- Page 1 08 27123 01- 1100TRC hood 17/5/05 4:14 pm Page 1 1100TRC Chimney Hood User & Installation Instructions...
- Page 2 08 27123 01- 1100TRC hood 17/5/05 4:14 pm Page 2...
-
Page 3: Table Of Contents
08 27123 01- 1100TRC hood 17/5/05 4:14 pm Page 3 Contents User’s Section ......... . -
Page 4: Introduction
08 27123 01- 1100TRC hood 17/5/05 4:14 pm Page 4 Introduction Our policy is one of constant development Installation and improvement. Strict accuracy of This appliance has been designed for illustrations and specifications is not use as an exhausting (air evacuation guaranteed. -
Page 5: Parts Identification
08 27123 01- 1100TRC hood 17/5/05 4:14 pm Page 5 Parts Identification Figure 1: Viewed from underneath removable slider grease filters control motor & carbon filters frame light bulb lamp covers Outlet adaptor inner chimney extension piece wall bracket adjustable... -
Page 6: Using The Hood
08 27123 01- 1100TRC hood 17/5/05 4:14 pm Page 6 Using the Hood light switch neon speed control high off on medium Figure 2: Slider controls. Important safety notes • Keep hob rings covered with pans Using the hood when switched on to avoid To switch on the hood, slide the speed damaging the hood. -
Page 7: Care And Maintenance
08 27123 01- 1100TRC hood 17/5/05 4:14 pm Page 7 Care & Maintenance Before cleaning or maintenance, Outer casing switch off the electricity supply. All external parts of the outer casing and visor can be safely cleaned with a Replacing a light bulb clean cloth wrung out in hot soapy 1. -
Page 8: Installation
08 27123 01- 1100TRC hood 17/5/05 4:14 pm Page 8 Installation Regulations and standards Mounting height Before you start please read instructions The cooker hood must be fitted at least carefully. All installations, service and 650 mm above a gas or electric hob. -
Page 9: Method 1: Re-Circulation
08 27123 01- 1100TRC hood 17/5/05 4:14 pm Page 9 Installation Method 1: Re-circulation (dual Assembly filtration) 1. Remove the grease filters. The fan draws cooking fumes through 2. Fit the carbon filter (if supplied - the washable grease filters into the... -
Page 10: Method 2: Extraction Through An Outside Wall
08 27123 01- 1100TRC hood 17/5/05 4:14 pm Page 10 Installation Method 2: Extraction through Wall vent kit and ducting an outside wall • For connecting the hood outlet The fan draws cooking fumes through adaptor to the outside wall, we... -
Page 11: Wall Fixing
08 27123 01- 1100TRC hood 17/5/05 4:14 pm Page 11 Installation Wall fixing (figures2,3,4) • Drill the holes A, as per the dimen- sions in fig 2. • Using the screws and dowels supplied with the appliance, fasten the wall bracket to the wall. -
Page 12: Electrical Connection
08 27123 01- 1100TRC hood 17/5/05 4:14 pm Page 12 Installation Electrical connection Figure 6: Typical example of a Typical example of a double double pole fused spur outlet. pole fused spur outlet This appliance is double insulated for safety and therefore does not require an earth connection to the mains inlet. -
Page 13: Frame Mounting Instructions
08 27123 01- 1100TRC hood 17/5/05 4:14 pm Page 13 Installation Frame mounting instructions 2. Side frame assembly • Connect the endcap E to the side The frame is packed separately within bar D. the cooker hood box. • From inside the hood, pass screw F through the specific hole. -
Page 14: Technical Data
08 27123 01- 1100TRC hood 17/5/05 4:14 pm Page 14 Technical Data Electricity supply Noise level (External Venting) 230 - 240V ~ 50Hz Position 3 56 dBA Position 2 51 dBA Classification Position 1 48 dBA class II metal encased... -
Page 15: Customer Support
08 27123 01- 1100TRC hood 17/5/05 4:14 pm Page 15 Customer Support In case of di culty please call our Customer Support Helpline on 0844 815 3740 When you dial this number you will hear a ringing tone. This indicates that your call has been accepted and is being held in a queue. - Page 16 08 27123 01- 1100TRC hood 17/5/05 4:14 pm Page 16 STOVES STONEY LANE, PRESCOT, MERSEYSIDE, L35 2XW 08 27123 01 © 05.2005...
