- Page 1 ANUAL Version 2.0.2 (2006.05.22) Parani SD™ Bluetooth RS232C Serial Adaptor by Bluetooth Enabling Wireless Serial Communications...
- Page 2 FCC CONCERNS FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
-
Page 3: Parani-Sd100 User Manual – Table Of Contents
Parani-SD100 User Manual – Table of Contents Parani-SD100 SD100 Bluetooth Serial Adaptor Part Number External type wireless serial adapter with dip switch Description Class1 Power Class Up to 100m RF Range DC plug or 9 pin Power Connector DC5V / 2A (AC100~240V / 50Hz~60Hz) Power supply Female DB9 Serial connector... -
Page 4: Table Of Contents
Parani-SD100 User Manual – Table of Contents Table of Contents 1. Getting Started Components --------------------------------------------------------4 Assembly ------------------------------------------------------------- 4 Locating the Controls ------------------------------------------ 5 2. Configurations Operation Modes ------------------------------------------------- 7 LED Indicators -----------------------------------------------------8 Serial Ports ---------------------------------------------------------- 8 Reset to Factory Defaults ------------------------------------- 8 Terminal Program ------------------------------------------------ 9... -
Page 5: Getting Started
Parani-SD100 User Manual – 1. Getting Started 1. Getting Started Components Assembly Locating the Controls... - Page 6 Parani-SD100 User Manual – 1. Getting Started Components Helical Antenna Parani-SD100 DC 5V Power Cable Fig.1-1 Components of Prani-SD100 Assembly ※ Antenna is left-hand threaded. ※ Use of non-authorized power adapter is not recommended. Fig.1-2 Assembly of Prani-SD100...
- Page 7 Parani-SD100 User Manual – 1. Getting Started Locating the Controls Reset Button Front Panel † Pairing Button Power Jack Back Label ‡ Power Switch Fig.1-3 Locating the Controls...
-
Page 8: Configurations
Parani-SD100 User Manual – 2. Configurations 2. Configurations Operation Modes LED Indicators Serial Ports Reset to Factory Defaults Terminal Program Dip Switch Pairing Button... - Page 9 Parani-SD100 User Manual – 2. Configurations Operation Modes In addition to the serial port configurations such as bit/second, data bit, parity, stop bit, flow control, Parani-SD has some configurations for Bluetooth. For getting the most out of Parani-SD100, user should understand the following Bluetooth connection schemes.
- Page 10 Parani-SD100 User Manual – 2. Configurations LED Indicators Indicator Power LED Standby LED Connect LED Green Mode0 ┏━━━━━━━ ┏━━━━━━━ Green Green (every 1 sec) ┏┓ Mode1 ┏━━━━━━━ Mode2 Green Green (every 3 sec) ┏┰┓ ┏━━━━━━━ Mode3 Green Green (every 3 sec) ┏┰┓ ┏━━━━━━━...
-
Page 11: Terminal Program
Parani-SD100 User Manual – 2. Configurations Terminal Program A terminal p rogram is an application that will enable a PC to c ommunicate directly with a modem. If you are using Windows 98SE or higher version of Windows, HyperTerminal program as it is included as part of the operating system. Parani-SD100 provides some extended AT commands for its configurations on terminal program. -
Page 12: Dip Switch
Parani-SD100 User Manual – 2. Configurations AT+BTINFO? 000195000509,PSDv3b-000509,MODE0,STANDBY,0,0,HWFC AT+BTINQ? 00019520007E,PSDv2a-20007E,001F00 0004B300E205,AP2002:1 #0,020300 ATD00019520007E CONNECT 0001952007E Dip Switch With the combination of 4 slot dip switches, baud rate and hardware flow control can be set simply without host computer. Dip Switch Reset Button Pairing Button Upper 3 dip switches are used for setting baud rate, and bottom dip switch is used for setting hardware flow control... - Page 13 Parani-SD100 User Manual – 2. Configurations Press the Pairing Button of SD2 for 2 seconds until Standby LED turns off and Connect LED blinks 3 times every 2 seconds. Now press again the Pairing Button for 2 seconds until Connect LED blinks every 0.5 second. Wait for SD1 &...
-
Page 14: Connections
Parani-SD100 User Manual – 3. Connections Connections RS232 Interface Pin Assignment Power Supply... - Page 15 Parani-SD100 User Manual – 3. Connections RS232C Interface DTE/DCE If the full EIA232 standard is implemented as defined, the equipment at the far end of the connection is named the DTE device (Data Terminal Equipment, usually a computer or terminal), has a male DB9 connector. Equipment at the near end of the connection (the telephone line interface) is named the DCE device (Data Circuit-terminating Equipment, usually a modem), has a female DB9 connector.
- Page 16 Parani-SD100 User Manual – 3. Connections Pin Assignment To Host with DTE Interface To Host with DCE Interface...
- Page 17 Parani-SD100 User Manual – 3. Connections Power Supply Parani-SD100 can be supplied power through the power jack and through pin 9 of DB9 connector. Through Power Jack DC 5 V, Min. 150mA power should be supplied through DC power cable. Red cable is positive and black one is negative.
-
Page 18: Specifications
Parani-SD100 User Manual – 4. Specifications 4. Specifications Bluetooth Serial Interface Power Mechanical Dimensions Environmental Default Antenna Wireless Coverage... - Page 19 Parani-SD100 User Manual – 4. Specifications Bluetooth Interface Bluetooth 1.2 specification compatible and qualified Protocol: RFCOMM, L2CAP, SDP Profiles: Serial Port Profile, Generic Access Profile, Service Discovery Profile Radio Frequency: 2.402 ~ 2.480GHz Number of Channels: 79 Transmission Power Class 1 Data Transmission Rate: 380Kbps Max.
- Page 20 Parani-SD100 User Manual – 4. Specifications Default Antenna Type: Helical Frequency: 2,400 ~ 2,485GHz Gain: Max. 2dBi Impedance: 50Ω size: 30mm 9mm (W D) weight: 3.5g Wireless Coverage The table below shows the average measuring results in open space. These results can vary according to the environmental conditions.
-
Page 21: Appendix A. At Commands
Parani-SD100 User Manual – Appendix A. AT Commands Appendix A. AT Commands Terminology Command Description... -
Page 22: Terminology
Parani-SD100 User Manual – Appendix A. AT Commands Terminology AT Command AT command set is the d e facto standard l anguage for controlling m odems . The AT command set was developed by H ayes and is recognized by virtually all p ersonal computer modems. -
Page 23: Command Description
Parani-SD100 User Manual – Appendix A. AT Commands Command Description 1 ATZ SD Response Purpose Software Reset Description This is the same effect as power off and on. This command disconnects Bluetooth device, and stops ongoing task. After rebooting, the status is decided by the preset operation mode. Some AT commands need ATZ to take effect. - Page 24 SD100, v3b for the version of firmware, and 445566 for the last 6 digits of BD address. Mode=MODE0/MODE1/MODE2/MODE3 Status=STANDBY/PENDING/CONNECT Auth=0/1 (Authentication is not activated when 0) Encrypt=0/1 (Encryption is not activated when 0) FlowControl=HWFC/NoFC 000B530011FF,SENA,MODE0,PENDING,1,1,HWFC Example 7 AT+BTINQ? SD Response 112233445566,FriendlyName,CoD 112233445566,FriendlyName,CoD...
- Page 25 Parani-SD100 User Manual – Appendix A. AT Commands 10 +++ SD Response Purpose Convert the operation status of ‘Connect’ to ‘Standby’ Description In ‘Connect’ status, data from host is transmitted to the other side Bluetooth device, and any AT command is not accepted but this command, which is not echoed on the screen.
- Page 26 Parani-SD100 User Manual – Appendix A. AT Commands CONNECT 112233445566 ERROR Purpose Connect to the Bluetooth device with given BD address Parameters 112233445566=BD address Description Parani-SD100 attempts to connect to the Bluetooth device with the given BD address. To make successful connection, the Bluetooth device must be in Page scan. This attempt continues for 5 minutes.
- Page 27 Parani-SD100 User Manual – Appendix A. AT Commands SD Response Purpose Change S-register value Parameters nn= Address of S-register mm= New value of S-register Description Some S-registers are optimized for the overall performance and protected from an arbitrary change by user. When users try to change these S-registers, SD response is ‘ERROR’.
