- Page 1 FCC ID : BEJM1940AB APPENDIX F : USER’S MANUAL 1 / 50...
-
Page 2: Regulatory Information
Regulatory Information FCC Compliance Statement CE Conformity Notice (for Europe) This equipment has been tested and found to comply within Products with the “ C E ” Marking comply with the EMC the limits of a Class B digital device pursuant to Part 15 of Directive(89/336/EEC) and LOW VOLTAGE Directive the FCC Rules. - Page 3 Regulatory Information cont. scheme, which provides for international environmental Lead can be found in picture tubes, display screens, solder, labelling of personal computers. The labelling scheme was and capacitors. Lead damages the nervous system and in developed as a joint effort by the TCO (The Swedish higher doses causes lead poisoning.
- Page 4 Regulatory Information cont. TCO99 The energy requirements include a demand that the computer and/or display, after a certain period of inactivity, shall reduce its power consumption to a lower level in one or more stages. The length of time to reactivate the computer shall be reasonable for Congratulations! the user.
- Page 5 (U.S.A only) is a set of power-saving guidelines NERGY issued by the U.S. Environmental Protection Agency(EPA). As an ENERGY STAR Partner LG Electronics U.S.A.,Inc. has determined that this product meets the ENERGY STAR guidelines for energy efficiency. EPA POLLUTION PREVENTER...
- Page 6 M1740A/M1940A/M2040A User's Guide Please read this manual carefully before operating your set. Retain it for future reference. Record model number and serial number of the set. See the label attached on the back cover and quote this information to your dealer when you require service.
- Page 7 Table of Contents Safety Precautions Installation Accessories Before Connecting to the PC Connection Name and Function of the Parts Connecting to External Devices Connecting to your PC Watching Video Watching TV Selecting and Adjusting the Screen Input OSD (On Screen Display) Screen Tracking Order Selection Set/Selects the channel when using the TV and Tracking...
- Page 8 Safety Precautions Please read these safety precautions carefully before using If you ignore the warning message, you may be seriously injured or there is a possibility of Warning accident or death. Caution If you ignore the caution message, you may be slightly injured or the product may be damaged Precautions in installing the Monitor Warning Keep away from heat sources like electrical heaters.
- Page 9 Electrical Power Related Precautions Warning Make sure to connect the power cable to the grounded current. - You may be electrocuted or injured. Use the rated voltage only. - The monitor can be damaged, or you may be electrocuted. During a thunder or lightning storm, unplug the power cable or signal cable. - You may be electrocuted or a fire can break out.
- Page 10 Safety Precautions Caution Do not shock the monitor when moving it. - You may be electrocuted or the monitor can be damaged Do not dispose the product-packing box. Use it when you move. Make the panel face forward and hold it with both hands to move. - If you drop the monitor, the damaged monitor can cause electric shock or fire.
- Page 11 Accessories Please check the accessories in the product package. * The monitor and the accessories can be different from the figures shown here. Remote Control User’s Manual/ Power Cord /Batteries (AAA x 2) Cards/Driver Diskette D-SUB Signal Cable DVI-D Signal Cable Audio Cable (PC) Back cap Inserting batteries into remote controller.
- Page 12 Before Connecting to the PC Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Unfolding the stand base Place the product with its front facing downward on a cushion or soft cloth. Hold down the release button inside the stand and strongly pull out the stand with your two hands.
- Page 13 To arrange the cables After connecting the cables neatly, arrange the cables to the Cable Holder as shown in the following figure. Cable Holder Push the back cap shown in the following figure. Back Cap For remove the back cap, N o t e Pull it shown in the following figure.
- Page 14 TV: Automatic TV channel setup Button PC: Automatic adjustment function Operational at the TV mode only (Operational for the analog signal only) Sound Mode Select Select the sound mode : MONO/STEREO/SAP CAPTION Button (See A33) Video Operation Button Applicable for LG products only...
- Page 15 • Input Select Button • TV/AV Button If you press the button once, This button will be enabled only the following Input Signal when you selected the TV/AV Window will appear. Select signal. The signal type will be the signal type you want changed with the following order.
- Page 16 Name and Function of the Parts Swap Button You can swap the main screen and the sub-screen when the PIP/POP/PBP function is used.. SWAP SWAP When 'Input Signal 1' comes on in the main screen, only 'Input Signal 2' can be displayed on the sub-screen. On the contrary, if the main screen displays 'Input Signal 2', the sub-screen can display 'Input Signal 1' only.
-
Page 17: Rear View
Rear View Audio Audio S-Video Audio ANT IN Audio Audio ANT IN Audio Theft prevention locking device Power Cord Connector : Connect the power cord AV Input Terminal TV Tuner Jack: Connect the antenna. DVI Signal Connector D-SUB Analogue Signal Connector Audio Jack :Connect to the jack in the PC sound card. - Page 18 Name and Function of the Parts AV Input Terminal Audio Audio AV(CVBS) Input Terminal(Audio) S-Video AV(CVBS) Input Terminal(Video) S-Video Input Terminal Headphone/Earphone Connection Terminal Connecting the sound card output terminal • Make sure to check the sound card connection terminal in the PC before connecting to the monitor. If the PC sound card supports both Speaker Out and Line Out, change it to Line Out by setting the jumper or the PC application.
- Page 19 Connecting to External Devices When Connecting to your PC First of all, see if the computer, product and the peripherals are turned off. Then, connect the signal input cable. When connecting with the DVI signal input cable. When connecting with the D-SUB signal input cable. (IBM compatible PC) When connecting with the D-SUB signal input cable.
- Page 20 Connecting to External Devices Turn on power by touching the Power On/Off sensor on the product. Power On/Off sensor Turn on the PC. Select an input signal. Press the Input Select button on the remote controller to select the input signal. Or, press the SOURCE button at the front side of the monitor.
- Page 21 When watching VCR Connect the video cable as shown in the below figure and then connect the power cord (See page A12). When connecting with an RCA cable. Connect the input terminal with a proper color match. (Video – Yellow, Sound (left) – •...
- Page 22 Connecting to External Devices When watching DVD Connect the video/audio cable as shown in the below figure and then, connect the power cord (See page A12). When connecting with an Comonent cable. Connect the input terminal with a proper color match. •...
- Page 23 When watching TV See if the antenna cable is connected at the rear side of the monitor and then, connect the power cord . Audio Audio S-Video Audio ANT IN Audio Rear side of the Product Audio ANT IN Audio Antenna Cable (Not Included) Select an input signal.
- Page 24 Selecting and Adjusting the Screen Name of the Buttons in the Screen Adjustment Unit SOURCE MENU < VOL > AUTO/SELECT • This indicator lights up blue when the display operates normally. If the Power LED display is in DPM (Energy Saving) mode, this indicator color changes to amber.
-
Page 25: Source Button
Name of the Buttons in the Screen Adjustment Unit [For PC Analogue signal-RGB] AUTO/SELECT Button Auto In progress [For TV] Auto In progress ----- [Other signals] • The current signal and mode information will be displayed. SOURCE Button • Select the input signal INPUT SELECT Television Composite video... -
Page 26: Osd Menu
Selecting and Adjusting the Screen OSD Menu Icon Function Description Set/Selects the channel. STATION Adjusts screen brightness, contrast and color that you prefer. PICTURE Adjusts the audio function. SOUND Adjusts the timer function. TIMER Adjusts the screen status according to the circumstances. SPECIAL Adjusts the screen video. -
Page 27: How To Adjust The Screen Automatically
How to adjust the OSD (On Screen Display) screen. Move where Pops up the Select a menu icon Adjust the status Save/Select Exit from the you want to menu screen adjustment menu screen. adjust • Use the remote controller to adjust the OSD screen. Press the MENU Button, then the main menu of the OSD appears. - Page 28 Selecting and Adjusting the Screen Set/Selects the channel when using the TV STATION EZ Scan Manual Prog MENU Prev EZ Scan To automatically search the available STATION TV channels. EZ Scan To start Manual Prog MENU Prev To Start Press button to start automatic programming.
- Page 29 Adjusting the picture function EZ Video PICTURE EZ Video Dynamic TV/AV1/AV2/S-Video input only Standard Mild Game User MENU Prev The EZ Video function automatically adjusts the screen image quality depending on the AV/TV usage environment. • Dynamic : Select this option to display with a sharp image. •...
- Page 30 Selecting and Adjusting the Screen Adjusting the picture function RGB PC / DVI PC input only PICTURE EZ Video 6500K • 6500K/9300K 9300K Selecting a factory setting color set. 6500K: Slightly reddish white. User 9300K: Slightly bluish white. • User : Select this option to use the user-defined settings.
- Page 31 Adjusting the sound function EZ Audio SOUND • Flat The most commanding and natural audio. EZ Audio Flat • Music Balance Music Select this option to enjoy the original sound when listening to the music. Movie SRS WOW • Movie Speech Select this option to enjoy sublime sound.
-
Page 32: Adjusting The Timer Function
Selecting and Adjusting the Screen Adjusting the timer function Auto Clock Setup Clock This function is used to set up of current time. TIMER You must set the time correctly before using on/off timer function. 1) Press the MENU button and then use button to select the Clock TIMER menu. - Page 33 Adjusting the special function SPECIAL If you press the ?? button Input once, the following Input Key lock Video Signal Window will appear. language S-Video Select the signal type you Power indicator Component Transparency want using the button. Zoom Reset MENU Prev key lock...
-
Page 34: Closed Captions
Selecting and Adjusting the Screen Closed Captions Closed captioning is a process which converts the audio portion of a television program into written words which then appear as subtitles on the television screen. Closed captions allow viewers to read the dialogue and narration of television programs. - Page 35 V-CHIP rating and categories - Rating guidelines are provided by broadcast station. Most television programs and television movies can be blocked by TV rating and/or individual categories. Movies that have been shown at the theaters or direct-to-video movies use the Movies Rating System(MPAA) only. For movies previously shown in theaters.
-
Page 36: Selecting The Options
Selecting and Adjusting the Screen Selecting the options (To adjust the CAPTION & VCHIP function) PARENTAL MPAA Set Password Enter code Age block This menu is to be used to change password. Content block - - - - Once the correct current password is entered Set password using the number panel in a remote control, the Lock on/off... - Page 37 Selecting the options (To adjust the CAPTION & VCHIP function - Canadian Only) V-CHIP rating and categories (Optional) - Canadian Rating System - Rating guidelines are provided by broadcast station. Most television programs and television movies can be blocked by TV rating and/or individual categories. Canadian English PARENTAL...
- Page 38 Selecting and Adjusting the Screen Adjusting Screen CLOCK/PHASE and Position(only PC) SCREEN Auto-configure Clock Phase Position To select the image size of SCREEN the screen. Auto Auto-configure Full Full / 4:3 / 16:9 / Zoom In Clock only TV/AV1/AV2/S-Video Phase Spectacle 4:3 aspect ratios is not Position...
- Page 39 PIP/POP/PBP Mode (Multiple Screen) Functions PIP/POP/PBP On/Off Source Size Image Sound Position Swap MENU Prev On/Off After selecting PIP/POP/PBP in the PIP On/Off menu, the following menu items can be adjusted. After selecting PIP/POP/PBP in the POP On/Off menu, the following menu items can be adjusted. After selecting PIP/POP/PBP in the PBP On/Off menu, the following menu items can be adjusted.
- Page 40 Selecting and Adjusting the Screen PIP/POP/PBP Mode (Multiple Screen) Functions Position To adjust the position to PIP/POP/PBP PIP screen. On/Off Source Size Image Sound Position Swap MENU Prev To switch the main- Swap PIP/POP/PBP screen and sub-screen On/Off in PIP/POP/PBP mode. Source Size Image...
-
Page 41: Troubleshooting
Troubleshooting No image is displayed Is the product power cord • See if the power cord is properly connected to the connected? outlet. Does the power LED is turned on? • See if the power switch is turned on. Power is on, power LED is green but •... - Page 42 Troubleshooting The screen image looks abnormal. • D-SUB analog signal – Press the “AUTO” button Is the screen position wrong? in the remote controller to automatically select the optimal screen status that fits into the current mode. If adjustment is not satisfactory, use the Position menu in OSD .
- Page 43 The audio function does not work. No sound? • See if the audio cable is connected properly. • Adjust the volume. • See if the sound is set properly. No sound is available when the • See if the sound is set to On in the PIP/POP/PBP PIP/POP/PBP mode is engaged.
- Page 44 Specifications [17 inches] LCD Panel Screen Type 17 inches (431.8mm) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel Visible diagonal size: 431.8mm Pixel Pitch 0.264mm Video Signal Max. Resolution 1280X1024 @75Hz Recommended Resolution 1280X1024 @60Hz Horizontal Frequency D-SUB : 30 - 83 kHz DVI-D : 30 - 71 kHz Vertical Frequency 56 - 75 Hz...
- Page 45 [19 inches] LCD Panel Screen Type 19 inches (482.6mm) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel Visible diagonal size: 482.6mm Pixel Pitch 0.294mm Video Signal Max. Resolution 1280X1024 @75Hz Recommended Resolution 1280X1024 @60Hz Horizontal Frequency D-SUB : 30 - 83 kHz DVI-D : 30 - 71 kHz Vertical Frequency 56 - 75 Hz...
- Page 46 Specifications [20.1 inches] LCD Panel Screen Type 20.1 inches (510mm) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel Visible diagonal size: 510mm Pixel Pitch 0.2805mm Video Signal Max. Resolution 1600X1200 @60Hz Recommended Resolution 1600X1200 @60Hz Horizontal Frequency D-SUB : 30 - 92 kHz DVI-D : 30 - 80 kHz Vertical Frequency 56 - 85 Hz...
-
Page 47: Power Led
PC Mode – Preset Mode [17, 19 inches] Horizontal Vertical Horizontal Vertical Preset mode Frequency Frequency Frequency Frequency Preset mode (kHz) (Hz) (kHz) (Hz) 31.469 640 x 350 VESA 1024 x 768 48.363 31.468 720 x 400 VESA 1024 x 768 60.123 31.469 640 x 480... -
Page 48: Vesa Wall Mounting
Specifications VESA wall mounting VESA wall mounting Connected to another object (stand type and wall-mounted type. This monitor accepts a VESA-compliant mounting interfacepad.optional) For further information, refer to the VESA Wall Mounting Instruction Guide. Theft prevention locking device Audio Audio S-Video ANT IN Audio... - Page 50 http://www.lge.com P/NO. : 3828TUL289S(0412-REV00) Printed in Korea...
