- Page 1 ★ Labo K Effects – www.labo-k-effects.com – karim@labo-k-effects.com...
- Page 2 Contents CONTENTS TECHNICAL INFO OVERVIEW CONTROLS POWER SUPPLY POWER-LINK SYSTEM ADVICES TROUBLESHOOTING RECALL SHEET ★ Labo K Effects – www.labo-k-effects.com – karim@labo-k-effects.com...
-
Page 3: Technical Info
technical info COntrols ! Output level (Volume) ! Tone (Tone) ! Distortion amount (Drive) ! Behaviour (Gate) ! Colour (Bright-Warm-Deep) ! Frequency range (Fuzz-Fat-Ultra) TECHNOLOGy ! Selected components ! Robust diecast enclosure ! Cliff et Lumberg connectors specifications ! True Bypass 3PDT switch. ! Consumption 4mA. -
Page 4: Overview
As its name indicates it, the Fuzz Ultra is to be classified in the family of Fuzz. The Fuzz effect describes the sound obtained by the clipping of the signal which presents a wave of square shape. A sensible choice of components gives to this Fuzz a particular, at the same time vintage and modern, texture. -
Page 5: Controls
This setting controls the rate of signal clipping. 4. Gate This setting is the originality of the Fuzz Ultra. It offers a wide variety of effects ranging from the Gate effect (mute in the absence of signal) to the Pumping (compressor pumping style) over the staccato (mute after the attack). -
Page 6: Power Supply
Link » cord. ! 9V battery from another Labo ★ K Effects pedal via « Power- Link » cord. Notes : The power consumption of the Fuzz Ultra is 4mA what gives internal battery a comfortable lifetime. When input jack... -
Page 7: Power-Link System
power-link system The Power-Link system of Labo ★ K Effects allows an external power supply to power several Labo ★ K Effects pedals via the cable supplied with each pedal by creating a daisy chain. Using the Power-Link system of Labo ★ K Effects it is even possible to power a Labo ★... - Page 8 USE OF THE POWER-LINK CORD ★ Labo K Effects – www.labo-k-effects.com – karim@labo-k-effects.com...
-
Page 9: Advices
If an external adapter is exclusively used, it is recommended to remove the internal battery. Fuzz Ultra and wha-wha Fuzz Ultra can be positioned either before or after a wha-wha pedal. However Fuzz Ultra positioned before the wha-wha widens the sound spectre of the wha-wha. -
Page 10: Troubleshooting
troubleshooting STAGE 1 No sound comes out of the device: ! Verify that all your equipment works without the pedal. ! Insert the pedal into the chain. ! If the sound comes out in by pass mode, go directly to the stage If the sound does not comes out either in by pass mode, nor in effect mode, go directly to the stage 4 STAGE 2... -
Page 11: Recall Sheet
RECALL SHEET ★ Labo K Effects – www.labo-k-effects.com – karim@labo-k-effects.com...
