Avocent Emerge MPX1500 Technical Specifications

Wireless HD Multipoint Extender
MPX1500: High-definition audio and video
The Avocent Emerge MPX multipoint extender provides wireless or wired connectivity for
distribution of high-definition content from a source to one or more destinations. Emerge MPX
transmitters and receivers work in unison to form a managed audio video extension network
able to deliver a synchronized stream of high-definition computer graphics or video and
associated audio from a source to as many as eight display devices. Display device control
information, content protection and interactive device control signals, including IR and serial are
passed from source to sink through the extension network, providing a fully integrated solution.
Ideal for professional high-definition media applications, the MPX1500 transmitter and receiver
feature a universal media port based upon a locking digital video interface (DVI-I) connector.
This media port allows for extension of digital and analog media formats, including: DVI-D,
HDMI, DVI-A, RGBHV or YPbPr signals. Embedded digital audio and unbalanced analog
audio are both supported. The MPX system serves as a video splitter and a extender by
wirelessly delivering audio and video to multiple displays up to 1000 feet away.
All MPX extenders feature an on-board web server for ease of central management. For
system control and configuration, the Emerge MPX extender solution is accessible through an
on-board web server that allows browser-based configuration, status monitoring, and
administration. The extenders allow for centralized control of attached audio-visual equipment
through RS-232 serial and infrared interfaces. The Emerge MPX product is field upgradeable
to support future functionality.
The Emerge MPX1500T transmitter and MPX1500R receiver feature a universal media port
based upon a digital video interface (DVI-I) connector. Support for both digital and analog video
formats enables these MPX extenders to connect to HDMI, DVI-D, DVI-A, RGB and component
source and display devices.
Emerge MPX1500
®
F E A T U R E S A N D B E N E F I T S
•
•
•
•
•
•
•
•
Plasma/LCD
Display and Audio
•
•
HDMI, the HDMI logo and High-Definition Multimedia
Interface are trademarks or registered trademarks of
HDMI Licensing LLC.
Wireless or Wired Extension. Provides
installation flexibility for wireless or wired
high-definition applications.
Universal DVI-I Video Port. The MPX1500 T/R
features a single DVI-I media port that supports
RGB, component, DVI-A, DVI-D, and HDMI video.
Enhanced Audio. Supported audio standards
include stereo analog audio supported via white
and red RCA connectors.
Point to Multipoint Distribution. High-
definition computer graphics or video and
associated audio can be distributed to as many
as eight display devices.
Serial Control. MPX1500 extenders support
broadcast and bi-directional serial data
transfers for management of attached display
devices.
IR Control. MPX 1500 extenders support
broadcast and bi-directional IR data transfers
for session control from the point of display or
for display control from the location of the
source device. Mini-jack cables allow IR
blasters and receivers to be optimally placed.
Web Control Interface. Allows local or
remote control and configuration of the system
without special software tools.
Serial Interface. Allows integration with third
party control systems.
AES 128 Bit Encryption. Audio-visual
information is encrypted with built-in Advanced
Encryption Standard (AES) for secure
transmission.
Small Form Factor. Small footprint allows
convenient installation and saves space where
it's needed the most.
