Swisscom Magic-Box Setup Manual page 2

Congratulations! You have chosen to purchase
the WLAN Magic-Box!
As of today, you can start surfing on the latest generation WLAN network. You also have the
option to access all the data saved on a connected hard drive from any device connected to
your network.
The best WLAN network
using two frequency ranges at the
same time
Fast data transmission
by cable, thanks to the Gigabit ports
Data sharing (optional)
> you can access your data by using various devices
> you can stream music/pictures/videos
26
1
2
3
4
WLAN On/Off
Power On/Off
Pow er On
/Of f
USB hard drive
Your new WLAN network
The Magic-Box has two WLAN frequency ranges (dualband): 2.4 GHz and 5 GHz, that can be used
for wireless data transmission.
> The new 5GHz network has significantly less interferences and allows a much higher data
transmission rate than the Usual 2.4 GHz network. This makes this network particularly
adapted for high-performance applications such as video signals.
> The 2.4 GHZ network usually has a wider reach and is compatible with most devices. This
network is recommended for connecting smartphones and computers.
If a given device is compatible with both frequencies, it will automatically select the most
suitable frequency range (this depends on the connection quality as well as on its availability).
In case you need to choose by yourself if a device should be connected to the 2.4 GHz or the 5
GHz network, please proceed as described on page 30 «Defining different WLAN names (SSID)
for the 2.4 GHz and the 5 GHz networks (optional)».
Network example
TV-Box
Router
Connection Kit
5 GHz
2.4 GHz
Magic-Box
1
2
3
4
WLAN On/Off
Power On/Off
27
