LG M1921A User Manual
Hide thumbs
Also See for M1921A:
- User manual (41 pages) ,
- Service manual (38 pages) ,
- Brochure (34 pages)
Table of Contents
Advertisement
Advertisement
Table of Contents
Related Manuals for LG M1921A
Summary of Contents for LG M1921A
- Page 1 User’s Guide M1721A M1921A ake sure to read the Safety Precautions before using the product. Keep the User's Guide(CD) in an accessible place for furture reference. ee the label attached on the product and give the information to your dealer when you ask...
-
Page 2: Safety Precautions
Safety Precautions Please read these safety precautions carefully before using the product. If you ignore the warning message, you may be seriously injured or there is a possibility of Warning accident or death. Caution If you ignore the caution message, you may be slightly injured or the product may be damaged Precautions in installing the Product Warning Keep away from heat sources like electrical heaters. -
Page 3: Precautions In Moving The Product
Safety Precautions Electrical Power Related Precautions Warning Make sure to connect the power cable to the grounded current. - You may be electrocuted or injured. Use the rated voltage only. - The product can be damaged, or you may be electrocuted. During a thunder or lightning storm, unplug the power cable or signal cable. - Page 4 Safety Precautions Caution Do not shock the product when moving it. - You may be electrocuted or the product can be damaged. Do not dispose the product-packing box. Use it when you move. Make the panel face forward and hold it with both hands to move. - If you drop the product, the damaged product can cause electric shock or fire.
-
Page 5: Before Connecting To The Pc
Before Connecting to the PC Connecting the stand Before setting up the product, ensure that the power supply, the computer system, and other attached devices is turned off. Place the monitor with its front facing downward on a soft cloth. Connect the Stand Base to the Stand Body and press latches at the button toward each end. -
Page 6: Positioning Your Display
Before Connecting to the PC Before setting up the product, ensure that the power supply, the computer system, and other attached devices is turned off. Positioning your display Adjust the position of the panel in various ways for maximum comfort. Tilt Range : -5˚~15˚... -
Page 7: Name And Function Of The Parts
Name and Function of the Parts Name of the Remote Control Buttons (Atype) MUTE POWER TV : TV button MUTE POWER INPUT Input Each time you press the Input INPUT I/II button it will change to LIST Q.VIEW MENU If nothing is inputted for several seconds the screen will automatically move to the selected menu. -
Page 8: Number Buttons
Name and Function of the Parts LIST : Programme list MUTE POWER To display the programme list (0~ 99). Programme List INPUT I/II C 01 C 07 C 35 C 50 C 05 C 51 LIST Q.VIEW MENU C 11 C 41 C 04 C 63... - Page 9 Name and Function of the Parts Remote Control - Using the Teletext function Please select your local teletext language. (page A28) If you don't, the teletext may not appear correctly on the screen. LIST Q.VIEW MENU TEXT To select the teletext on or off. The main index page or the last selected page appears on the screen together with an information headline and an option line at the bottom of the screen.
- Page 10 Name and Function of the Parts Remote Control - Using the Teletext function UPDATE Press the button to appear the TV programme. At the top of screen indicates that you are still in the teletext mode. Before interrupting teletext, you may select a page number. When the page has been found, the information line appears briefly on your screen.
- Page 11 Name and Function of the Parts Name of the Remote Control Buttons (Btype) TV : TV button POWER INPUT POWER INPUT MUTE Input Each time you press the Input button it will change to If nothing is inputted for several seconds the screen will automatically move to the selected menu.
- Page 12 Name and Function of the Parts Name of the Remote Control Buttons I/II : Bilingual choice and sound mode selection POWER INPUT [TV] To switch from Stereo to Mono sound in case of stereo transmission, or from Nicam Stereo to Nicam Mono, in case of digital transmission. MUTE to switch from Nicam Dual I to Nicam Dual II or Nicam Dual I+II in case of Nicam Dual transmission.
-
Page 13: Name Of The Remote Control Buttons
Name and Function of the Parts Name of the Remote Control Buttons LIST Q.VIEW PR ( ) Buttons Able to change channel. VOL ( ) Buttons Able to adjust sound. OK Button Use when functional adjustment is completed. MENU TEXT Use this button to enter the On Screen Display menu. - Page 14 Name and Function of the Parts Remote Control - Using the Teletext function Please select your local teletext language. (page 28) If you don't, the teletext may not appear correctly on the screen. Yellow key Favourite Program On : Rotate favourite channel Favourite Program Off : To display the previously selected TV channel.
- Page 15 Name and Function of the Parts Remote Control - Using the Teletext function REVEAL Press the button to reveal/conceal the hidden information, such as solutions to riddles and puzzles. Press this button again to remove the information from the display. TEXT INDEX To display the main index.
-
Page 16: Rear View
Name and Function of the Parts Rear View ANTENNA IN RGB (PC/DTV) IN AUDIO (RGB) IN AUDIO VIDEO S-VIDEO (Mono) AV IN 2 ANTENNA IN RGB (PC/DTV) IN AUDIO (RGB) IN AUDIO VIDEO S-VIDEO (Mono) AV IN 2 Power Connector : Connect the power cord. SCART Input/Output Terminal AV Input Terminal D-Sub Analog Signal Connector... - Page 17 Name and Function of the Parts AV Input Terminal (RGB) IN AUDIO VIDEO S-VIDEO (Mono) AV IN 2 Video Input Terminal Audio Input Terminal S-Video Input Terminal...
-
Page 18: Connecting To External Devices
Connecting to External Devices Connecting to your PC First of all, see if the computer, product and the peripherals are turned off. Then, connect the signal input cable. Rear side of the product. ANTENNA IN RGB (PC/DTV) IN AUDIO (RGB) IN VIDEO AUDIO S-VIDEO... - Page 19 Connecting to External Devices Connect the power cord. Rear side of the product. ANTENNA IN RGB (PC/DTV) IN AUDIO (RGB) IN AUDIO VIDEO S-VIDEO (Mono) AV IN 2 Turn on power by pressing the power button on the product. INPUT MENU Power button Turn on the PC.
-
Page 20: Connecting To Vcr/Dvd
Connecting to External Devices Connecting to VCR/DVD Connect the video/audio cable as shown in the figure below and then connect the power cord (See page 18). When using the S-Video cable. When using the RCA cable. Connect to the S-Video input terminal to Connect the input terminal with a •... - Page 21 Connecting to External Devices When using the SCART cable. Rear side of the Product SCART Cable Please, use shielded scart cable. (Not Included) VCR / DVD Select an input signal. Press the INPUT button on the remote control to select the input signal. INPUT Or, press the INPUT button at the topside of the product.
-
Page 22: Connecting To Dvd/Set-Top Box
Connecting to External Devices Connecting to DVD/SET-TOP BOX Connect the D-sub cable, RCA/PC cable as shown in the below figure and then connect the power cord. (see page 18) [Rear side of the Product] AUDIO RGB PC/DTV IN (RGB) IN RCA-Stereo cable (not included) D-Sub cable... -
Page 23: When Watching Tv
Connecting to External Devices When Watching TV Check if the antenna cable is connected at the rear side of the product and then, connect the power cord. Rear Side of the Product ANTENNA IN RGB (PC/DTV) IN AUDIO (RGB) IN VIDEO AUDIO S-VIDEO... -
Page 24: To Arrange Cables Using Cable Management
To arrange cables using cable management Arrange the cables in the center as shown in the following picture. Fit the cable management to the Holder Groove downwards. cable management Hold the cable management and lift up slightly to remove it. Warning •... -
Page 25: Adjusting The Screen
Adjusting the Screen Name of the Buttons in the Screen Adjustment Unit ANTENNA IN RGB (PC/DTV) IN AUDIO (RGB) IN VIDEO AUDIO S-VIDEO (Mono) AV IN 2 INPUT MENU • This Indicator lights up green when the display operates normally Power Indicator (On Mode). -
Page 26: Input Button
Adjusting the Screen Name of the Buttons in the Screen Adjustment Unit • OK button is usually used in choosing the MENU. OK Button When there is no MENU on the screen pushing the OK button will give the information about the current input source. Input INPUT Button Television... -
Page 27: Osd (On-Screen Display) Menu
Adjusting the Screen OSD (On Screen Display) Menu Icon Function Description Set/Select the channel when using the TV Station Adjusting the picture function. Picture Adjusting the sound function. Sound Adjusting the time function. Time Selecting the special function. Special Adjusting the screen function. Screen Note OSD(On Screen Display) -
Page 28: Osd (On Screen Display) Screen Tracking Order
Adjusting the Screen OSD (On Screen Display) Screen Tracking Order A type MENU MENU Pop up the Move where Select a menu icon Adjust the status Save Exit from the you want to menu screen adjustment menu screen. adjust • Use the remote control to adjust the OSD screen. B type Pop up the Move where... -
Page 29: On-Screen Menu Language / Country Selection
Adjusting the Screen On-Screen Menu Language / Country Selection Installation guide menu appears on product screen when it is turned on for the first time. I n s t a l l a t i o n g u i d e Language Chesky Nederlands... -
Page 30: Station Id Set/Select The Channel When Using The Tv
Adjusting the Screen STATION ID set/Select the channel when using the TV Auto programme Station Auto programme To set Manual programme Programme edit Favourite programme OK MENU System It should be set before run auto searching. Press the buttons to select the TV system of the country or part of the world from where you want to receive the TV channels. - Page 31 Adjusting the Screen STATION ID set/Select the channel when using the TV Press the buttons to select VHF/UHF for aerial channels or Cable for Band cable channels. To select the channel reception type. : VHF/UHF / Cable. If you know the channel number, enter it directly with the digit buttons 0 to Channel In case of poor reception, you can improve the reception by fine tuning.
- Page 32 Adjusting the Screen STATION ID set/Select the channel when using the TV Favourite Station programme _ _ _ _ _ Auto programme _ _ _ _ _ _ _ _ _ _ Manual programme _ _ _ _ _ Programme edit _ _ _ _ _ Favourite programme _ _ _ _ _...
- Page 33 Adjusting the Screen PICTURE ID adjust the picture function (RGB-PC) The PSM function automatically adjusts the screen Picture image quality. (It is not working in PC input.) • Dynamic Dynamic Select this option to display with a sharp image. Standard •...
- Page 34 Adjusting the Screen PICTURE ID adjust the picture function (TV/Video/RGB-DTV) The PSM function automatically adjusts the screen Picture image quality. • Dynamic Dynamic Select this option to display with a sharp image. Standard • Standard Reset Mild The most general and natural screen display status. Game •...
-
Page 35: Sound Id To Adjust The Sound Function
Adjusting the Screen SOUND ID to adjust the sound function Sound Flat Music Balance Movie Sports User OK MENU The best sound tone quality will be selected automatically depending on the video type that you're currently watching. • Flat : The most commanding and natural audio. •... -
Page 36: Time Id To Adjust The Time Function
Adjusting the Screen TIME ID to adjust the time function Time -- : -- Clock Off time On time Auto sleep OK MENU This function is used to set up of current time. Clock You must set the time correctly before using On/Off time function. 1) Press the MENU button and then use button to select the Time menu. -
Page 37: Special Id To Select The Special Function
Adjusting the Screen SPECIAL ID to Select the special function Special Language Country Child lock DDC-CI OK MENU To choose the language in which the control names are displayed. Language Country Please select your local teletext language. If you don't, the teletext may not appear correctly on the screen. This feature is not available in all countries. -
Page 38: Screen Id To Adjust The Screen Function
Adjusting the Screen SCREEN ID to adjust the screen function Screen Auto config. To set Manual config. Reset OK MENU Auto This button is for the automatic adjustment of the screen Position, Clock and Phase. (It is not working in RGB) config. -
Page 39: Troubleshooting
Troubleshooting No image is displayed G Is the product's power cord • Check if the power cord is properly connected to the outlet. connected? G Is the power indicator turning on? • See if the power switch is turned on. G Power is on, power indicator is •... -
Page 40: The Screen Image Looks Abnormal
Troubleshooting The screen image looks abnormal. G Is the screen position wrong? • Adjust the Position menu in OSD . • See if the video card resolution and frequency are supported by the product. If the frequency is out of range, set to the recommended resolution in the Control Panel –... -
Page 41: The Audio Function Does Not Work
Troubleshooting The audio function does not work. G No sound? • Check if the audio cable is connected properly. • Adjust the volume. • Check if the sound is set properly. G Sound is too low. • Adjust the volume. The TV function does not work. -
Page 42: Specifications
Specifications The product specifications can change without prior notice for product improvement. [17 inch] LCD Panel Screen Type 17 inches (43.27 cm) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel Visible diagonal size: 43.27 cm Pixel Pitch 0.264 mm Video Signal Max. - Page 43 Specifications The product specifications can change without prior notice for product improvement. [19 inch] LCD Panel Screen Type 19 inches (48.19 cm) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel Visible diagonal size: 48.19 cm Pixel Pitch 0.294 mm Video Signal Max.
-
Page 44: Power Indicator
Specifications PC Mode – Preset Mode [17 inch] [19 inch] Horizontal Vertical Horizontal Vertical Preset mode Frequency Frequency Frequency Frequency Preset mode (kHz) (Hz) (kHz) (Hz) 31.469 640 x 350 VESA 1024 x 768 48.363 31.468 720 x 400 VESA 1024 x 768 60.123 31.469... - Page 45 Specifications VESA wall mounting This product meets VESA-compliant mounting interface pad specifications. Put the product on a piece of cloth or other soft surface with the front side facing downward. Pullout the stand as shown in the picture. Fasten the screw on the backside of the product and the other one in the joint of the stand. Install the VESA standard wall mounting.
