SIMTOO Dragonfly Drone Pro Manual

Fly with GPS Watch

Instruction of RC Watch（Diagram 9）
Diagram 9：
Flight Height
Ready to fly
⑨Follow-me（press once）
Aircraft GPS Signals
16 00.0m
Stabilize
9 00:00:00
Watch GPS Signals
Time
⑩Auto-rotate（press once）
Orbit fly（press&hold）
Follow Me Mode
①Power on/off(press&hold)
Notes: Do not press two buttons at the same time which may interfere with each other.
Press the hover button first before switching one flight mode to another.
Bind to Watch
The aircraft is linked with remote controller by default before
sales. It is necessary to bind the codes again if the dragonfly is
going to be controlled with watch.
Codes Binding Procedures
Plug a small connector into the smaller needles on the gimbal
mount to make a short circuit. Turn on the aircraft and
immediately remove the connector. Then turn on the watch and
hold the take-off button and land button at the same time for a
few seconds until the watch says "Bind code begins...". The
watch will get connected with the aircraft when the screen shows
the control interface.
⑦Ascend(press&hold)
⑤Auto-take Off (press once)
Aircraft Battery Level
②Gimbal Up/Down(Rotate
Up/Down)
③Joystick
④Hover（press once）
Arm Motors（press&hold）
Watch Battery Level
⑥Auto land（press once）
Return-home（press&hold）
⑧Descend（press&hold）
Bind code Begin ... Bind code ... 0
NET ID:XXX
1 2
Preparations Pre-fly
1. Place Dragonfly on a flat platform and turn on the battery by
pressing & hold the power button on the tail. The aircraft will
immediately start self-checking when the front red LEDs lights
and rear blue LEDs quickly flashes.
2. When the blue LEDs slowly flashes and the aircraft gives out
Di-Di sound, it indicates the checking of fly control system is
completed.
3. When the gimbal is level and the aircraft gives out another
Di-Di sound, it indicates that the gimbal is ready.
4. Turn on the watch by pressing & hold the power button. In a
few seconds the watch will get connected to the aircraft when the
screen shows the control interface. Wait until the aircraft gets at
least 10 GPS satellites and an icon of "
before take-off. If the satellite signals are not stable, try it at
another place.
Notes: If dragonfly receives no instruction for 10 minutes while powered on, it will
emit an alarm sound, which is a normal. You could either unlock the motors or turn
off the battery to stop that sound.
Fly with GPS Watch
" shows on the watch
