Using your Revolution S
TCR Mode:
When in TCR mode
and the title is flashing
indicating that the menu is
active, turn the adjustment
switch to the left and the
sub-menu (M1, M2 and
M3) will flash. Whilst the
sub-menu is flashing turn
the adjustment switch to
the right to shift between
M1, M2 and M3, then
press the power button to
confirm.
(Also see: Configuring
TCR Mode)
8
TW_Revolution S Manual.indd 8-9
Configuring TCR Mode:
To set the temperature coefficient of resistance to
match a particular coil, when the device is powered
off simultaneously hold the power button and turn
the adjustment switch to the right to enter the TCR
configuration menu.
Turn the adjustment switch to the right or left to select
which to configure from M1, M2 and M3 – this feature
allows the TCR values for 3 materials to be stored
to the device. Press the power button to select the
TCR value and then turn the adjustment switch to the
right or left to increase or decrease the value to your
preference, long press the power button or leave the
device for 10 seconds to confirm the selection.
