 313361271706 Cabinet-A, Painted 9359797029 218-3 Power Relay 9900074012 Cabinet-B, Painted 9359798026 Accumulator 9385005006 Base Assy, Painted...

  • Page 23: Standard Accessories

    STANDARD ACCESSORIES INDOOR UNIT Name and Shape Part No. Wall hook bracket 9368579005 9371190013 Remote control unit (AR-JW1) (Heat & Cool model) (Reverse cycle) 9371190020 (AR-JW2) (Cooling only model) Battery (penlight) 0600185534 Remote control unit holder 9305642014 Tapping screw (big) ( 4 x 20) 301141164200 Tapping screw (small)
  • Page 24 0701G3199...
