addresses of the current Default Gateway, along with Wired
Gateway SNMP information and Receive Transmit statistics.
Configure SNMP for the most complete results. Tap the TOOLS
button
Tap the DHCP Server to view the process and results of

acquiring an IP address via DHCP on the wired connection.
Tap the DNS Server button to view the performance of DNS

servers resolving the specified URL.
Tap the Discovery icon to see devices discovered in the

broadcast domain.
The Nearest Switch is located below the network infrastructure
tests.
Tap the Nearest Switch to show the switch name, model, port

and VLAN of the wired connection. If SNMP is enabled,
additional information is available.
The media tests are next as you move down the screen.
Cable/Link provides:

·
unterminated cable length.
·
detects shorts, opens, splits, or good termination for each pair.
·
link speed and duplex.
The following icons are at the bottom of the screen.
TOOLS

The IP address is shown to the left of the OneTouch Instrument

icon.
Tap the OneTouch AT 10G instrument icon for network

connection details, errors, statistics, and more.
The Test button

tests and user tests.

How to Run an AutoTest

AutoTest provides a comprehensive test of network infrastructure
tests, along with user-defined tests.
The OneTouch analyzer does not initiate any link, user test, or
infrastructure test activity until you run AutoTest.
1. Power the Analyzer
Connect the AC adapter to charge the battery if necessary.
2. Connect to the Network
Connect the network under test to a port (Items
You can use the RJ45 Ethernet jack for copper cable, or an SFP+
inserted in the SFP+ receptacle for fiber cable.
3. Run AutoTest
Tap the
The OneTouch analyzer will:
Link on active port (fiber or copper)

, then tap Analysis.
are discussed later in this document.
initiates link and runs infrastructure
icon or press the AutoTest key (on the front panel).
or in Figure 1).
 
