Totally Wicked Revolution S User Manual page 6

Using your Revolution S
TCR Value Range
Material
Nickel
NiFe
Titanium
SS (303. 304, 316, 317)
Note: The TCR value displayed is 105 (100,000) times greater than the actual TCR
value and is for Revolution S usage only.
10
TW_Revolution S Manual.indd 10-11
TCR Value Range
600 - 700
300 - 400
300 - 400
80 - 200
Bypass Mode:
When in bypass mode there is a direct voltage output dependent on battery voltage and
atomizer resistance.
Upgrading Firmware:
To upgrade the firmware installed on the device simply load the relevant product page
on the Totally Wicked website, click on the link under 'Firmware Upgrade' and follow the
instructions provided.
Shift Between Clock Modes:
Two clock display modes are available, dial and numerical. When the clock display
is active, press the power button 3 times consecutively to activate the menu, turn the
adjustment switch to the left once and the second row will flash, turn the adjustment switch
to the right to cycle through the dial and numerical display options and press the power
button to confirm the selection.
11
27/06/2016 14:45
