1. Introduction

About the SBC
This product, which is equipped with the Intel(R) 852GM chip set, is a PCI bus compliant half-sized
single board computer that supports
SPC-8520-LA : Capable of equipping with the Pentium(R) M 1.6G - 2.0GHz or Celeron(R) M 1.3G -
1.5GBHz.
SPC-8521-LA : Equipped with the Celeron(R) M 800MHz of the fan less type
Max. 1GB DDR SDRAM SO-DIMM support and featured all-in-one-design with a variety of interfaces,
equipped with the analog RGB, LVDS interface, also supported the Dual View
This product also equipped with a CF card slot (Type I), enabling boot-up from a CF card.
When connecting external devices or building the system, please read this manual carefully.
Features
[SPC-8520-LA]
- Supported CPU : Intel(R) Pentium(R) M processor 1.6G - 2.0GHz (FSB400MHz),
Intel(R) Celeron(R) M processor 1.3G - 1.5GHz (FSB400MHz).
[SPC-8521-LA]
- Equipped with the fan less type Intel(R) Celeron(R) M processor 800MHz (FSB400MHz) CPU
[Common]
- Half sized CPU board for the PCI and equipped with the wide variety of interface including the IDE,
USB2.0 x 2, serial x 2, parallel, PS/2, LAN, audio and so on
- Adopting the Intel(R) 852GM chip set
- Capable of equipping with Max. 1GB DDR SDRAM SO-DIMM
- Equipped with the Analog RGB and LDVS interface, supports Dual View
- Equipped with the LDVS interface, capable of connecting to the LCD display directly
- Equipped with a CF card slot (Type I), enabling boot-up from a CF card
