2. Cut any ties holding the Upright Wire (42) to the the right
Upright (69).
Identify the Right Handrail (72), which has a large hole in
the left side. Feed the Upright Wire (42) into the hole in
the bottom of the Right Handrail and out of the large hole
in the side. Note: It may be helpful to use needlenose pli-
ers to pull the Wire Harness out of the hole.
Attach the upper end of the Right Handrail (72) to the
right Upright (69) with a 3" Bolt (37). Do not tighten the
Bolt yet. Attach the lower end of the Right Handrail with
a 4" Bolt (98) and a 5/16" Star Washer (97). Firmly
tighten the 3" Bolt and 4" Bolt.
Attach the upper end of the Left Handrail (71) to the left
Upright (69) with a 3" Bolt (37). Do not tighten the Bolt
yet. Attach the lower end of the Left Handrail with a 4"
Bolt (98) and a 5/16" Star Washer (97). Firmly tighten
the 3" Bolt and 4" Bolt. Note: There is not a wire har-
ness on the left side.
3. With the help of another person, carefully lower the
Uprights (69) as shown. Note: It may be helpful to place
one foot on one of the Extension Legs (63) as you tip the
Uprights. Make sure that the Extension Legs remain
in the Uprights.
Attach each Extension Leg (63) with two 1" Tek Screws
(39) and a Base Pad (57) as shown. Attach the lower
Tek Screw, without the Base Pad, first.
Attach two Base Pads (57) to the base of the Uprights
(69) with two 1" Tek Screws (39).
Attach the two Wheels (66) with two 2" Bolts (64) and
two Wheel Nuts (32) as shown. Do not overtighten the
Bolts; the Wheels should be able to spin freely.
With the help of another person, carefully raise the
Uprights (69) to the vertical position.
2
37
97
3
66
64
69
63
7
71
72
69
42
Hole
37
98
69
32
32
57
39
63
57
39
Hole
69
98
97
64
66
39
57
57
39
