TECHNICAL DESCRIPTION

There are four Ecosmart Mini tank models, a 1.5 gallon, a 2.5 gallon, a 4
gallon and a 6 gallon model. The pressure vessel (water tank) is welded,
glass lined steel and is equipped with an anode rod.
The water heater is equipped with a thermostat and a high limit temperature
switch. A temperature/pressure relief valve is supplied with the unit.

INSTALLATION INSTRUCTIONS

ECO MINI 1- ECO MINI 2.5 - ECO MINI 4 -
The installation must be completed by a licensed professional. All state and
local codes must be adhered to. The manufacturer will not be liable for any
damages because of failure to comply with these installation instructions or
because of improper installation performed by an unqualified installer.
CHOOSE A LOCATION that allows ease of access for maintenance or
servicing, ideally installed at least 8" to 9" from the ceiling (inside top of
cabinet) or any adjacent walls.
WALL MOUNTING
Fasten the supplied mounting bracket to the wall. Use screws that are
suitable for the wall material and the weight of the water heater filled to
capacity (ECO MINI 1= 25 lbs. - ECO MINI 2.5 = 37 lbs. - ECO MINI 4 = 52
lbs. - ECO MINI 6 = 80 lbs.). Hang the water heater on the bracket and pull
downwards on the water heater to insure that both "fingers" of the bracket
are seated in the mounting slots. Confirm your water piping orientation (hot
and cold) before wall mounting. ONLY INSTALL IN VERTICAL POSITION.
Heater can sit on the floor. Confirm water piping orientation before finalizing
on floor. ONLY INSTALL IN VERTICAL POSITION! ECO MINI models
can be installed under the sink.
ECO MINI 6
55
Page 7 of
