GN-WLMR101
IEEE 802.11b Cardbus Wireless LAN Card
User's Manual
http://www.gigabyte.com.tw
Rev. 1.0 First Edition

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GN-WLMR101 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gigabyte GN-WLMR101

Summary of Contents for Gigabyte GN-WLMR101

  • Page 1 GN-WLMR101 IEEE 802.11b Cardbus Wireless LAN Card User’s Manual http://www.gigabyte.com.tw Rev. 1.0 First Edition...

  • Page 2: Table Of Contents

    Contents CHAPTER 1. PRODUCT OVERVIEW ..................1 1-1. I ...............1 NTRODUCTION TO IRELESS 1-2. F .........................1 EATURES 1-3. P ................1 HYSICAL IMENSIONS ACKAGING 1-4. LED I ....................2 NDICATING IGHT 1-5. S ....................2 YSTEM EQUIREMENTS 1-5-1. Supported Platform ......................2 1-5-2. Supported Operation System..................2 CHAPTER 2.

  • Page 3: Chapter 1. Product Overview

    Chapter 1. Product Overview 1-1. Introduction to The Wireless LAN Card This wireless Local Area Network (LAN) card is composed of the IEEE 802.11b MAC with CARDBUS interface, Baseband, radio components, and two built-in antennas. This product adopts the direct sequence spread spectrum (DSSS) technology using the DBPSK, DQPSK, and CCK modulations to provide a very stable wireless communication quality and an excellent signal receiver capability.

  • Page 4: Led Indicating Light

    1-4. LED Indicating Light Link The Link LED lights up when the adapter has an active connection. If the LED isn’t on, the adapter isn’t interfacing with the network. Act: Blinking of the Act LED indicates that both transmit and receive activity is occurring.

  • Page 5: Chapter 2. Installing The Wireless Lan Card

    Chapter 2. Installing the Wireless LAN Card 2-1. Installing The Driver & Utility Step 1: Please make sure that you don’t plug your card yet. Step 2: Insert our setup CD into your CDROM drive, the following window will pop up. Step 3: Click “Install Wireless LAN Driver”.
  • Page 6 Step 5: Insert your wireless LAN card, wait a moment, and then the following window will pop up. Step 6: Click “Yes”. Step 7: Click “OK”. Step 8: Click “OK”, and then your installation is ok.

  • Page 7: Chapter 3. Using The Utility

    Chapter 3. Using The Utility The Configuration & Monitor Utility is a powerful application that helps you to configure the card and monitor the statistics of the communication. Unlike the standard method of configuring the card via the operating system utilities (e.g. Control Panel), this application permits the dynamic modification of the configuration parameters while the card is operating.
  • Page 8 Figure 3-3. All available wireless networks You can choose any available network and click “Connect” to join it. If this network had built a security mechanism, you must to enter a correct security key (eg. WEP) before click “Connect”. If you don’t know which network to join, or you want to configure and monitor your network, you can click “Advanced”...

  • Page 9: Configuration

    Signal Strength: It shows the received signal strength from the detected wireless device. Signal Quality: It shows the quality of communication between the wireless LAN card and the associated network (In Figure 3-4, it mean linksys-11g). 3-1. Configuration The “Config” Tab contains several fields where operating parameters of the driver can be viewed or changed.

  • Page 10: Advance Configuration

    3-1-2 Available Profiles: In this field, you can click “Add” to add a available network into your available profiles. You also can click “Remove” to delete this profile or click “Set Default” to set a default associated network. Every time this card is active, it will automatically try to connect to this default network.

  • Page 11: Status

    switch to CAM mode. Once these packets are retrieved, it switches back to Power Saving status. 3-3. Status The “Status” tab shows you the information and status of the card. See figure 3-7. Figure 3-7. The information and status of the card 3-4.

  • Page 12: About

    Figure 3-8 The statistic information of packets sent and received by the card 3-5. About This tab shows you the software driver’s version. See the following window.

  • Page 13: Chapter 4. Specifications

    Full mobility and seamless roaming Security 64 and 128 bit WEP Management Utility Link Configuration for network join and statistics PHYSICAL SPECIFICATION Dimensions 118mm x 54mm x 5mm Weight 39 g Packaging Generic, Gigabyte, private labeling optional LED indicator Two LEDs indicating Activity/Link...
