REMOS GX
Pilot's Operating Handbook for Light Sport Aircraft
Airplane Registration Number
Airplane Serial Number
REMOS Publication No.
iS
______________________
______________________
104714, dated December 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GXiS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Remos GXiS

Summary of Contents for Remos GXiS

  • Page 1 REMOS GX Pilot’s Operating Handbook for Light Sport Aircraft Airplane Registration Number ______________________ Airplane Serial Number ______________________ REMOS Publication No. 104714, dated December 2017...
  • Page 2 intentionally left blank...

  • Page 3: Introduction

    G3-8 MA FM 9400 – R01 Introduction Record of Manual Revisions Please make a notation below if any changes have been made to this manual or to the aircraft. This manual is an important document for the pilot in command to ensure safe operation of the aircraft. Therefore, it is recommended to keep this Operating Handbook updated with the newest information available.
  • Page 4 G3-8 MA FM 9400 – R01 Introduction List of Content and Revisions This POH consists of the following listed pages and sections. You will find a marking indicating the revision and date of issue at the top border of each page. Insert the latest changed pages. Pilot Operating Handbook –...

  • Page 5: Certification

    G3-8 MA FM 9400 – R01 Introduction GXiS Light Sport Aircraft REMOS GXiS The REMOS was manufactured in accordance with the Light Sport Aircraft airworthiness standards and does not conform to standard category airworthiness requirements. The standards to be used for certification are given by FAA and can be obtained from the FAA’s website.
  • Page 6 G3-8 MA FM 9400 – R01 Introduction Views wingspan 9,32m (30.6 ft) total length 6,64m (21.8 ft) Introduction...
  • Page 7 G3-8 MA FM 9401 - R01 General Information Table of Contents sect. description page Introduction Certification Continued Airworthiness Quick Reference Technical Specifications Performance Engine Fuel 1.10 Propeller 1.11 ICAO Designator 1.12 Noise Certification General Information 1 - 1...
  • Page 8 G3-8 MA FM 9401 - R01 General Information Introduction This Operating Handbook is designed to help enable a safe and successful completion of each flight with the REMOS GXiS . It provides you with all necessary information for regular maintenance and operation of the aircraft.

  • Page 9: Quick Reference

    G3-8 MA FM 9401 - R01 General Information Quick Reference Type: Full composite carbon fiber aircraft with two seats. Design: High wing design with struts, front mounted engine propeller, traditional stabilizer concept, differential ailerons. Electrically operated flaps (0°, 15° and 35°), electric elevator trim, three-wheel landing gear with steerable nose wheel.

  • Page 10: Performance

    G3-8 MA FM 9401 - R01 General Information Performance This section shall give a summary of the performance of the REMOS GXiS . Detailed performance data is given in section 5 of this Pilot Operating Handbook. 105 kTAS @° 5,300 rpm...

  • Page 11: Fuel

    Fuel released by actual revision of ROTAX service instruction SI-912i- fuel qualities 001, preferably free of ethanol. Please refer to REMOS notification NOT-001 and ROTAX SI-912i-001 latest revision for further information on suitable engine fluids (fuel, oil, cooling liquid, additives, etc).

  • Page 12: Propeller

    1.11 ICAO Designator ICAO Designator: (as per ICAO Doc. 8643) 1.12 Noise Certification According to noise requirements for Ultralight aircraft (LS-UL) dated GXiS August 1996, the REMOS is certified to a noise level of 60 dB (A). General Information 1 - 6...

  • Page 13: Table Of Contents

    G3-8 MA FM 9402 - R01 Operating Limitations Table of Contents sect. description page Reference Airspeeds Airspeed Indicator Range and Markings Stalling Speeds at Maximum Takeoff Weight Flap Extended Speed Range Operating Maneuvering Speed Never Exceed Speed Service Ceiling Load Factors Approved Flight Maneuvers 2.10 Prohibited Maneuvers...

  • Page 14: Reference Airspeeds

    G3-8 MA FM 9402 - R01 Operating Limitations Reference Airspeeds speed description airspeed which shall never never exceed speed 135 kts be exceeded maximum speed airspeed which shall not be 107 kts in turbulence exceeded in gusty weather maximum airspeed for all permissible maneuvers operating maneuvering speed...

  • Page 15: Airspeed Indicator Range And Markings

    G3-8 MA FM 9402 - R01 Operating Limitations Airspeed Indicator Range and Markings marking range description white arc 39…78 kts airspeed range for flaps extended green arc 43…107 kts normal use 107…135 kts yellow arc caution in gusty conditions red line 135 kts maximum permissible airspeed The yellow arc defines the “caution”...

  • Page 16: Flap Extended Speed Range

    G3-8 MA FM 9402 - R01 Operating Limitations Flap Extended Speed Range Flaps may be operated and the aircraft may be flown at airspeeds higher than V as long as flap deflection is limited. Following restrictions apply as a function of airspeed: ...

  • Page 17: Never Exceed Speed

    G3-8 MA FM 9402 - R01 Operating Limitations Never Exceed Speed never exceed speed = 135 kTAS Due do the reduced density of air at altitude, true airspeed is higher than calibrated or indicated airspeed. Therefore, V is limited to 135 kts true airspeed in order to prevent flutter.

  • Page 18: Approved Flight Maneuvers

    GXiS tested. A general wind limitation is not defined for the REMOS Operating Limitations 2 - 6...

  • Page 19: Engine

    7 coolant temp not defined 120°C = 248°F Please refer to REMOS notification NOT-001 and ROTAX SI-912i-001 for further information on suitable engine fluids (fuel, oil, cooling liquid, additives, etc). NOTE Have a frequent look on www.flyrotax.com...

  • Page 20: Fuel

    7.0 bar = 102 psi oil temperature min. 50°C (120°F) max. 130°C (266°F) Please refer to REMOS notification NOT-001 and ROTAX SI-912-016/SI-914-019 for further information on suitable engine fluids (fuel, oil, cooling liquid, additives, etc). NOTE Have a frequent look on www.flyrotax.com and on www.remos.com...

  • Page 21: Maximum Wind Velocity For Tie-Down

    1 occupant (the pilot in command) and a maximum of 2 occupants. REMOS does not define a seat for the pilot in command. The seat of the pilot in command may be otherwise defined by regulations or by the owner/operator.

  • Page 22: Flight Conditions

    G3-8 MA FM 9402 - R01 Operating Limitations 2.19 Flight Conditions and Minimum Equipment List operation minimum equipment Day-VFR as per D-VFR Minimum Equipment List Night-VFR as per N-VFR Minimum Equipment List IFR in IMC not approved IFR in VMC as per IFR/VMC Minimum Equipment List Aerobatics not approved...
  • Page 23 G3-8 MA FM 9402 - R01 Operating Limitations N-VFR Minimum equipment list • as per D-VFR minimum equipment list, plus • electrical artificial horizon (*) • instrument panel lighting • position lights • taillight • anti collision lights • landing light •...

  • Page 24: Placards And Markings Inside Cabin

    G3-8 MA FM 9402 - R01 Operating Limitations 2.20 Placards and Markings Inside Cabin The placards and markings feature the following color codes. Type Inside Information white lettering on a black background - white framed Safety white lettering on a black background - red framed Warning white lettering on a red background - white framed The following list does not define the layout but the content and...
  • Page 25 G3-8 MA FM 9402 - R01 Operating Limitations The following information placards are installed inside the cabin. Installation of these placards is mandatory placard location center stack actual callsign of aircraft center stack between lane reset switches center stack at engine test button center stack around ignition key Operating Limitations 2 - 13...
  • Page 26 G3-8 MA FM 9402 - R01 Operating Limitations placard location center console at power lever left panel labeled with CB’s installed right panel labeled with CB’s installed Operating Limitations 2 - 14...
  • Page 27 G3-8 MA FM 9402 - R01 Operating Limitations The following safety placards are installed inside the cabin. Installation of these placards is mandatory placard location left cockpit above left cockpit screen left cockpit above left cockpit screen installed in combination with towing clutch only center stack on top of center stack...
  • Page 28 G3-8 MA FM 9402 - R01 Operating Limitations placard location aileron pushrod cut out baggage compartment when recovery system is installed The following warning placards are installed inside the cabin. Installation of these placards is mandatory placards location door door Operating Limitations 2 - 16...
  • Page 29 G3-8 MA FM 9402 - R01 Operating Limitations The following information placards and markings are found inside the cabin. Attaching these placards is not mandatory; these placards provide additional information to the pilot. placards location center stack at flap switch center stack at landing light switch center stack...
  • Page 30 G3-8 MA FM 9402 - R01 Operating Limitations placards location armrest at parking brake valve Operating Limitations 2 - 18...

  • Page 31: Placards And Markings Outside Cabin

    G3-8 MA FM 9402 - R01 Operating Limitations 2.21 Placards and Markings Outside Cabin The placards and markings feature the following color codes. Type Outside Information black lettering on a white background - black framed Safety red lettering on a white background - red framed Warning red lettering on a white background - red framed The following list does not define the layout but the content and...
  • Page 32 G3-8 MA FM 9402 - R01 Operating Limitations The following information placards are installed outside the cabin. Installation of these placards is mandatory placards location fuel tank filler cap metric units acceptable Operating Limitations 2 - 20...
  • Page 33 G3-8 MA FM 9402 - R01 Operating Limitations The following safety placards are installed outside the cabin. Installation of these placards is mandatory placards location center of elevator next to the opening for aileron pushrod, covered by wing if not folded center of fixed surface of elevator, covered if elevator...
  • Page 34 G3-8 MA FM 9402 - R01 Operating Limitations The following information placards and markings are found outside the cabin. Attaching these placards is not mandatory; these placards provide additional information to the pilot. placards location wheel fairings placard set with one unit only acceptable static ports The following safety placards and markings are found outside the...
  • Page 35 G3-8 MA FM 9403 - R01 Emergency Procedures Table of Content sect. description page Definitions Jettison of Doors Spin Recovery Recovery System Emergency Descent Inadvertent Icing Encounter Loss of Altimeter Loss of Airspeed Indicator Total Loss of Glass Cockpit 3.10 Loss of Elevator Control 3.11 Loss of Aileron Control...
  • Page 36 G3-8 MA FM 9403 - R01 Emergency Procedures sect. description page 3.28 Flight with INOP Generator(s) 3-24 3.29 Miscellaneous Engine Trouble 3-25 3.30 Flight with ONE deactivated LANE 3-28 3.31 Flight with ONE INOP Fuel Pump 3-28 3.32 Precautionary Landing 3-29 3.33 Emergency Landing on Land...

  • Page 37: Definitions

    G3-8 MA FM 9403 - R01 Emergency Procedures Definitions Procedures are instructions that must be performed in the given sequence, as far as possible without interruption. Checklists are lists for items to be checked in the applicable phase of flight (taxi, take-off, climb, etc.).

  • Page 38: Jettison Of Doors

    G3-8 MA FM 9403 - R01 Emergency Procedures Jettison of Doors Procedure 1. door lock OPEN 2. hinge pin PULL 3. door JETTISON Spin Recovery Procedure 1. engine IDLE 2. control stick NEUTRAL 3. rudder OPPOSITE SPIN DIRECTION 4. after stopping of rotation RECOVER Recovery System Procedure...

  • Page 39: Inadvertent Icing Encounter

    G3-8 MA FM 9403 - R01 Emergency Procedures Inadvertent Icing Encounter Procedure 1. engine FULL POWER 2. flaps 3. carburetor heat PULL 4. electric fuel pump 5. heading change BACKTRACK 6. descent LEAVING ICING CONDITIONS 7. altitude KEEP SAFE ALTITUDE Loss of Altimeter Procedure for aircraft with more than one altimeter installed...

  • Page 40: Loss Of Airspeed Indicator

    G3-8 MA FM 9403 - R01 Emergency Procedures Loss of Airspeed Indicator Procedure for aircraft with more than one airspeed indicator installed 1. AVIATE – NAVIGATE – COMMUNICATE 2. airspeed indicator USE ALTERNATE ASI 3. in case of failure of all airspeed indicators installed continue with procedure below for aircraft with one airspeed indicator installed or total failure of ASI 4.200…4.600 rpm...

  • Page 41: Total Loss Of Glass Cockpit

    G3-8 MA FM 9403 - R01 Emergency Procedures Total Loss of Glass Cockpit Procedure failure of one glass screen (frozen or black) 1. AVIATE – NAVIGATE – COMMUNICATE 2. glass screen USE ALTERNATE SCREEN 3. continue flight and land on appropriate airfield to determine the reason for the failure failure of both glass screens (frozen or black) 1.

  • Page 42: Loss Of Elevator Control

    G3-8 MA FM 9403 - R01 Emergency Procedures 3.10 Loss of Elevator Control Procedure aircraft equipped with recovery system 1. AVIATE – NAVIGATE – COMMUNICATE 2. declare emergency MAYDAY MAYDAY MAYDAY 3. recovery system DEPLOY aircraft without recovery system 1. AVIATE – NAVIGATE – COMMUNICATE 2.

  • Page 43: Loss Of Aileron Control

    G3-8 MA FM 9403 - R01 Emergency Procedures 3.11 Loss of Aileron Control Procedure aircraft equipped with recovery system 1. AVIATE – NAVIGATE – COMMUNICATE 2. declare emergency MAYDAY MAYDAY MAYDAY 3. recovery system DEPLOY aircraft without recovery system 1. AVIATE – NAVIGATE – COMMUNICATE 2.

  • Page 44: Loss Of Rudder Control

    G3-8 MA FM 9403 - R01 Emergency Procedures 3.12 Loss of Rudder Control Procedure aircraft equipped with recovery system 1. AVIATE – NAVIGATE – COMMUNICATE 2. declare emergency MAYDAY MAYDAY MAYDAY 3. recovery system DEPLOY aircraft without recovery system 1. AVIATE – NAVIGATE – COMMUNICATE 2.

  • Page 45: Loss Of Trim System

    G3-8 MA FM 9403 - R01 Emergency Procedures 3.13 Loss of Trim System Procedure pitch down trim runaway or stuck trim with lot of trim down 1. AVIATE – NAVIGATE – COMMUNICATE 2. expect nose down attitude 3. keep nose up with manual stick input 4.

  • Page 46: Loss Of Flap Control System

    G3-8 MA FM 9403 - R01 Emergency Procedures 3.14 Loss of Flaps Control System Procedure flaps stuck in deflected position or flaps down runaway 1. AVIATE – NAVIGATE – COMMUNICATE 2. max. flap speed = 78 kIAS 3. approach airspeed = 60 kIAS 4.

  • Page 47: Loss Of Oil Pressure

    G3-8 MA FM 9403 - R01 Emergency Procedures 3.15 Loss of Oil Pressure Procedure oil temperature not stable (constantly and rapidly rising) smell of oil, oil fumes, oil on windscreen 5. AVIATE – NAVIGATE – COMMUNICATE 6. PERFORM PRECAUTIONARY LANDING oil temperature stable (constant oil temperature) no obvious oil leakage, engine running smooth 1.

  • Page 48: High Oil Pressure

    G3-8 MA FM 9403 - R01 Emergency Procedures 3.16 High Oil Pressure Procedure oil temperature not stable (constantly and rapidly rising) smell of oil, oil fumes, oil on windscreen 1. AVIATE – NAVIGATE – COMMUNICATE 2. PERFORM PRECAUTIONARY LANDING oil temperature stable (constant oil temperature) no obvious oil leakage, engine running smooth 1.

  • Page 49: High Cylinder Head Temperature

    G3-8 MA FM 9403 - R01 Emergency Procedures 3.17 High Cylinder Head Temperature Procedure 1. AVIATE – NAVIGATE – COMMUNICATE 2. power setting REDUCE TO MIN. POSSIBLE 3. continue flight and land on appropriate airfield to determine the reason of the high cylinder head temperature 4.

  • Page 50: Engine Stoppage During Take-Off

    G3-8 MA FM 9403 - R01 Emergency Procedures 3.18 Engine Stoppage during Take-Off Procedure during take-off run (aborted take-off) 1. AVIATE – NAVIGATE – COMMUNICATE 2. brakes AS REQUIRED 3. ignition key during climb out (altitude below 500ft) 1. AVIATE – NAVIGATE – COMMUNICATE 2.

  • Page 51: Engine Stoppage In Flight

    G3-8 MA FM 9403 - R01 Emergency Procedures 3.19 Engine Stoppage in Flight Procedure case 1: altitude not enough for engine re-start 1. AVIATE – NAVIGATE – COMMUNICATE 2. landing site IDENTIFY 3. declare emergency MAYDAY MAYDAY MAYDAY 4. safety belts TIGHTEN 5.

  • Page 52: Engine On Fire During Start-Up

    G3-8 MA FM 9403 - R01 Emergency Procedures 3.20 Engine on Fire During Start-Up Procedure 1. ignition key 2. vacate aircraft IMMEDIATELY 3.21 Engine on Fire During Take-Off Procedure during take-off run (aborted take-off) 1. AVIATE – NAVIGATE – COMMUNICATE 2.

  • Page 53: Engine On Fire In Flight

    G3-8 MA FM 9403 - R01 Emergency Procedures 3.22 Engine on Fire in Flight Procedure 1. AVIATE – NAVIGATE – COMMUNICATE 2. declare emergency MAYDAY MAYDAY MAYDAY 3. ignition key AVIONIC (engine off) 4. sideslip AS REQUIRED 5. safety belts TIGHTEN 6.

  • Page 54: Loss Of Power

    G3-8 MA FM 9403 - R01 Emergency Procedures 3.24 Loss of Power Procedure 1. AVIATE – NAVIGATE – COMMUNICATE 2. landing site IDENTIFY 3. power and setting CHECK power not sufficient for safe flight 4. declare emergency MAYDAY MAYDAY MAYDAY 5.

  • Page 55: Generator Failure / Voltage Drop

    G3-8 MA FM 9403 - R01 Emergency Procedures 3.25 Generator Failure / Voltage Drop Procedure 1. AVIATE – NAVIGATE – COMMUNICATE 2. Identification LANE A and B FLASHING and or LOW VOLTAGE WARNING 3. emergency switch LIFT and ENGAGE 4. SkyView LH press STAY ON 5.

  • Page 56: Battery Warning

    G3-8 MA FM 9403 - R01 Emergency Procedures 3.26 Battery Warning Checklist If installed, battery warning is coming up as lighting or flashing battery status light in the DYNON SkyView system. Proceed as follows: warning light flashing voltage possible cause action <...

  • Page 57: Over-Voltage

    G3-8 MA FM 9403 - R01 Emergency Procedures 3.27 Over-Voltage Procedure The aircraft is equipped with an overvoltage protection. This subsystem protects the aircraft systems and the avionics in case of an overvoltage event. The overvoltage protection is integrated into the PSU (power supply unit) and needs neither maintenance not operation.

  • Page 58: Flight With Inop Generator(S)

    G3-8 MA FM 9403 - R01 Emergency Procedures 3.28 Flight with INOP Generator(s) Briefing The engine is equipped with two generators – one for the engine systems (ignition, fuel pumps, ECU, fuse box) and a second one for the aircraft systems. After a single generator failure, the ECU switches to the remaining generator to ensure safe operation of the engine.
  • Page 59 G3-8 MA FM 9403 - R01 Emergency Procedures 3.29 misc. Engine Trouble Procedure 1. AVIATE – NAVIGATE – COMMUNICATE 2. landing site IDENTIFY 3. emergency switch LIFT and ENGAGE 4. SkyView LH press STAY ON 5. landing light 6. troubleshooting SEE TABLE By engaging the emergency mode non-essential systems are switched off, i.e.:...
  • Page 60 G3-8 MA FM 9403 - R01 Emergency Procedures LANE fault procedure 1. LANE RESET 2. distress solved CONTINUE FLIGHT one LANE 3. Flight may be continued to suitable destination flashing on own discretion with one corrupt LANE. 1. LANE A RESET 2.
  • Page 61 G3-8 MA FM 9403 - R01 Emergency Procedures One flashing LANE indicates an error with lower severity that has been detected by the internal testing NOTE procedures of the ECU and does not imply any risk for an engine failure. With one corrupt LANE, the associated engine NOTE instruments will fail.

  • Page 62: Flight With One Deactivated Lane

    G3-8 MA FM 9403 - R01 Emergency Procedures 3.30 Flight with ONE deactivated LANE Briefing The engine is equipped with a dual lane engine control unit. Failure of one of those lanes does not lead to an engine failure and does not lead into an immediate dangerous situation.

  • Page 63: Precautionary Landing

    G3-8 MA FM 9403 - R01 Emergency Procedures 3.32 Precautionary Landing Procedure 1. AVIATE – NAVIGATE – COMMUNICATE 2. landing site IDENTIFY 3. direction of wind IDENTIFY 4. landing direction INTO THE WIND or UPHILL 5. landing site inspection PERFORM LOW APPROACH 6.

  • Page 64: Emergency Landing On Land

    G3-8 MA FM 9403 - R01 Emergency Procedures 3.33 Emergency Landing on Land Procedure 1. AVIATE – NAVIGATE – COMMUNICATE 2. landing site IDENTIFY 3. direction of wind IDENTIFY 4. approach airspeed = 60 kIAS 5. max. flap speed = 78 kIAS 6.
  • Page 65 G3-8 MA FM 9404 - R01 Standard Procedures Table of Content sect. description page Definitions Preflight Check Before Start-Up Engine Start After Start-Up Engine Run Up Taxi Departure Take-Off 4.10 Best Angle of Climb Speed (V 4-12 4.11 Best Rate of Climb Speed (V 4-12 4.12 Cruise...

  • Page 66: Standard Procedures

    G3-8 MA FM 9404 - R01 Standard Procedures Definitions Procedures are instructions that must be performed in the given sequence, as far as possible without interruption. Checklists are lists for items to be checked in the apropriate phase of flight (taxi, take-off, climb, etc.).
  • Page 67 G3-8 MA FM 9404 - R01 Standard Procedures Preflight Check Checklist Checks outside the aircraft fuel system drained before moving the aircraft at all engine oil level (between min. and max. markings) level of engine coolant (between min. and max. markings) cowling is closed and properly secured propeller has no damage or wear nose gear and wheel/tire have no damage or wear, air pressure is...
  • Page 68 G3-8 MA FM 9404 - R01 Standard Procedures 26. fuselage has no damage right main gear and wheel/tire have no damage or wear, air pressure correct and suspension is free 28. lower wing strut attachment is secured 29. flap, linkage and hinges have no damage, rubber stops (flutter damper) on outer hinges are in place 30.
  • Page 69 G3-8 MA FM 9404 - R01 Standard Procedures Checks inside the aircraft aileron quick-fasteners are securely locked enough fuel on board for the flight both seats are properly secured in intended position both doors can be locked check proper functioning of the flap drive and gauge Insecurely connected, improper operation of control surfaces or insecurely locked fasteners will lead to loss of control of the aircraft!! Standard Procedures 4 - 5...

  • Page 70: Engine Start

    G3-8 MA FM 9404 - R01 Standard Procedures Before Start-Up Checkliste 1. doors LOCKED 2. safety belts FASTENED 3. parking brake 4. recovery system ARMED Engine Start Procedure 1. ignition key AVIONIC 2. avionics SET UP (if applicable) 3. ignition key ENGINE 4.
  • Page 71 G3-8 MA FM 9404 - R01 Standard Procedures After Start-Up Procedure 1. oil pressure 2,000 … 2,500 rpm 2. engine speed for warm-up Once the engine has started it is supported by generator B, the aircraft systems are powered by the aircraft batteries only.
  • Page 72 G3-8 MA FM 9404 - R01 Standard Procedures Taxi Procedure 1. landing light RECOMMENDED 2. parking brake RELEASE 3. engine speed AS REQUIRED 4. control on ground VIA PEDALS 5. min. turn radius ca. 20 ft = 7 m 6. braking AS REQUIRED 7.
  • Page 73 G3-8 MA FM 9404 - R01 Standard Procedures Take-Off Procedure standard take-off 1. brakes 2. flaps 3. elevator trim GREEN MARK ON INDICATOR 4. rudder and aileron NEUTRAL 5. engine power FULL POWER 6. brakes RELEASE 7. rotate and lift-off 52 kIAS 8.
  • Page 74 G3-8 MA FM 9404 - R01 Standard Procedures comfort take-off 1. flaps 2. elevator trim GREEN MARK ON INDICATOR 3. rudder and aileron NEUTRAL 4. engine power FULL POWER 5. rotate 45 kIAS 50 … 55 kIAS 6. lift-off 7. best climb 60 kIAS Take-off with this procedure is way more comfortable, but take-off distances increase significantly as when using...
  • Page 75 G3-8 MA FM 9404 - R01 Standard Procedures short/soft field take-off 1. brakes 2. flaps 15 deg 3. elevator trim GREEN MARK ON INDICATOR 4. rudder and aileron NEUTRAL 5. engine power FULL POWER 6. brakes RELEASE 7. rotate and lift off 50 kIAS 8.
  • Page 76 G3-8 MA FM 9404 - R01 Standard Procedures 4.10 Best Angle of Climb Speed (V Checklist 1. flaps 15deg or CLEAN 2. steepest climb = 50 kIAS 3. engine power FULL POWER 4. coolant temperature max. 248°F = 120°C 120…266°F = 50…130°C 5.
  • Page 77 G3-8 MA FM 9404 - R01 Standard Procedures 4.13 Flying in Rain Checklist 1. engine speed AS REQUIRED 2. coolant temperature max. 248°F = 120°C 120…266°F = 50…130°C 3. oil temperature • visibility to the front is very limited • windscreen may need defogging •...
  • Page 78 G3-8 MA FM 9404 - R01 Standard Procedures 4.15 Flying Without Doors Procedure 1. door lock OPEN 2. gas spring on door DETACH 3. hinge pin PULL 4. door TAKE OUT CAREFULLY is reduced to 100 kIAS when flying without doors. NOTE Flying without doors leads to high wind velocities inside NOTE...
  • Page 79 G3-8 MA FM 9404 - R01 Standard Procedures 4.16 Descent Checklist 1. flaps CLEAN 2. engine speed AS REQUIRED 3. operating maneuvering speed V = 88 kIAS (600kg AUW) = 59 kIAS (400kg AUW) 4. normal operating speed = 107 kIAS 5.
  • Page 80 G3-8 MA FM 9404 - R01 Standard Procedures 4.18 Landing Procedure 1. full flaps airspeed = 78 kIAS 2. approach airspeed = 60 kIAS 3. flaps DOWN 4. target airspeed AS RECOMMENDED 5. engine power AS REQUIRED 6. elevator trim AS REQUIRED 7.
  • Page 81 G3-8 MA FM 9404 - R01 Standard Procedures advise In landing configuration, the airplane is very draggy and the propeller provides additional braking. Therefore, airspeed bleeds off quickly during flare. It is easy to misjudge altitude during flare. When flare is initiated too high and airspeed bleeds away the airplane may stall or bounce.
  • Page 82 G3-8 MA FM 9404 - R01 Standard Procedures 4.19 Balked Landing Procedure 1. engine power FULL POWER 2. initial climb 52 kIAS 3. flaps retract SAFE ALTITUDE 4. best climb 60 kIAS 5. coolant temperature max. 120°C 50…130°C 6. oil temperature 4.20 After Landing Checklist 1.
  • Page 83 G3-8 MA FM 9405 - R01 Performance Table of Contents sect. description page General Summary of Flight Performances ISA Atmosphere Take-Off Distance Landing Distance Cruise Speed and Fuel Flow 5-11 Range and Endurance 5-12 Rate of Climb 5-14 Low Airspeed and Stall 5-16 5.10 Safe Glide Ratio...

  • Page 84: General

    G3-8 MA FM 9405 - R01 Performance General All flight performances given in this section (speed, range, fuel flow, rate of climb, etc.) are reference values. Tolerances of engine and propeller as well as deviations NOTE from standard temperature and density of air may reveal divergent performances.

  • Page 85: Summary Of Flight Performances

    G3-8 MA FM 9405 - R01 Performance Summary of Flight Performances (stallspeed flaps 35°) kIAS (stallspeed flaps 15°) kIAS (stallspeed flaps 0°) kIAS (any flap setting) kIAS (flaps clean) kIAS rate of climb at MSL flaps clean ft/min rate of descent at MSL in idle ft/min best glide kIAS...

  • Page 86: Isa Atmosphere

    G3-8 MA FM 9405 - R01 Performance ISA Atmosphere All flight performance data are given for ISA standard atmosphere at sea level and standard temperature. To determine temperature in relation to ISA conditions please refer to the following chart: ISA std. Temperature 15000 14000 13000...
  • Page 87 G3-8 MA FM 9405 - R01 Performance Take-Off Distances For take-off with max. take-off weight on an even, dry, paved runway with ISA conditions on sea level, dry aircraft, wind calm, standard tires with wheel pants and doors closed the following take-off distances apply: flaps 0°...
  • Page 88 G3-8 MA FM 9405 - R01 Performance Performance data apply under ISA conditions on an even, dry, hard runway surface, standard tires with wheel pants and doors closed. Various circumstances have an effect on take-off performance, it is recommended to use following add-ons on roll- and air distances: add-ons on take-off roll distance for dry grass + 20%...

  • Page 89: Take-Off Distance

    G3-8 MA FM 9405 - R01 Performance example calculation: Take-off in 2.000ft at 35°C from wet grass runway, 5kt tailwind, wet wing, take-off with flaps 15°. Standard wheels are mounted with wheel fairings. 1. temperature acc. to ISA diagram 12°C real temperature 30°C temperature above ISA:...

  • Page 90: Landing Distances

    G3-8 MA FM 9405 - R01 Performance Landing Distances Landing is to be done with full flaps (35 deg). After touchdown, brake to the max for shortest landing distance, but do not block the wheels. For landing with max. take-off weight on dry, paved runway with ISA conditions on sea level, dry aircraft, wind calm, standard tires with wheel pants and doors closed the following landing distances apply: Flaps 35°...
  • Page 91 G3-8 MA FM 9405 - R01 Performance Performance data apply under ISA conditions on an even, dry, hard runway surface, standard tires with wheel pants and doors closed. Various circumstances have an effect on take-off and landing performance, it is recommended to use following add-ons on roll- and air distances: add-ons on landing roll distance for dry grass...

  • Page 92: Landing Distance

    G3-8 MA FM 9405 - R01 Performance example calculation: Landing on soft surface with 2.000ft field elevation at 22°C, 5kt tailwind, wet wing and 2% downhill slope 1. temperature acc. to ISA diagram 12°C real temperature 22°C temperature above ISA: 10°C add-on for 10°C above ISA 2.

  • Page 93: Cruise Speed And Fuel Flow

    G3-8 MA FM 9405 - R01 Performance Cruise Speed and Fuel Flow Performance 5 - 11...

  • Page 94: Range And Endurance

    G3-8 MA FM 9405 - R01 Performance Range and Endurance Performance 5 - 12...
  • Page 95 G3-8 MA FM 9405 - R01 Performance Performance 5 - 13...

  • Page 96: Rate Of Climb

    G3-8 MA FM 9405 - R01 Performance Rate of Climb Performance 5 - 14...
  • Page 97 G3-8 MA FM 9405 - R01 Performance best angle of climb airspeed kIAS (any flap setting) best rate of climb airspeed kIAS (flaps clean) best rate of climb at MSL initial climb Climb is flown with flaps retracted, see section 4 NOTE Expect a performance loss of about 5% when flying NOTE...

  • Page 98: Low Airspeed And Stall

    G3-8 MA FM 9405 - R01 Performance Low Airspeed and Stall If the center of gravity is within the permissible range, the aircraft will be fully controllable until reaching the stall speed. As the aircraft approaches the stall speed, this will be indicated by slight aerodynamic buffeting.

  • Page 99: Safe Glide Ratio

    G3-8 MA FM 9405 - R01 Performance 5.10 Safe Glide Ratio Airspeed for best glide is 60kIAS. Safe glide ratio of the airplane with wind milling propeller is approximately 1:11. This will result in following glide distances: airspeed for best glide [ kIAS ] glide ratio [ -- ]...
  • Page 100 G3-8 MA FM 9405 - R01 Performance intentionally left blank Performance 5 - 18...
  • Page 101 G3-8 MA FM 9406 - R01 Weight and Balance Table of Contents General Station Definitions Aircraft Weighing Procedure Change of Equipment Operating Weights and Loading Weight and Balance Chart Center of Gravity Range and Determination Calculation Example Equipment List 6.10 Aircraft Specific Weights 6-15 Weight and Balance 6 - 1...

  • Page 102: General

    G3-8 MA FM 9406 - R01 Weight and Balance General This section provides information how to determine the inflight center of gravity. Prior to each take-off, the pilot in command shall ensure that the center of gravity is within its permissible envelope. For a correct determination of the inflight center of gravity the pilot needs following information: •...

  • Page 103: Station Definitions

    G3-8 MA FM 9406 - R01 Weight and Balance Station Definitions seats fuel baggage item station seats 210 mm baggage 950 mm fuel 960 mm empty/inflight CG variable Procedure for determination of empty CG is given in the maintenance handbook. Actual empty CG can be obtained from the aircraft’s individual weight and balance report and/or section 6.8 of this manual.

  • Page 104: Aircraft Weighing Procedure

    G3-8 MA FM 9406 - R01 Weight and Balance Aircraft Weighing Procedure To determine the aircraft empty weight and CG, put the aircraft on 3 weighing scales, positioned on a level surface. Before weighing, a level wing main chord has to be established (use pads between main wheels and scale beneath).

  • Page 105: Change Of Equipment

    G3-8 MA FM 9406 - R01 Weight and Balance Change of Equipment After change of equipment with known weight and CG of the added or removed equipment the new empty weight and CG of the aircraft can also be calculated instead of being determined by weighing as follows: old empty weight new empty weight weight of item added/removed...

  • Page 106: Operating Weights And Loading

    G3-8 MA FM 9406 - R01 Weight and Balance Operating Weights and Loading The CG range for any given airborne weight, measured from reference, must be within the permissible limits of 9.6in to 16.3in. minimum airborne weight 880 lb maximum take-off weight 1.320 lb front limit of CG 9.6 in...

  • Page 107: Center Of Gravity Range And Determination

    G3-8 MA FM 9406 - R01 Weight and Balance Center of Gravity Range and Determination The following procedure must be used to calculate the inflight CG. 1. moment calculation moment (lb-inch) weight (lb) x station (inch) weight station moment inch lb-inch empty weight ____...

  • Page 108: Calculation Example

    G3-8 MA FM 9406 - R01 Weight and Balance Calculation Example weight station moment inch lb-Inch empty weight 12.5 8,375 occupants 1,453 baggage 37.4 1,122 fuel 37.8 4,536 Weight Total: Moment Total: 15,486 moment total (lb-inch) center of gravity (inch) weight total (lb) 15,486...

  • Page 109: Equipment List

    [ - ] [ - ] [ kg ] [ m ] [ - ] tie down ring REMOS G3-8_WG-04-00-30 0.05 0.30 Ceiling hanging brackets REMOS G3-8_AC-01-00-00 0.09 0.30 Venting Qty. Item Manufacturer Model Weight R/O/A (*) [ - ]...
  • Page 110 Interior Pad ctr. LH REMOS 102770 0.15 - 0.30 Interior Pad ctr. RH REMOS 102771 0.15 - 0.30 Interior Pad leg area LH REMOS 102772 0.1 - 0.30 Interior Pad leg area RH REMOS 102773 0.1 - 0.30 Interior Pad armrest REMOS 102774 0.30...
  • Page 111 [ m ] [ - ] battery, min. 8.3Ah not specified lead battery 4.20 - 0.66 battery, min. 8.3Ah not specified LiFePO4 battery 1.60 - 0.66 Electrical System GXiS REMOS G3-8_CP-30-06-24 8.50 -0,45 Emergency Equipment Qty. Item Manufacturer Model Weight R/O/A (*)
  • Page 112 REMOS G3-8_MG-10-30-00 0.02 0.65 Main Wheel Assy REMOS G3-8_MG-10-10-00 1.15 0.65 Nose Wheel Assy REMOS G3-8_NG-50-10-00 0.45 - 0.75 Maingear bellyfairing LH REMOS G3-8_MG-40-02-29 0.30 0.65 Maingear bellyfairing RH REMOS G3-8_MG-40-02-28 0.30 0.65 Maingear legfairing LH REMOS G3-8_MG-40-02-25 0.25 0.65...
  • Page 113 G3-8 MA FM 9406 - R01 Weight and Balance Lights Qty. Item Manufacturer Model Weight R/O/A (*) [ - ] [ - ] [ - ] [ - ] [ kg ] [ m ] [ - ] ACL/NAV Light LH AeroLEDs PULSAR-NS180 0.12...
  • Page 114 LORD J 3608 0.10 -0.79 Propeller incl. Spinner Duc Hélices FLASH-R H- 6.10 - 1.35 FSH_3-D-R-I Cooling System REMOS G3-8_EN-23-00-09 4.50 -1.10 Exhaust System 87-2231 5.20 - 0.86 _____________________________________________ R = required, O = optional, A = alternative (5*) engine including overload clutch, starter relay, starter engine, cooling hoses,...

  • Page 115: Aircraft Specific Weights

    G3-8 MA FM 9406 - R01 Weight and Balance 6.10 Aircraft Specific Weights Below are noted the aircraft specific data. Pilots must use this information to ensure a correct weight and balance calculation prior to every flight. This is essential for safe flight. For detailed information of the weight and balance data and the equipment installed on the aircraft refer to the individual aircraft weight and balance report, which includes the equipment list.
  • Page 116 G3-8 MA FM 9406 - R01 Weight and Balance intentionally left blank Weight and Balance 6 - 16...
  • Page 117 G3-8 MA FM 9407 - R01 Airplane and Systems Description Table of Contents sect. description pages General Airframe Control System Cockpit Overview 7-12 DYNON SkyView 7-14 COM and NAV/COM 7-19 Intercom and Audio Panel 7-24 GPS Equipment 7-26 Transponder 7-28 7.10 GTN750 GPS/NAV/COM/XPDR/Audio 7-30...

  • Page 118: General

    G3-8 MA FM 9407 - R01 Airplane and Systems Description General This section of the POH shall give a brief introduction into the systems installed in the REMOS GXiS . For further information, maintenance and repair instructions see maintenance manual, latest revision.
  • Page 119 G3-8 MA FM 9407 - R01 Airplane and Systems Description assembly of the wing The wing consists of four main pars: wingbox, flap, aileron and wingtip. The wingtip is bolted to the wingbox, aileron and flap are hinged to allow control movements. The wing is completed by the cover glass of the landing light and the main wingbolt which attaches the wing to the fuselage.
  • Page 120 G3-8 MA FM 9407 - R01 Airplane and Systems Description structure of the wing The wingbox is built up by the upper and lower wing skin consisting of CFRP sandwich (foam). Loads are transferred into the main and rear wing spar. The structure is completed by the landing light bay and ribs reinforcing hinge areas, closing the wing to the wingtip and the fuse- lage.
  • Page 121 G3-8 MA FM 9407 - R01 Airplane and Systems Description structure of the fuselage The skins of the fuselage are build of a monolithic layup of glass, car- bon and Kevlar, reinforced by carbon tapes. Sandwich material (foam) is found in the fixed surface of the vertical tail only, which is an integral part of the fuselage.
  • Page 122 The wing strut is attached towards the wing and fuselage by a high tensile bolt, which is a genuine REMOS part. The wing strut can pivot about its axis some degree in order to allow the wing to be folded.
  • Page 123 G3-8 MA FM 9407 - R01 Airplane and Systems Description installation of horizontal tail The horizontal tail is made from GFRP. It is built up similar as the wing structure, consisting of ribs and spars. The elevator included a trim tab, which is operated electrically. The trim tab does not have a dedicated hinge, but uses the elastic flap technology;...

  • Page 124: Control System

    G3-8 MA FM 9407 - R01 Airplane and Systems Description Control System The control system is made of aluminum pushrods and crank bells for the elevator and aileron controls. The rudder is operated by steel ca- bles. The trim system is an electrically driven trim tab on the elevator; aileron and rudder have ground adjustable tabs.
  • Page 125 G3-8 MA FM 9407 - R01 Airplane and Systems Description elevator control system The control sticks are installed to a pivoting connection element (stick bridge). Thereby a push/pull input stick is transferred from the control stick through a bell crank and a push-pull tube towards the elevator. An electrical operated elevator trim tab is installed on the elevator.
  • Page 126 G3-8 MA FM 9407 - R01 Airplane and Systems Description aileron control system Both control sticks are linked together by a control rod system to en- sure synchronous movement. The linkage is located beneath two fi- berglass-panels on the floor of the cabin right in front of the seats. A translator connects the control stick linkage to the aileron linkage, which uses several bell cranks to establish the connection to the con- trol surfaces.
  • Page 127 G3-8 MA FM 9407 - R01 Airplane and Systems Description flying with only one control stick installed Under certain conditions it might be favorable to have only one control stick installed. It is permissible to take out the control stick on the pas- senger side.

  • Page 128: Cockpit Overview

    G3-8 MA FM 9407 - R01 Airplane and Systems Description Cockpit Overview general The REMOS GXiS is available with several avionic suites. Standard equipment is one DYNON D600 SkyView SE with 7” screen size and a PS Engineering PAR200A radio with integrated intercom.
  • Page 129 G3-8 MA FM 9407 - R01 Airplane and Systems Description cockpit examples circuit breakers circuit breakers engine emergency switch 7“ SkyView 7“SkyView landing light dimmer cockpit light flap switch LANE deactivate heating and ventilation engine START engine TEST ELT switch ignition key circuit breaker circuit breaker...

  • Page 130: Dynon Skyview

    G3-8 MA FM 9407 - R01 Airplane and Systems Description DYNON SkyView Versions The DYNON SkyView Family is available in three versions of two dif- ferent screen sizes each. The size of the screen has no effect on func- tionality. HDX800/ funktionality D600/D900...
  • Page 131 G3-8 MA FM 9407 - R01 Airplane and Systems Description screen of DYNON D600/D700/D900/D1000 Figures show elements. Display may vary in flight Systems 7 - 15...
  • Page 132 G3-8 MA FM 9407 - R01 Airplane and Systems Description screen of DYNON HDX800/HDX1100 Figure shows elements. Display may vary in flight primary instrumentation The primary flight instrumentation and engine indication are realized by the DYNON SkyView glass cockpit system. This is an integrated system, it includes the “Electronic Flight information Display”...
  • Page 133 OAT, HIS incl. CDI and glideslope for ILS approaches. Engine speed, oil pressure, oil temper- ature, fuel flow, fuel pressure, fuel amount in fuel tank and voltmeter. Although the REMOS GXiS equipped with the DYNON...
  • Page 134 G3-8 MA FM 9407 - R01 Airplane and Systems Description Push joystick, tilt up or down to select BARO, then rotate to adjust QNH layout The screen split and content can be selected by pressing LAYOUT, then the items to be displayed can be selected, e.g.

  • Page 135: Com And Nav/Com

    G3-8 MA FM 9407 - R01 Airplane and Systems Description COM and NAV/COM GARMIN GTR225A The GARMIN GTR225A is a VHF COM transceiver with 8.33kHz fre- quency channel spacing. It incorporates a number of functions that save time and effort. Provide the GTR 225 with an airport identifier and it will automatically find its frequency (and vice versa) thanks to a built- in, updateable database.
  • Page 136 G3-8 MA FM 9407 - R01 Airplane and Systems Description GARMIN GNC255A The GARMIN GNC255A is a VHF COM transceiver with 8.33kHz fre- quency channel spacing and a 200-channel VOR/LOC/GS NAV re- ceiver in one combined housing. The GNC255A also incorporates workload-reducing functions such as automatic decoding of the Morse code station identifier for VOR/LOC/ILS, most-used frequency storage in unit memory, built-in course deviation indicator and more.
  • Page 137 G3-8 MA FM 9407 - R01 Airplane and Systems Description COM/NAV display Pressing the C/N button changes display of NAV and COM frequencies. COM frequency Hit C/N first to select COM frequency band. Frequency is selected with the outer ring and inner selector of the TUNE knob.
  • Page 138 G3-8 MA FM 9407 - R01 Airplane and Systems Description PS-Engineering PAR200A The PS-Engineering PAR200A is a VHF radio with 8.33kHz spacing with integrated intercom. It can manage another radio or NAV/COM (no MKR functionality). This POH only provides basic introduction and instructions. For de- tailed data refer to the manufacturer's instruction manual that comes with your plane.
  • Page 139 G3-8 MA FM 9407 - R01 Airplane and Systems Description on/off, volume The radio is switched on and off by pushing the VOL knob. This knob also adjusts volume. frequency Frequency is selected with the outer ring and inner selector of the TUNE knob. Frequency selected is displayed in the right of the display.

  • Page 140: Intercom And Audio Panel

    G3-8 MA FM 9407 - R01 Airplane and Systems Description Intercom and Audio Panel PS-Engineering PMA8000BTi This is an audio panel with marker beacon receiver. It incorporates audio-in capability with several muting modes. The audio panel may be used with mono or stereo headsets. A common volume knob is provided for left and right seat.
  • Page 141 G3-8 MA FM 9407 - R01 Airplane and Systems Description on/off, volume The audio panel is switched on and off by pushing the VOL knob. This knob also adjusts volume. selecting NAV/COM The PMA8000BTi can manage two radios or NAV/COM. Selecting a radio from the RCV line allows monitoring to that radio.

  • Page 142: Gps Equipment

    G3-8 MA FM 9407 - R01 Airplane and Systems Description GPS Equipment Garmin aera660 und aera 796 The GPS by Garmin are prime class navigation aids with brilliant color screen and touch operation. The GPS is switched on automatically once the ignition key is set to AVIONIC. aera660 aera 796 Systems...
  • Page 143 G3-8 MA FM 9407 - R01 Airplane and Systems Description This POH only provides basic introduction and instructions. For details refer to the manufacturer's instruction manual that comes with your airplane. The website of GARMIN www.garmin.com offers the possi- bility to download the manuals. Following gestures operate the GPS: select zoom...

  • Page 144: Transponder

    G3-8 MA FM 9407 - R01 Airplane and Systems Description Transponder DYNON D600/D700 and D900/D1000 The top bar displays the transponder status as shown below: To set the transponder hit the softkey XPNDR from the main menu. The XPDR menu will now show up as follows: turns on ground mode, pressing the softkey again will put the transponder into standby mode activates Mode A, pressing the softkey again will...
  • Page 145 G3-8 MA FM 9407 - R01 Airplane and Systems Description DYNON HDX800 and HDX1100 The top bar displays the transponder status as shown below. To set the transponder touch into the top bar in the area that displays the transponder status. The XPDR control page will appear as follows: IDENT squawks ident squawks VFR...

  • Page 146: Gtn750 Gps/Nav/Com/Xpdr/Audio

    G3-8 MA FM 9407 - R01 Airplane and Systems Description 7.10 GTN750 GPS/NAV/COM/XPDR/Audio The GTN750 is an IFR navigator which integrates the functionality of a WAAS GPS with moving map, NAV/COM, transponder and audio panel. This system replaces the transponder integrated into the DY- NON SkyView system.
  • Page 147 G3-8 MA FM 9407 - R01 Airplane and Systems Description After start-up of the system the home screen appears: activated sectional map TARFFIC displays surrounding traffic (if installed) FLIGHT PLAN shows active flightplan and allows programming PROC activates IFR procedures (if database installed) NEAREST shows nearest airfields DIRECT TO...
  • Page 148 G3-8 MA FM 9407 - R01 Airplane and Systems Description active NAV frequency tap to flip active/standby frequency standby NAV frequency, tap to open menu to set new frequency tap to open audio open panel menu to select XPDR menu to act.

  • Page 149: Autopilot

    VOR (ILS is a special version of a VOR with just one radial). In the version as offered by REMOS, the autopilot does not offer VNAV, it can only hold or change a selected altitude. The autopilot does not provide vertical guidance on an ILS or GPS-based LPV ap- proaches.
  • Page 150 G3-8 MA FM 9407 - R01 Airplane and Systems Description autopilot modes The DYNON autopilot has two modes: 1. track and altitude (TRK+ALT) The autopilot keeps your selected altitude, climbs or descents to it and follows a given ground track. Setting up or even select a navigation source is not required.
  • Page 151 G3-8 MA FM 9407 - R01 Airplane and Systems Description that is displayed on the HSI from the provided source. For ex- ample, is the selected HIS source is the SkyView GPS, and there is an active flightplan, the autopilot will fly that flightplan. Or if the source is a VOR, the autopilot will seek to capture and hold se set radial to or from the VOR.
  • Page 152 G3-8 MA FM 9407 - R01 Airplane and Systems Description control wheel steering When the autopilot is engaged, press and hold the AP/DISC button on the control stick to put the autopilot into control wheel steering mode. While control wheel steering mode is active, the autopilot servos are temporarily disengaged.
  • Page 153 G3-8 MA FM 9407 - R01 Airplane and Systems Description selecting a navigation source (D600/D700 and D900/D1000) From the main menu select PFD to open the PFD menu, then hit HSI SCR to cycle the HSI through the different navigation data sources that are connected to the SkyView system.
  • Page 154 G3-8 MA FM 9407 - R01 Airplane and Systems Description select PFD TOOLS menu page Now touch HSI SRC to cycle the HSI through the different navigation data sources that are connected to the SkyView system. Other than SKYVIEW, which is the system’s internal GPS, these are all external navigation devices: external GPS or NAVCOM.
  • Page 155 G3-8 MA FM 9407 - R01 Airplane and Systems Description selecting autopilot mode (D600/D700 and D900/D1000) Open the autopilot menu from the main menu by pressing the button AUTOPILOT. Now the different modes of the autopilot may be se- lected. main menu autopilot menu BACK...
  • Page 156 G3-8 MA FM 9407 - R01 Airplane and Systems Description 180° Pressing the 180° to initiate an autopilot controlled 180 degree turn from the current track while maintaining the current altitude. After the turn the autopilot is in TRK+ALT mode. To disengage the autopilot, hit TRK+ALT, OFF or you may also hit the AP/DISC button on the control stick.
  • Page 157 G3-8 MA FM 9407 - R01 Airplane and Systems Description leave menu here select PFD TOOLS leave menu here menu page Now the different modes of the autopilot may be selected. leave menu here select autopilot mode leave menu here Systems 7 - 41...
  • Page 158 G3-8 MA FM 9407 - R01 Airplane and Systems Description EXIT or X gets you back into the main menu disengages autopilot TRK+ALT Engages autopilot in track and altitude mode. Subsequent presses of this button disengages the autopilot again. To disengage the autopilot you may also hit the AP/DISC button on the control stick.
  • Page 159 G3-8 MA FM 9407 - R01 Airplane and Systems Description adjusting altitude Click on one of the joysticks or kick it up or down and then select the ALT bug by either rotating the joystick or clicking up or down. Once the ALT bug is selected, adjust the bug and therefore altitude by rotat- ing the joystick.

  • Page 160: Electrical System

    During start-up, the avionic bus is completely separated from the en- gine bus. By this, the REMOS GXiS has does not have a dedicated avionic bus switch, bus selection is completely automatic.
  • Page 161 Next step is to set the ignition key into position ENGINE. All systems that have been offline until now are switched on. To fire up the engine the central ENGINE START button needs to be hit, the REMOS SMARTstart system takes over control during the start-up process. In cold weather, throttle should be cracked open.
  • Page 162 A magneto check in the common sense does not exist in the REMOS GXiS ; the REMOS SMARTstart takes over the check proce- dure. Once the aircraft is arrested with the parking brake, engine speed is set to 4,000 rpm and the ENGINE TEST button is hit. Follow- ing procedure is executed in the background: •...
  • Page 163 Should this not be the case, the planned flight must be cancelled. A ferry flight might be possible with special permission, ask REMOS for advice. The engine lanes LANE A and LANE B are always active as soon as the ignition switch is set to ENGINE.
  • Page 164 G3-8 MA FM 9407 - R01 Airplane and Systems Description emergency operation – single generator failure The engine needs electric power supply to be able to operate. Without sufficient electric power the engine will quit. Following vital engine sub- systems are electrically powered: dual channel injection and engine management, ignition, fuel pumps, engine instrumentation.
  • Page 165 G3-8 MA FM 9407 - R01 Airplane and Systems Description ternal backup batteries), autopilot and second ATC radio. All other air- craft systems are powered by the aircraft batteries and the excess power of the remaining generator. ATC radio and transponder are also online.
  • Page 166 All circuit breakers can be released manually. To do so, press on the circuit breaker until it releases and stands out. aircraft batteries The aircraft batteries on the REMOS GXiS have a high responsibility regarding safe flight as can be seen from the preceding descriptions.
  • Page 167 G3-8 MA FM 9407 - R01 Airplane and Systems Description The recommended battery EarthX ETX900VNT features a battery warning system that is connected to the DYNON SkyView system. Other batteries may also be installed, but in these cases the battery warning feature is not active.
  • Page 168 G3-8 MA FM 9407 - R01 Airplane and Systems Description 13.2 V … 14.6 V cell to cell charge May come on briefly dur- levels are not bal- ing periods of high current anced charging until the cells are automatically balanced.
  • Page 169 G3-8 MA FM 9407 - R01 Airplane and Systems Description overvoltage protection The aircraft is equipped with an overvoltage protection. This subsys- tem protects the aircraft systems and the avionics in case of an over- voltage event. The overvoltage protection is integrated into the PSU (power supply unit) and needs neither maintenance not operation.

  • Page 170: Engine

    G3-8 MA FM 9407 - R01 Airplane and Systems Description 7.13 Engine general The ROTAX 912 iS Sport is a horizontally opposed 4-cylinder 4-stroke spark ignition engine with electronically controlled fuel injection. The engine features one central camshaft, driving two overhead valves per cylinder by push rods and hydraulic tappets.
  • Page 171 The sight hose at the fuel tank behind the right seat is the relevant fuel GXiS indication on the REMOS There is a draining valve installed at on the fuel tank accessible from the outside belly of the fuselage behind the main landing gear. This valve is used for draining and dumping fuel.
  • Page 172 G3-8 MA FM 9407 - R01 Airplane and Systems Description Systems 7 - 56...
  • Page 173 G3-8 MA FM 9407 - R01 Airplane and Systems Description combustion air The engine is aspirated with combustion air by a NACA inlet on the right lower side of the cowling. Using a flexible hose, air is routed to the air filter. The AAPTS sensor for sensing intake air temperature and static pres- sure is installed into the NACA inlet.
  • Page 174 G3-8 MA FM 9407 - R01 Airplane and Systems Description • LSA cooling system recommended for standard operation even in higher ambient temperatures of up to app. 100°F (40°C) • tropic cooling system for operation under tropic conditions The cooling system is designed for clean oncoming airflow. This is hardly given during ground operations.
  • Page 175 -17°F (-27°C) +95°F (+35°C) -36°F (-38°C) +86°F (+30°C) cabin heating system GXiS The cabin heating system of the REMOS is powered by the wa- ter cooling system. A certain share of the coolant is fed to the cabin heat exchanger by a separate water pump. The current of water varies with heating demand and is controlled with the temperature knob in the cockpit.

  • Page 176: Propeller

    G3-8 MA FM 9407 - R01 Airplane and Systems Description 7.14 Propeller The aircraft is equipped with the DUC Hélices FLASH propeller. This is a three-blade carbon fiber, ground adjustable propeller, equipped with a plastic spinner. Although the propeller is technically spoken a ground ad- justable propeller, the owner/operator may not change NOTE prop pitch.

  • Page 177: Throttle And Brakes

    NOTE aged. 7.16 Flaps GXiS Flaps on the REMOS can be set in three positions: up, 15° for take-off and approach and 35° maximum deflection for landing. Flaps are set with the flap-shaped switch in the center of the instru- ment panel.

  • Page 178: Heating And Ventilation

    G3-8 MA FM 9407 - R01 Airplane and Systems Description 7.17 Heating and Ventilation The upper corners of the windscreen feature fresh air nozzles. These can be adjusted in outlet direction. Airstream is adjusted by rotating the front ring. Small vents are installed in the door windows. Pulling back the small handle allows opening the vents in two steps.

  • Page 179: Baggage And Luggage

    (strobes) and a landing light. All lights are using LED technology, con- GXiS ventional light bulbs are not used on the REMOS Nav- and anti-collision lights switch on automatically as long as the ignition key is set into ENGINE position. In case these lights shall in- tentionally switched off, the circuit breakers need to be released.

  • Page 180: Recovery System

    G3-8 MA FM 9407 - R01 Airplane and Systems Description 7.22 Recovery System The recovery system must be installed according to the approved pro- cedures. The belts of the system are attached to the wing’s main spar attachment fittings. They are protected against environmental condi- tions and are maintenance free.

  • Page 181: Special Equipment And Customizing

    These avionics systems may replace the equipment mentioned in this manual in part or whole. The installation of this equipment must be approved by REMOS and listed in the equipment list. For operating instructions please refer to the manuals belonging to the equipment installed.
  • Page 182 G3-8 MA FM 9407 - R01 Airplane and Systems Description intentionally left blank Systems 7 - 66...
  • Page 183 G3-8 MA FM 9408 - R01 Aircraft Ground Handling and Servicing Table of Content sect. description page Introduction Checking and Servicing Coolant Checking and Servicing Oil Servicing with Fuel Approved Coolant Grade and Specification Approved Oil Grade and Specification Approved Fuel Grade and Specification Towing 8-10 Tie-Down...

  • Page 184: Introduction

    Maintenance procedures are defined in the maintenance manual that is specific to the individual aircraft. All maintenance shall be performed according to the REMOS Service and Maintenance Checklist, available directly at REMOS or on the website www.remos.com Checking and Servicing Coolant...

  • Page 185: Servicing With Fuel

    G3-8 MA FM 9408 - R01 Aircraft Ground Handling and Servicing crankcase. The speed of rotation is not important for the pressure transfer into the crankcase. This process is finished when air is returning back to the oil tank and can be noticed by a murmur from the open oil tank.
  • Page 186 G3-8 MA FM 9408 - R01 Aircraft Ground Handling and Servicing shifting of CG The fuel tank is located behind the CG, which in return travels aft when filling the tank. Due to the CG shift during fueling it is possible that the aircraft settles on its tail.
  • Page 187 Dispose of drained or dumped fuel in an environmental correct manner. further information For further information about fuel containing ethanol please refer to the REMOS Notification NOT-001-ethanol-fuel and the ROTAX Service Instruction SI-912i-001. Aircraft Ground Handling and Servicing 8 - 5...

  • Page 188: Approved Coolant Grade And Specification

    Plus/G48. There are several coolant fluids on the market and some of them have been released by ROTAX as being suitable. However, REMOS has tested and therefore released only one specific coolant: conventional coolant with silicate- based corrosion inhibitor mixed with...

  • Page 189: Approved Oil Grade And Specification

    There are several oils on the market and some of them have been released by ROTAX as being suitable. However, REMOS has tested and therefore released only one specific oil: RON 424...

  • Page 190: Approved Fuel Grade And Specification

    . Premium automotive fuel without ethanol is recommended, though. Such fuel is often referred as MOGAS. The use of AVGAS, with or without lead, is approved on the REMOS GXiS , though fuel without lead shall be preferred as prevailing use of 100LL reduces oil change interval from 100h to 50h.
  • Page 191 Aircraft Ground Handling and Servicing At the time of releasing this POH, following fuels have been found suitable by ROTAX and have been approved by REMOS. This list may be revised by a REMOS NOTIFICATION. RON 95 (research octane number)

  • Page 192: Towing

    G3-8 MA FM 9408 - R01 Aircraft Ground Handling and Servicing Towing Due to the low weight of the REMOS GXiS , it is very easy to move the aircraft by hand on the ground. That’s why there is no special equipment for towing provided.

  • Page 193: Rigging A Folded Aircraft

    G3-8 MA FM 9408 - R01 Aircraft Ground Handling and Servicing 8.10 Rigging a Folded Aircraft The REMOS GXiS is manufactured to the highest quality standards. All components are very precise and provide the maximum aerodynamic quality. It is therefore strongly recommended that you be very careful when assembling or disassembling components such as the wings, stabilizer and other parts.
  • Page 194 When in doubt contact your local REMOS dealer or service center. Repeat steps 1 thru 8 with second wing. Aircraft Ground Handling and Servicing 8 - 12...

  • Page 195: Folding A Rigged Aircraft

    When in doubt contact your local REMOS dealer or service center. 6. Attach the tail cover and secure it with the screws provided. Connect the electric jack for the taillight.

  • Page 196: Transportation Of The Aircraft

    When the aircraft has to be moved by trailer, please ask your authorized REMOS dealer for advice. When placed on a trailer in a wrong way, serious damage could result. In any case, make sure the aircraft is properly fixed and cannot move under any circumstances.
  • Page 197 G3-8 MA FM 9408 - R01 Aircraft Ground Handling and Servicing intentionally left blank Aircraft Ground Handling and Servicing 8 - 15...
  • Page 198 Imprint Pilot Operating Handbook REMOS GXiS ASTM Edition Copyright REMOS AG © REMOS 2017, all rights reserved...
  • Page 199 REMOS GX POH Supplement – Flight Training...
  • Page 200 G3-8 MA FM 9409 - R01 Supplement Flight Training Table of Content sect. description page Introduction Take-Off Climb Cruise Stall Slip Glide Descent Approach 9-10 Touch Down 9-12 Supplement Flight Training 9 - 1...

  • Page 201: Introduction

    G3-8 MA FM 9409 - R01 Introduction This chapter should enable you to familiarize yourself with the flight GXiS performance and flight characteristics of the REMOS . To complete these instructions, please refer to the appropriate sections in the POH.

  • Page 202: Take-Off

    G3-8 MA FM 9409 - R01 Take-Off Take-off under normal conditions (comfort take-off) 1. After the pre-flight check has been completed, taxi into position. Standard take-off is with flaps up, on grass select flaps 15°. 2. Elevator trim in take-off position, i.e. 2/3 up. 3.

  • Page 203: Climb

    G3-8 MA FM 9409 - R01 Climb Climb with Best Angle of Climb With engine set to full power, establish V = 50 kIAS for any flap setting. At this airspeed, the aircraft will achieve the steepest angle of climb. During climb it is essential to monitor oil and water (CHT) temperatures.

  • Page 204: Cruise

    Cruise in gusty conditions When flying in gusty weather conditions, the normal operating airspeed V = 107 kIAS should not be exceeded for safety reasons. The REMOS GXiS offers very stable flight characteristics even in heavy weather conditions. Cruise in rain or with dirty aircraft Raindrops and bugs affect the performance of the aircraft.

  • Page 205: Stall

    G3-8 MA FM 9409 - R01 Stall The REMOS GXiS is fully controllable when flying at a wide range of airspeeds. At airspeeds below the lower speed limit, the aircraft will display very stable stall characteristics. If the airspeed is reduced by the pilot gradually pulling back on the control stick, aerodynamic buffet will occur, indicating that the aircraft is approaching the stall speed.

  • Page 206: Slip

    G3-8 MA FM 9409 - R01 Slip The slip is a very stable flight condition and is also very easy to perform. This maneuver is used to increase aerodynamic drag to enable a high rate of descent. Before establishing a slip, you have to ensure that the airspeed is within the required limits.
  • Page 207 G3-8 MA FM 9409 - R01 Gliding The aircraft can glide well with the engine off. Best glide ratios are achieved within an indicated airspeed of 60 kIAS. These speeds will establish a glide ratio of about 1:11 with the flaps retracted (0° position).

  • Page 208: Descent

    G3-8 MA FM 9409 - R01 Descent When descending from level flight it is important to monitor engine temperatures. During descent, the temperatures will decrease. The water cooling system has a thermostat installed, hence the water temperature will not drop too much. However, the oil system does not has a thermostat installed, therefore some power may be needed to maintain safe oil temperatures.

  • Page 209: Approach

    1,000 lb. Approach under tailwind conditions GXiS When on final approach with a tailwind component, the REMOS does not require different approach or flare procedures than those used in calm or headwind conditions. However, you do have to keep in mind that the landing distance will increase significantly.
  • Page 210 In doubt or without an urge to achieve shortest landing distance as GXiS possible, or when not yet familiar with the REMOS , it is recommended to keep a higher target airspeed. This will give you a reserve airspeed to balance any unexpected deviations in altitude and heading.

  • Page 211: Touchdown

    The aircraft has very good low speed characteristics and so is very controllable all the way through the landing phase. After a good GXiS approach has been conducted, the REMOS does not require much action to land with a perfect touch down. It is important to establish a safe and stable airspeed during the approach.
  • Page 212 G3-8 MA FM 9409 - R01 Imprint intentionally left blank...

  • Page 213: Supplement Flight Training

    G3-8 MA FM 9409 - R01 Imprint Pilot Operating Handbook REMOS GXiS Supplement Flight Training ASTM Edition Copyright REMOS AG © REMOS 2017, all rights reserved...
  • Page 214 REMOS GX POH Supplement – Continued Airworthiness...
  • Page 215 G3-8 MA FM 9410 - R01 Continued Airworthiness Table of Content sect. description page Purpose 10-2 Continued Airworthiness System 10-3 Owner/Operator Responsibilities 10-5 Release of Notices to the Public 10-7 Documentation Update 10-8 Maintenance and Annual Condition Inspection 10-9 Modifications or Change of Equipment 10-10 Repairs 10-12...

  • Page 216: Purpose

    G3-8 MA FM 9410 - R01 Purpose Continued Airworthiness is everything that is required to keep an aircraft in a safe condition to fly. This does not only include the technical part like maintenance and annual condition inspection. It also includes update of documentation, e.g.

  • Page 217: Continued Airworthiness System

    G3-8 MA FM 9410 - R01 Continued Airworthiness System REMOS AG shall be informed about potential issues of safety of flight or service difficulties by means of the Customer Feedback Form G3-8 MA CA 0050. This document is attached to the maintenance manual and is also available on the website www.remos.com.
  • Page 218 • decision of corrective action The continued airworthiness system of REMOS AG does not only cover events that have occurred during operation of the aircraft. Proposals for improvements or corrections, service difficulties, findings during maintenance events or annual condition inspections are also covered by the continued airworthiness system.

  • Page 219: Owner/Operator Responsibilities

    G3-8 MA FM 9410 - R01 Owner/Operator Responsibilities During handover of the aircraft the owner/operator is introduced into the continued airworthiness system of REMOS AG. The customer is informed about the following: • The maintenance handbook provides all information that the customer needs to comply with the regulations, especially with continued airworthiness and maintenance.
  • Page 220 This information is provided by means of the customer commitment form, which is part of the maintenance manual. The owner/operator shall sign this form and send it to REMOS AG. On this form the owner/operator shall also provide the manufacturer with current contact data.
  • Page 221 REMOS AG to its customers. • NOTIFICATION will be issued in case service information is required. The public is notified via the website www.remos.com which is the central means of communication of REMOS AG to its customers. Supplement Continued Airworthiness 10 - 7...

  • Page 222: Documentation Update

    Documentation Update Any documentation update will be released on the website www.remos.com Owner/operators will not be informed by postal mail, unless such a documentation update is mandatory for safety of flight and is released by a safety alert or a service bulletin. Examples for documentation updates are new revisions of: •...
  • Page 223 G3-8 MA FM 9410 - R01 Maintenance and Annual Cond. Inspection Maintenance intervals of all REMOS aircraft are 25h for the first maintenance event, followed by 100h inspections. In case that AVGAS 100LL is used for more than 30% of the time, oil change interval is reduced to 50h.

  • Page 224: Modifications Or Change Of Equipment

    A&P Mechanic or a Part 145 Repair Station with appropriate ratings after the work is accomplished. Then this LOA will be signed by the Head of Design of REMOS AG and handed out to the customer. This procedure will be performed by e-mail.
  • Page 225 G3-8 MA FM 9410 - R01 Modifications or Change of Equipment Without having updated the equipment list and weight and balance or not having changes approved by the manufacturer that are not part of the maintenance manual, the aircraft is considered not airworthy and unsafe to fly.

  • Page 226: Repairs

    Mechanic or a Part 145 Repair Station with appropriate ratings after the work is accomplished. Then this Repair Approval will be signed by the Head of Design of REMOS AG and handed out to the customer. This procedure will be performed by e-mail.
  • Page 227 G3-8 MA FM 9410 - R01 Repairs The extent of work cannot generally be defined; it is always an individual project. Working hours of the engineering department will be charged by the hour according to actual pricelists. This procedure is not intended and built up for the manufacturer to make money of it.

  • Page 228: Contact Data

    G3-8 MA FM 9410 - R01 Contact Data The manufacturer of the REMOS aircraft and the only reliable and legal source for continued airworthiness is REMOS AG Franzfelde 31 D-17309 Pasewalk G E R M A N Y Tel: +49-3973-225519-0...
  • Page 229 G3-8 MA FM 9410 - R01 Imprint Pilot Operating Handbook REMOS GXiS Supplement Continued Airwothiness ASTM Edition Copyright REMOS AG © REMOS 2017, all rights reserved...
  • Page 230 REMOS GX POH Supplement – Abbreviated Checklists...
  • Page 231 G3-8 MA FM 9411 – R01 Supplement Abbreviated Checklists intentionally left blank Supplement Flight Training 11 - 2...
  • Page 232 REMOS only. This POH supplement section 10 offers abbreviated checklists released by REMOS. By using these abbreviated checklist, the pilot in command acknowledges that the content is abbreviated and might be incomplete. Always refer to sections 3 and 4 for full version of these checklists.
  • Page 233 G3-8 MA FM 9411 – R01 Supplement Abbreviated Checklists intentionally left blank Supplement Flight Training 11 - 4...
  • Page 234 G3-8 MA FM 9411 – R01 Supplement Abbreviated Checklists CHECK BEFORE ENGINE START LANDING preflight check ......OK approach ..... BRIEFED seat belts ....FASTENED flaps .........DOWN brake ........SET approach speed ..... 60 KIAS SHUTDOWN brake ........SET ENGINE START ignition key ....
  • Page 235 G3-8 MA FM 9411 – R01 Supplement Abbreviated Checklists ABBREVIATED EMERGENCY CHECKLIST AVIATE – NAVIGATE - COMMUNICATE DECLARE EMERGENCY SPIN RECOVERY GENERATOR FAILURE engine ......... IDLE emergency switch ....ON aileron ......NEUTRAL SkyView ...... STAY ON rudder....OPPOSITE SPIN landing light ......
  • Page 236 G3-8 MA FM 9411 – R01 Imprint intentionally left blank...
  • Page 237 G3-8 MA FM 9411 – R01 Imprint GXiS Pilot Operating Handbook REMOS Abbreviated Checklists ASTM Edition Copyright REMOS AG © REMOS 2007-2017, all rights reserved...

Table of Contents
