Becoming Familiar with your CVR500 Remote

All adjustments to your Car Vision® system are made via the CVR500 remote control. For your convenience the buttons
on the remote are backlit to aid in use under low light conditions. The CVR500 remote also includes a speaker for audio
equipped systems and serves to provide an audible alert when the system is used in conjunction with our active radar
component.
Button Label and Function
Manually turns the display on or places it in standby.
Accesses the on-screen users menu.
Scrolls through the menu items.
Adjusts the radar audible alert volume between three available preset levels.
(Active when used with a compatible radar system)
Goes back to the prior character when naming camera positions.
Increases screen brightness.
Increases the value of a menu item.
Decreases screen brightness.
Decreases the value of a menu item.
Selects the external video input. (EXT must be set to ON in the Installer's
Menu before EXT can be selected).
Displays the selected Multi-Camera View.
Skips to the next character when naming camera positions.
Manually Selects Camera 1
Selects the next page while displaying the menu
Manually Selects Camera 2
Selects the prior page while displaying the menu
Manually Selects Camera 3
Manually Selects Camera 4
Manually Selects Camera 5
Allows the user to Auto Cycle through the connected cameras.
Press both buttons simultaneously to access the Installer Menu.
