Mix 51 Surround Panning and
Mixing plug-in for Pro Tools™
Version 1.1 for Pro Tools HD/LE/M-Powered
Systems on Macintosh OS X and Windows XP
Copyright
This guide is copyrighted ©2007 by Neyrinck with all
rights reserved. Under copyright laws, this guide
may not be duplicated in whole or in part without
the written consent of Neyrinck.
Trademarks
"DIGIDESIGN", "PRO TOOLS", "PRO TOOLS
HD","PRO TOOLS LE", and "PRO TOOLS M-
POWERED" are trademarks or registered trademarks
of Avid Technology, Inc.
Dolby and Pro Logic are trademarks of Dolby
Laboratories, Inc.
Disclaimers
Plug-In Users Guide
Created By Neyrinck
San Francisco, CA USA
Technical Support (USA)
support@neyrinck.com
Product Information (USA)
Product features, specifications, system requirements
and availability are subject to change without notice.
www.neyrinck.com
info@neyrinck.com
www.neyrinck.com
www.neyrinck.com
info@neyrinck.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO TOOLS MIX 51 and is the answer not in the manual?

Questions and answers

Summary of Contents for Avid Technology PRO TOOLS MIX 51

  • Page 1 Neyrinck. Trademarks “DIGIDESIGN”, “PRO TOOLS”, “PRO TOOLS HD”,“PRO TOOLS LE”, and “PRO TOOLS M- POWERED” are trademarks or registered trademarks of Avid Technology, Inc. Dolby and Pro Logic are trademarks of Dolby Laboratories, Inc. Disclaimers Plug-In Users Guide...
  • Page 2 Table Of Contents Chapter 1 Introduction Welcome System Requirements Important Latency Information Chapter 2 Installation Installing Mix 51 Authorizing Mix 51 Removing Expired Plug-Ins Chapter 3 Quick Start Guide Chapter 4 Surround Mixer Plug-In Overview Connecting the Outputs Description and Use Of Controls Chapter 5 Surround Panner Plug-In Overview...
  • Page 3: Chapter 1 Introduction

    Chapter 1 Introduction Welcome To Mix 51 Mix 51 is a suite of 5.1 surround panning and mixing plug-ins for Pro Tools LE and M-Powered systems with six or more outputs such as Mbox 2 Pro, 002, 003, and M-Audio interfaces such as the Delta 1010 or FireWire 410 or for use with stereo output systems such as Mbox...
  • Page 4 such as 002, 003, or Mbox 2 Pro or a stereo interface connected to a 5.1 Pro Logic II decoding system. Important Latency Information Mix 51 uses the host CPU to perform the surround panning and mixing. It introduces latency that is equivalent to one buffer of audio based on the Pro Tools H/W Buffer Size.
  • Page 5: Chapter 2 Installation

    Chapter 2 Installation Installing Mix 51 Installers can be downloaded from the Neyrinck website (www.neyrinck.com) Installation steps are essentially the same, regardless of the bundle, package, or system you purchase. Installation To install Mix 51: 1. If Pro Tools is running, Quit Pro Tools.
  • Page 6: Chapter 3 Quick Start Guide

    Chapter 3 Quick Start Guide Overview This section guides you through steps to create a Pro Tools session that will pan one audio track to a 5.1 main bus and a quad reverb effect send which will be monitored out six channels of your Pro Tools system.
  • Page 7 purpose is to provide outputs that can be routed into other tracks, as Connect The Outputs Create five stereo auxiliary tracks and change the track names to: Dialog Front, Dialog C LFE, Dialog Rear, Reverb Front, and Reverb Rear, respectively. Then set the track outputs to Front, Center-LFE, Rear, Front, and Rear, respectively.
  • Page 8: Chapter 4 Surround Mixer Plug-In

    Chapter 4 Surround Mixer Plug-In Overview The Surround Mixer is implemented as an RTAS plug-in and can be placed on any mono or stereo track. Because a single instance of the Surround Mixer plug-in manages all Mix 51 surround inputs and outputs in a Pro Tools session, it is not necessary to insert more than one Surround Mixer.
  • Page 9 Description and Use Of Controls The Surround Mixer user interface provides master output control of the three 5.1 busses and three quad- send busses. Each bus has volume, mute, and solo controls. Surround Mixer Controls – Default Settings When the Surround Mixer plug-in is opened, the controls default to unity gain with no muting or soloing.
  • Page 10: Chapter 5 Surround Panner Plug-In

    Chapter 5 Surround Panner Plug-In Overview The Surround Panner plug-in operates as an RTAS plug-in on mono and stereo tracks. It will simultaneously pan to one of the 5.1 channel main busses and to one of the quad-channel effect send busses.
  • Page 11 The mute buttons will silence the trackʼs contribution to the main bus and/or send bus you have chosen. The solo button will only allow the audio through for this track and any other soloed tracks. If you want other tracks coming through the Mix 51 mixer, then they need to be soloed also.
  • Page 12 channel only, you should use the LFE panner plug-in. Default/Fine-Tune Opt-click (OS X) or alt-click (WinXP) to reset any control to the default position. Hold down the cmd key (OS X) or the control key (WinXP) to perform fine-tuned adjustments.
  • Page 13: Chapter 6 Lfe Send Plug-In

    Chapter 6 LFE Send Plug-In Overview The LFE Send plug-in operates as an RTAS plug-in in mono or multi- mono for stereo tracks. Its purpose is to allow you to send a track directly to the LFE channel without having to also mix the signal into the main L/C/R/Ls/Rs outputs.
  • Page 14: Chapter 7 Automation

    Chapter 7 Automation Overview All of the Mix 51 parameters can be automated using standard Pro Tools plug-in automation. Click the “auto” button in the Mix 51 plug-in window header and add the controls you would like to be automated. When the track is in “write” mode (or other modes which write/update automation) you should see a red box drawn around any controls you have chosen to be automated.
  • Page 15 Panner with all controls in “write” automation enabled mode Thus, to migrate the Left-Right panning automation of Mix 51, you must copy it into the Front Position and Rear Position pan automation tracks of the Pro Tools panner. To do so, select the track automation for the Mix 51 Left-Right pan control and copy it.
  • Page 16: Chapter 8 Pro Logic™ Ii Movie Mode Monitoring

    Chapter 8 Pro Logic™ II Movie Mode Monitoring Overview Mix 51 provides a stereo, matrix encoded, LtRt output that is compatible with Dolby Pro Logic II decoding systems. This allows you to use a stereo Pro Tools LE system with a 5.1 home theater system for monitoring.
  • Page 17 menu which shows the various Mix 51 outputs available (from each of the Main Bus outputs and Send Bus outputs). Panner or Mixer Not Getting any Signal The track must not be set to “no output”, or else the Mix 51 plug-ins will not receive any input signal (even if you donʼt want the main track to be routed anywhere, you need to have it go to an unused bus or perhaps a separate stereo output).
