- Page 1 Dragon y Pro New vision of the world USER MANUAL Shenzhen Simtoo Intelligent Technology Co., Ltd. West Industry Building A5, Park Road, Bao An District, Shenzhen, China 518000 TEL: +86 755 2373 2452 Web: www.simtoo.com Email: service@simtoo.com...
- Page 2 Precautions Safe Flying Tips 1. Fly in an open wide area without large obstacles like buidings, trees or electric wires in 30 meters as they may distort the GPS signals or crash the aircraft. Do not fly close to metal structure with strong magnetic field.
- Page 3 Box Content Assembly Box Content Step1. Charging (Diagram 1) Turn on the battery, remote controller, watch and camera to check Please go through the checklist of items below after unboxing: the battery level. Insert the AC power cord into the charger and plug into a 100-240V AC socket.
- Page 4 Assembly Assembly Step 2. Unfold the Aircraft ( Diagram 2) Step 4. Propellers ( Diagram 4) Push down the spring button under the motor arm and slowly twist Attach the silver cap propellers onto the silver motors and secure the arm till the end. them by spinning clockwise.
- Page 5 Assembly Assembly Step 5. Gimbal & Camera (Diagram 5) Step 6. Battery ( Diagram 6) Unscrew the camera strap from gimbal. Pull up the spring button at the airframe tail.Align the battery Attach the camera into the gimbal frame ( the camera lens is on with the airframe, match the battery plug with the PCB slot and the right).
- Page 6 1. Do not insert or take out the SD card while the camera is power on. The card won’t go 1.Simtoo APP requires android 4.2 or later and IOS 7.1 or later. into the slot if inserted in the opposite position.
- Page 7 Fly with Remote Controller Fly with Remote Controller Instruction of Remote Controller Prepare the remote controller 1. Drive the mobile holder into the remote, fix the nut on the screw bar to make the holder face to you. 2. Adjust the holder to your desired postion, stretch the holder Mobile Holder clamp and attach your mobile device into the clamp.
- Page 8 Fly with Remote Controller Fly with Remote Controller Prepare the aircraft Take Off 1. Place dragonfly on a flat platform and turn on the battery by 1. Activate the motors by pushing the left stick to the lower right pressing & hold the power button on the tail. Dragonfly will corner and hold it for 3 seconds.
- Page 9 Fly with Remote Controller Fly with Remote Controller Orbit Fly Land Pressing and hold will keep dragonfly moving in a 5m radius 1.Pulling down the left stick will make dragonfly land. Do not push orbit around a center at its front. The aircraft head will point to down too hard or the aircraft may crash on the ground.
- Page 10 Fly with GPS Watch Fly with GPS Watch Instruction of RC Watch Preparations Pre-fly ⑦Ascend(press once) 1. Place Dragonfly on a flat platform and turn on the battery by Follow Me Mode Gimbal Left (Press&hold) pressing & hold the power button on the tail. Dragonfly will Motors Locked Ready to fly ⑤Auto-take Off (press once)
- Page 11 Fly with GPS Watch Fly with GPS Watch One Key to Take off Orbit Fly ( Point of Interest ) Before take-off, press and hold to check if the four motors are Pressing and hold will keep dragonfly moving in a 5m rotating properly.
- Page 12 Fly with GPS Watch Fly with GPS Watch Follow Me Land After the watch gets 8 follow-me GPS satellites and show an Pressing once will make dragonfly slowly land at its “ ”, press once and start to move. Dragonfly will current spot.
- Page 13 Battery Time - 2 hours Notes: With HD transmitter, the media is stored on your mobile device. The Simtoo APP in Android version can work with HD transmitter directly. For iphone users, Notes: Do not hold the handheld gimbal while it is doing self-checking.
- Page 14 Do not fly the drone near No-fly zone according to your local regulations. Please read through the user manual and make sure your master full fly skills of dragonfly drone. Simtoo will not take any responsibilities of damage, injury or financial loss by users’ misoperation.
