M43
2.4.6 Introduce the cleaning pistol into the cartridge, pull the trigger and move down to the bottom of
each cartridge.
2.4.7 Remove sticking dirt with a soft brush.
Note:
If a high-pressure cleaner is available, blast the cartridges from the outside with a fan jet nozzle.
Operating pressure of the high-pressure cleaner max. 60 bar. Cleansing agent: warm water or
water with cleansing fluid.
Attention:
When cleaning with a high-pressure cleaner, do not hold the nozzle too close to the gauze
in order to prevent damage or displacement of the gauze wires.
2.4.8 Rinse the cartridges in clean cleaning fluid, blow them out and let them dry with the opening
facing downwards.
2.4.9 Put a strong light behind the gauze and check the cleaning operation. Repeat it if necessary.
2.4.10 Install cartridges in reverse sequence as described under 2.4.3. O-ring between element plate
and cartridge must be free from cracks and deformation.
3. Check the seal between the element plate and filter housing and replace if necessary.
4. Mount filter insert in filter chamber.
5. Fit cover (replace seal).
6. Fill the filter chamber and vent it (see the plate on the filter cover).
en / 23.03.2007
Lubricating Oil Duplex Filter
Maintenance / Cleaning
IB020307
A5.05. 08.04.01.01
4/4
