Summary of Contents for SIMTOO Dragonfly Drone
- Page 2 Preconditions （Ⅰ）Safe Flying Tips 1.Ensure you are in an open area, most of your aircraft's abilities rely on strong GPS signal that can easily be weakened by nearby structures. 2.Put the aircraft on the flat ground. Long press the power button on the aircraft tail, when the Red indicators keep on.
- Page 3 GPS tracker. The blue indicator flashes when it’s matching. And blue indicator keeps on 1.Place Dragonfly drone on flat ground before turning on the battery. The front LED lights and “X” icon on the left bottom of watch will disappear when code-matching complete.
- Page 4 Installation Manual of Dragonfly Drone 3. If the aircraft goes unstable due to effect from the ground, weather or electrom- agnetism, press the land button immediately for an emergency landing.
- Page 5 Wing & Landing Gears Propellers Step1 Wing(as the diagram1) Step3 Propellers(as the diagram) Unfold or fold the wings: Installation of propellers(2 black pointed and 2 silver pointed) ： 1.Unfold the rear wings before folding the front wings. 1.Tighten the propeller by spinning it in the lock direction 2.
-
Page 6: Gimbal & Camera
Gimbal & Camera Gimbal & Airframe Step4 Gimbal & Camera Installation(as the diagram) Step5 Fit gimbal into airframe 1.Release the gimbal clamp 1.Fit the gimbal mount under the head of airframe. 2.Fit the camera into the gimbal holder 2.Drive a screw into the hole under the head of airframe through 3.Tighten the gimbal clamp with long screw the opening of gimbal mount. -
Page 7: Charging Cable
Battery & Airframe Charging cable Charging cable for battery, charger, watch, Step6 Fit battery into airframe(as the diagram) Step7 camera (as the diagram) Battery Installation： 1.Pull up the spring button at the airframe rear to let the battery Diagram: in or out 2.Match the battery plug with the slot on PCB before fully pushing the battery in.(as the diagram) Diagram：... - Page 8 Smart Mode - Follow me...
