2. System Reference

Specifications
Table 2.1. Functional Specifications <1/2>
Type
CPU
Cache
Processor socket
Memory(Option)
Chipset
BIOS
VGA
Keyboard / Mouse connector
Serial I/F
Parallel I/F
On board expansion bus
LAN Port
IDE I/F
SATA I/F
FDD I/F
CF Slot *1
SSD Socket
USB Port
RAID
Audio
Watchdog Timer
General-purpose I/F
Hardware Monitor
SPC-8520-LA, SPC-8521-LA
SPC-8520-LA
Option:
Intel(R) Pentium(R) M Processor
1.6G - 2.0GHz (FSB400MHz),
Intel(R) Celeron(R) M Processor
1.3G - 1.5GHz (FSB400MHz)
478pin FC-PGA
Built in CPU
Socket 478
Max.1GB, 200 pin SO-DIMM socket x 1, PC2100 (DDR266) DDR SDRAM
Intel(R) 852GM + ICH4
Award BIOS, PnP support
Built in Intel 852GM
One Analog RGB I/F (One HD-SUB 15pin connector),
One LVDS(18bit) I/F (One box-header 30-pin connector)
One PS/2 keyboard/Mouse connector(Bundled the 2 in 1 cable) ,
One box-header 5-pins connector for external keyboard
16550 UART
Two box-header 10-pin connector (RS-232C x 1, RS-232C/422A/485 x 1),
Baud rate: 50 - 115,200bps (programmable)
One box-header 26-pin connector,
One high-speed parallel port, support SPP/EPP/ECP mode
None
100BASE-TX/10BASE-T, Intel ICH4 integrated controller
One RJ-45 connector, Wake On LAN support
One IDE port, up to two IDE devices,
One box-header 40-pin connector, support Ultra DMA 33/66/100
None
One FDD port, up to two floppy drives (720KB, 1,44MB, 2.88MB),
One box-header 34-pin connector, 3.5inch 2mode I/F.
Type I x 1, IDE secondary port connection, Support booting
None
2ch USB2.0 compliant ports, Two USB Type A connectors (on bracket)
None
AC97 CODEC, One pin-header 10-pin connector for line-out, line-in, microphone-in.
1 - 255sec, 255 level
When time up: RESET
None
Monitoring of the temperature of CPU and board, power supply voltage, and fan speed
(Function of the Winbond W83627HG)
2. System Reference
SPC-8521-LA
Intel(R) Celeron(R) M Processor 800MHz
(FSB400MHz)
(Fan less mounting)
None
None
